Image class for storing images. More...
#include <mitkImage.h>
Public Types | |
| enum | ImportMemoryManagementType { CopyMemory, ManageMemory, ReferenceMemory, DontManageMemory = ReferenceMemory } |
| typedef Image | Self |
| typedef SlicedData | Superclass |
| typedef itk::SmartPointer< Self > | Pointer |
| typedef itk::SmartPointer < const Self > | ConstPointer |
| typedef itk::SmartPointerForwardReference < ImageDataItem > | ImageDataItemPointer |
| typedef std::vector < ImageDataItemPointer > | ImageDataItemPointerArray |
| Vector container of SmartPointers to ImageDataItems; Class is only for internal usage to allow convenient access to all slices over iterators; See documentation of ImageDataItem for details. | |
| typedef itk::Statistics::Histogram < double > | HistogramType |
Public Member Functions | |
| virtual const char * | GetClassName () const |
| const mitk::PixelType & | GetPixelType (int n=0) const |
| Returns the PixelType of channel n. | |
| unsigned int | GetDimension () const |
| Get dimension of the image. | |
| unsigned int | GetDimension (int i) const |
| Get the size of dimension i (e.g., i=0 results in the number of pixels in x-direction). | |
| virtual void * | GetData () |
| double | GetPixelValueByIndex (const mitk::Index3D &position, unsigned int timestep=0) |
| double | GetPixelValueByWorldCoordinate (const mitk::Point3D &position, unsigned int timestep=0) |
| virtual vtkImageData * | GetVtkImageData (int t=0, int n=0) |
| Get a volume at a specific time t of channel n as a vtkImageData. | |
| virtual mitkIpPicDescriptor * | GetPic () |
| Get the complete image, i.e., all channels linked together, as a mitkIpPicDescriptor. | |
| virtual bool | IsSliceSet (int s=0, int t=0, int n=0) const |
| Check whether slice s at time t in channel n is set. | |
| virtual bool | IsVolumeSet (int t=0, int n=0) const |
| Check whether volume at time t in channel n is set. | |
| virtual bool | IsChannelSet (int n=0) const |
| Check whether the channel n is set. | |
| virtual bool | SetSlice (const void *data, int s=0, int t=0, int n=0) |
| Set data as slice s at time t in channel n. It is in the responsibility of the caller to ensure that the data vector data is really a slice (at least is not smaller than a slice), since there is no chance to check this. | |
| virtual bool | SetVolume (const void *data, int t=0, int n=0) |
| Set data as volume at time t in channel n. It is in the responsibility of the caller to ensure that the data vector data is really a volume (at least is not smaller than a volume), since there is no chance to check this. | |
| virtual bool | SetChannel (const void *data, int n=0) |
| Set data in channel n. It is in the responsibility of the caller to ensure that the data vector data is really a channel (at least is not smaller than a channel), since there is no chance to check this. | |
| virtual bool | SetImportSlice (void *data, int s=0, int t=0, int n=0, ImportMemoryManagementType importMemoryManagement=CopyMemory) |
| Set data as slice s at time t in channel n. It is in the responsibility of the caller to ensure that the data vector data is really a slice (at least is not smaller than a slice), since there is no chance to check this. | |
| virtual bool | SetImportVolume (void *data, int t=0, int n=0, ImportMemoryManagementType importMemoryManagement=CopyMemory) |
| Set data as volume at time t in channel n. It is in the responsibility of the caller to ensure that the data vector data is really a volume (at least is not smaller than a volume), since there is no chance to check this. | |
| virtual bool | SetImportChannel (void *data, int n=0, ImportMemoryManagementType importMemoryManagement=CopyMemory) |
| Set data in channel n. It is in the responsibility of the caller to ensure that the data vector data is really a channel (at least is not smaller than a channel), since there is no chance to check this. | |
| virtual bool | SetPicSlice (const mitkIpPicDescriptor *pic, int s=0, int t=0, int n=0, ImportMemoryManagementType importMemoryManagement=CopyMemory) |
| Set pic as slice s at time t in channel n. | |
| virtual bool | SetPicVolume (const mitkIpPicDescriptor *pic, int t=0, int n=0, ImportMemoryManagementType importMemoryManagement=CopyMemory) |
| Set pic as volume at time t in channel n. | |
| virtual bool | SetPicChannel (const mitkIpPicDescriptor *pic, int n=0, ImportMemoryManagementType importMemoryManagement=CopyMemory) |
| Set pic in channel n. | |
| virtual void | Initialize (const mitk::PixelType &type, unsigned int dimension, unsigned int *dimensions, unsigned int channels=1) |
| virtual void | Initialize (const mitk::PixelType &type, const mitk::Geometry3D &geometry, unsigned int channels=1, int tDim=-1) |
| virtual void | Initialize (const mitk::PixelType &type, int sDim, const mitk::Geometry2D &geometry2d, bool flipped=false, unsigned int channels=1, int tDim=-1) |
| virtual void | Initialize (const mitk::Image *image) |
| virtual void | Initialize (const mitkIpPicDescriptor *pic, int channels=1, int tDim=-1, int sDim=-1) |
| virtual void | Initialize (vtkImageData *vtkimagedata, int channels=1, int tDim=-1, int sDim=-1) |
| template<typename itkImageType > | |
| void | InitializeByItk (const itkImageType *itkimage, int channels=1, int tDim=-1, int sDim=-1) |
| virtual bool | IsValidSlice (int s=0, int t=0, int n=0) const |
| Check whether slice s at time t in channel n is valid, i.e., is (or can be) inside of the image. | |
| virtual bool | IsValidVolume (int t=0, int n=0) const |
| Check whether volume at time t in channel n is valid, i.e., is (or can be) inside of the image. | |
| virtual bool | IsValidChannel (int n=0) const |
| Check whether the channel n is valid, i.e., is (or can be) inside of the image. | |
| bool | IsRotated () const |
| Returns true if an image is rotated, i.e. its geometry's transformation matrix has nonzero elements besides the diagonal. Non-diagonal elements are checked if larger then 1/1000 of the matrix' trace. | |
| unsigned int * | GetDimensions () const |
| Get the sizes of all dimensions as an integer-array. | |
| virtual void | SetGeometry (Geometry3D *aGeometry3D) |
| Set the Geometry3D of the data, which will be referenced (not copied!). It has to be a sub-class of SlicedGeometry3D. | |
| virtual const HistogramType * | GetScalarHistogram (int t=0) const |
| virtual ScalarType | GetScalarValueMin (int t=0) const |
| Get the minimum for scalar images. | |
| virtual ScalarType | GetScalarValueMax (int t=0) const |
| Get the maximum for scalar images. | |
| virtual ScalarType | GetScalarValue2ndMin (int t=0) const |
| Get the second smallest value for scalar images. | |
| virtual mitk::ScalarType | GetScalarValueMinNoRecompute (unsigned int t=0) const |
| Get the smallest value for scalar images, but do not recompute it first. | |
| virtual mitk::ScalarType | GetScalarValue2ndMinNoRecompute (unsigned int t=0) const |
| Get the second smallest value for scalar images, but do not recompute it first. | |
| virtual ScalarType | GetScalarValue2ndMax (int t=0) const |
| Get the second largest value for scalar images. | |
| virtual mitk::ScalarType | GetScalarValueMaxNoRecompute (unsigned int t=0) const |
| Get the largest value for scalar images, but do not recompute it first. | |
| virtual mitk::ScalarType | GetScalarValue2ndMaxNoRecompute (unsigned int t=0) const |
| Get the second largest value for scalar images, but do not recompute it first. | |
| mitk::ScalarType | GetCountOfMinValuedVoxels (int t=0) const |
| Get the count of voxels with the smallest scalar value in the dataset. | |
| mitk::ScalarType | GetCountOfMaxValuedVoxels (int t=0) const |
| Get the count of voxels with the largest scalar value in the dataset. | |
| virtual unsigned int | GetCountOfMaxValuedVoxelsNoRecompute (unsigned int t=0) const |
| Get the count of voxels with the largest scalar value in the dataset. | |
| virtual unsigned int | GetCountOfMinValuedVoxelsNoRecompute (unsigned int t=0) const |
| Get the count of voxels with the smallest scalar value in the dataset. | |
| virtual ImageDataItemPointer | GetSliceData (int s=0, int t=0, int n=0, void *data=NULL, ImportMemoryManagementType importMemoryManagement=CopyMemory) |
| virtual ImageDataItemPointer | GetVolumeData (int t=0, int n=0, void *data=NULL, ImportMemoryManagementType importMemoryManagement=CopyMemory) |
| virtual ImageDataItemPointer | GetChannelData (int n=0, void *data=NULL, ImportMemoryManagementType importMemoryManagement=CopyMemory) |
Static Public Member Functions | |
| static Pointer | New () |
Protected Member Functions | |
| int | GetSliceIndex (int s=0, int t=0, int n=0) const |
| int | GetVolumeIndex (int t=0, int n=0) const |
| void | ComputeOffsetTable () |
| virtual void | Expand (int timeSteps) const |
| virtual bool | IsValidTimeStep (int t) const |
| virtual void | ResetImageStatistics () const |
| virtual void | ComputeImageStatistics (int t=0) const |
| virtual ImageDataItemPointer | AllocateSliceData (int s=0, int t=0, int n=0, void *data=NULL, ImportMemoryManagementType importMemoryManagement=CopyMemory) |
| virtual ImageDataItemPointer | AllocateVolumeData (int t=0, int n=0, void *data=NULL, ImportMemoryManagementType importMemoryManagement=CopyMemory) |
| virtual ImageDataItemPointer | AllocateChannelData (int n=0, void *data=NULL, ImportMemoryManagementType importMemoryManagement=CopyMemory) |
| Image () | |
| virtual | ~Image () |
| virtual void | Clear () |
| Calls ClearData() and InitializeEmpty();. | |
| virtual void | Initialize () |
| ImageTimeSelector * | GetTimeSelector () const |
| virtual void | PrintSelf (std::ostream &os, itk::Indent indent) const |
Protected Attributes | |
| ImageDataItemPointerArray | m_Channels |
| ImageDataItemPointerArray | m_Volumes |
| ImageDataItemPointerArray | m_Slices |
| unsigned int | m_Dimension |
| unsigned int * | m_Dimensions |
| vcl_size_t * | m_OffsetTable |
| ImageDataItemPointer | m_CompleteData |
| PixelType | m_PixelType |
| itk::Object::Pointer | m_HistogramGeneratorObject |
| itk::Object::Pointer | m_TimeSelectorForExtremaObject |
| std::vector< unsigned int > | m_CountOfMinValuedVoxels |
| std::vector< unsigned int > | m_CountOfMaxValuedVoxels |
| std::vector< ScalarType > | m_ScalarMin |
| std::vector< ScalarType > | m_ScalarMax |
| std::vector< ScalarType > | m_Scalar2ndMin |
| std::vector< ScalarType > | m_Scalar2ndMax |
| itk::TimeStamp | m_LastRecomputeTimeStamp |
Friends | |
| class | SubImageSelector |
| template<typename ItkImageType > | |
| void | _ComputeExtremaInItkImage (ItkImageType *itkImage, mitk::Image *mitkImage, int t) |
Image class for storing images.
Can be asked for header information, the data vector, the mitkIpPicDescriptor struct or vtkImageData objects. If not the complete data is required, the appropriate SubImageSelector class should be used for access. Image organizes sets of slices (s x 2D), volumes (t x 3D) and channels (n x ND). Channels are for different kind of data, e.g., morphology in channel 0, velocities in channel 1. All channels must have the same Geometry! In particular, the dimensions of all channels are the same, only the pixel-type may differ between channels.
For importing ITK images use of mitk::ITKImageImport is recommended, see Adaptor Classes.
For ITK v3.8 and older: Converting coordinates from the ITK physical coordinate system (which does not support rotated images) to the MITK world coordinate system should be performed via the Geometry3D of the Image, see Geometry3D::WorldToItkPhysicalPoint.
QtFreeRender.cpp, Step3.cpp, Step6.cpp, and Step6RegionGrowing.txx.
Definition at line 62 of file mitkImage.h.
| typedef itk::SmartPointer<const Self> mitk::Image::ConstPointer |
Reimplemented from mitk::SlicedData.
Reimplemented in mitk::DiffusionImage< TPixelType >, mitk::QBallImage, mitk::TensorImage, mitk::SeedsImage, and mitk::DiffusionImage< DiffusionImagePixelType >.
Definition at line 67 of file mitkImage.h.
| typedef itk::Statistics::Histogram<double> mitk::Image::HistogramType |
Definition at line 88 of file mitkImage.h.
| typedef itk::SmartPointerForwardReference<ImageDataItem> mitk::Image::ImageDataItemPointer |
Smart Pointer type to a ImageDataItem.
Definition at line 69 of file mitkImage.h.
| typedef std::vector<ImageDataItemPointer> mitk::Image::ImageDataItemPointerArray |
Vector container of SmartPointers to ImageDataItems; Class is only for internal usage to allow convenient access to all slices over iterators; See documentation of ImageDataItem for details.
Definition at line 86 of file mitkImage.h.
| typedef itk::SmartPointer<Self> mitk::Image::Pointer |
Reimplemented from mitk::SlicedData.
Reimplemented in mitk::DiffusionImage< TPixelType >, mitk::QBallImage, mitk::TensorImage, mitk::SeedsImage, and mitk::DiffusionImage< DiffusionImagePixelType >.
Definition at line 67 of file mitkImage.h.
| typedef Image mitk::Image::Self |
Reimplemented from mitk::SlicedData.
Reimplemented in mitk::DiffusionImage< TPixelType >, mitk::QBallImage, mitk::TensorImage, mitk::SeedsImage, and mitk::DiffusionImage< DiffusionImagePixelType >.
Definition at line 67 of file mitkImage.h.
| typedef SlicedData mitk::Image::Superclass |
Reimplemented from mitk::SlicedData.
Reimplemented in mitk::DiffusionImage< TPixelType >, mitk::QBallImage, mitk::TensorImage, mitk::SeedsImage, and mitk::DiffusionImage< DiffusionImagePixelType >.
Definition at line 67 of file mitkImage.h.
Definition at line 80 of file mitkImage.h.
{ CopyMemory, ManageMemory, ReferenceMemory, DontManageMemory = ReferenceMemory };
| mitk::Image::Image | ( | ) | [protected] |
Definition at line 35 of file mitkImage.cpp.
References m_CountOfMaxValuedVoxels, m_CountOfMinValuedVoxels, m_HistogramGeneratorObject, mitk::BaseData::m_Initialized, m_Scalar2ndMax, m_Scalar2ndMin, m_ScalarMax, m_ScalarMin, QuadProgPP::max(), and New().
: m_Dimension(0), m_Dimensions(NULL), m_OffsetTable(NULL), m_CompleteData(NULL), m_PixelType(NULL), m_TimeSelectorForExtremaObject(NULL) { m_CountOfMinValuedVoxels.resize(1, 0); m_CountOfMaxValuedVoxels.resize(1, 0); m_ScalarMin.resize(1, itk::NumericTraits<ScalarType>::max()); m_ScalarMax.resize(1, itk::NumericTraits<ScalarType>::NonpositiveMin()); m_Scalar2ndMin.resize(1, itk::NumericTraits<ScalarType>::max()); m_Scalar2ndMax.resize(1, itk::NumericTraits<ScalarType>::NonpositiveMin()); m_Initialized = false; mitk::HistogramGenerator::Pointer generator = mitk::HistogramGenerator::New(); m_HistogramGeneratorObject = generator; }
| mitk::Image::~Image | ( | ) | [protected, virtual] |
Definition at line 52 of file mitkImage.cpp.
{
Clear();
m_ReferenceCountLock.Lock();
m_ReferenceCount = 3;
m_ReferenceCountLock.Unlock();
m_HistogramGeneratorObject = NULL;
m_TimeSelectorForExtremaObject = NULL;
m_ReferenceCountLock.Lock();
m_ReferenceCount = 0;
m_ReferenceCountLock.Unlock();
delete [] m_OffsetTable;
}
| mitk::Image::ImageDataItemPointer mitk::Image::AllocateChannelData | ( | int | n = 0, |
| void * | data = NULL, |
||
| ImportMemoryManagementType | importMemoryManagement = CopyMemory |
||
| ) | [protected, virtual] |
Definition at line 1139 of file mitkImage.cpp.
{
ImageDataItemPointer ch;
// allocate new channel
if(importMemoryManagement == CopyMemory)
{
ch=new ImageDataItem(m_PixelType, m_Dimension, m_Dimensions, NULL, true);
if(data != NULL)
std::memcpy(ch->GetData(), data, m_OffsetTable[4]*(m_PixelType.GetBpe()/8));
}
else
{
ch=new ImageDataItem(m_PixelType, m_Dimension, m_Dimensions, data, importMemoryManagement == ManageMemory);
}
m_Channels[n]=ch;
return ch;
}
| mitk::Image::ImageDataItemPointer mitk::Image::AllocateSliceData | ( | int | s = 0, |
| int | t = 0, |
||
| int | n = 0, |
||
| void * | data = NULL, |
||
| ImportMemoryManagementType | importMemoryManagement = CopyMemory |
||
| ) | [protected, virtual] |
Definition at line 1073 of file mitkImage.cpp.
{
int pos;
pos=GetSliceIndex(s,t,n);
// is slice available as part of a volume that is available?
ImageDataItemPointer sl, ch, vol;
vol=m_Volumes[GetVolumeIndex(t,n)];
if(vol.GetPointer()!=NULL)
{
sl=new ImageDataItem(*vol, 2, data, importMemoryManagement == ManageMemory, ((size_t) s)*m_OffsetTable[2]*(m_PixelType.GetBpe()/8));
sl->SetComplete(true);
return m_Slices[pos]=sl;
}
// is slice available as part of a channel that is available?
ch=m_Channels[n];
if(ch.GetPointer()!=NULL)
{
sl=new ImageDataItem(*ch, 2, data, importMemoryManagement == ManageMemory, (((size_t) s)*m_OffsetTable[2]+((size_t) t)*m_OffsetTable[3])*(m_PixelType.GetBpe()/8));
sl->SetComplete(true);
return m_Slices[pos]=sl;
}
// allocate new volume (instead of a single slice to keep data together!)
m_Volumes[GetVolumeIndex(t,n)]=vol=AllocateVolumeData(t,n,NULL,importMemoryManagement);
sl=new ImageDataItem(*vol, 2, data, importMemoryManagement == ManageMemory, ((size_t) s)*m_OffsetTable[2]*(m_PixelType.GetBpe()/8));
sl->SetComplete(true);
return m_Slices[pos]=sl;
//sl=new ImageDataItem(m_PixelType, 2, m_Dimensions);
//m_Slices[pos]=sl;
//return vol;
}
| mitk::Image::ImageDataItemPointer mitk::Image::AllocateVolumeData | ( | int | t = 0, |
| int | n = 0, |
||
| void * | data = NULL, |
||
| ImportMemoryManagementType | importMemoryManagement = CopyMemory |
||
| ) | [protected, virtual] |
Definition at line 1110 of file mitkImage.cpp.
{
int pos;
pos=GetVolumeIndex(t,n);
// is volume available as part of a channel that is available?
ImageDataItemPointer ch, vol;
ch=m_Channels[n];
if(ch.GetPointer()!=NULL)
{
vol=new ImageDataItem(*ch, 3, data, importMemoryManagement == ManageMemory, (((size_t) t)*m_OffsetTable[3])*(m_PixelType.GetBpe()/8));
return m_Volumes[pos]=vol;
}
// allocate new volume
if(importMemoryManagement == CopyMemory)
{
vol=new ImageDataItem(m_PixelType, 3, m_Dimensions, NULL, true);
if(data != NULL)
std::memcpy(vol->GetData(), data, m_OffsetTable[3]*(m_PixelType.GetBpe()/8));
}
else
{
vol=new ImageDataItem(m_PixelType, 3, m_Dimensions, data, importMemoryManagement == ManageMemory);
}
m_Volumes[pos]=vol;
return vol;
}
| void mitk::Image::Clear | ( | ) | [protected, virtual] |
Calls ClearData() and InitializeEmpty();.
Reimplemented from mitk::BaseData.
Definition at line 1162 of file mitkImage.cpp.
{
Superclass::Clear();
delete [] m_Dimensions;
m_Dimensions = NULL;
}
| void mitk::Image::ComputeImageStatistics | ( | int | t = 0 ) |
const [protected, virtual] |
Definition at line 1305 of file mitkImage.cpp.
References AccessByItk_2, mitk::ImageSource::GetOutput(), QuadProgPP::max(), mitk::ImageTimeSelector::SetTimeNr(), and QuadProgPP::t().
{
// timestep valid?
if (!IsValidTimeStep(t)) return;
// image modified?
if (this->GetMTime() > m_LastRecomputeTimeStamp.GetMTime())
this->ResetImageStatistics();
// adapt vector length
this->Expand(t+1);
// do we have valid information already?
if( m_ScalarMin[t] != itk::NumericTraits<ScalarType>::max() ||
m_Scalar2ndMin[t] != itk::NumericTraits<ScalarType>::max() ) return; // Values already calculated before...
if(this->m_PixelType.GetNumberOfComponents() == 1)
{
// recompute
mitk::ImageTimeSelector* timeSelector = this->GetTimeSelector();
if(timeSelector!=NULL)
{
timeSelector->SetTimeNr(t);
timeSelector->UpdateLargestPossibleRegion();
mitk::Image* image = timeSelector->GetOutput();
mitk::Image* thisImage = const_cast<Image*>(this);
AccessByItk_2( image, _ComputeExtremaInItkImage, thisImage, t );
}
}
else if(this->m_PixelType.GetNumberOfComponents() > 1)
{
m_ScalarMin[t] = 0;
m_ScalarMax[t] = 255;
}
}
| void mitk::Image::ComputeOffsetTable | ( | ) | [protected] |
Definition at line 1042 of file mitkImage.cpp.
{
if(m_OffsetTable!=NULL)
delete [] m_OffsetTable;
m_OffsetTable=new size_t[m_Dimension>4 ? m_Dimension+1 : 4+1];
unsigned int i;
size_t num=1;
m_OffsetTable[0] = 1;
for (i=0; i < m_Dimension; ++i)
{
num *= m_Dimensions[i];
m_OffsetTable[i+1] = num;
}
for (;i < 4; ++i)
m_OffsetTable[i+1] = num;
}
| void mitk::Image::Expand | ( | int | timeSteps ) | const [protected, virtual] |
Definition at line 1280 of file mitkImage.cpp.
References QuadProgPP::max().
{
if(timeSteps < 1) itkExceptionMacro(<< "Invalid timestep in Image!");
if(! IsValidTimeStep( timeSteps-1 ) ) return;
if(timeSteps > (int)m_ScalarMin.size() )
{
m_ScalarMin.resize(timeSteps, itk::NumericTraits<ScalarType>::max());
m_ScalarMax.resize(timeSteps, itk::NumericTraits<ScalarType>::NonpositiveMin());
m_Scalar2ndMin.resize(timeSteps, itk::NumericTraits<ScalarType>::max());
m_Scalar2ndMax.resize(timeSteps, itk::NumericTraits<ScalarType>::NonpositiveMin());
m_CountOfMinValuedVoxels.resize(timeSteps, 0);
m_CountOfMaxValuedVoxels.resize(timeSteps, 0);
}
}
| mitk::Image::ImageDataItemPointer mitk::Image::GetChannelData | ( | int | n = 0, |
| void * | data = NULL, |
||
| ImportMemoryManagementType | importMemoryManagement = CopyMemory |
||
| ) | [virtual] |
Definition at line 351 of file mitkImage.cpp.
References mitkIpPicDescriptor, mitk::ImageDataItem::SetComplete(), and QuadProgPP::t().
Referenced by mitk::SubImageSelector::GetChannelData().
{
if(IsValidChannel(n)==false) return NULL;
ImageDataItemPointer ch, vol;
ch=m_Channels[n];
if((ch.GetPointer()!=NULL) && (ch->IsComplete()))
return ch;
// let's see if all volumes are set, so that we can (could) combine them to a channel
if(IsChannelSet(n))
{
// if there is only one time frame we do not need to combine anything
if(m_Dimensions[3]<=1)
{
vol=GetVolumeData(0,n,data,importMemoryManagement);
ch=new ImageDataItem(*vol, 3, data, importMemoryManagement == ManageMemory);
ch->SetComplete(true);
}
else
{
ch=m_Channels[n];
// ok, let's combine the volumes!
if(ch.GetPointer()==NULL)
ch=new ImageDataItem(m_PixelType, m_Dimension, m_Dimensions, NULL, true);
ch->SetComplete(true);
size_t size=m_OffsetTable[m_Dimension-1]*(m_PixelType.GetBpe()/8);
unsigned int t;
ImageDataItemPointerArray::iterator slicesIt = m_Slices.begin()+n*m_Dimensions[2]*m_Dimensions[3];
for(t=0;t<m_Dimensions[3];++t)
{
int posVol;
ImageDataItemPointer vol;
posVol=GetVolumeIndex(t,n);
vol=GetVolumeData(t,n,data,importMemoryManagement);
if(vol->GetParent()!=ch)
{
// copy data of volume in channel
size_t offset = ((size_t) t)*m_OffsetTable[3]*(m_PixelType.GetBpe()/8);
std::memcpy(static_cast<char*>(ch->GetData())+offset, vol->GetData(), size);
mitkIpPicDescriptor * pic = vol->GetPicDescriptor();
// replace old volume with reference to channel
vol=new ImageDataItem(*ch, 3, data, importMemoryManagement == ManageMemory, offset);
vol->SetComplete(true);
mitkIpFuncCopyTags(vol->GetPicDescriptor(), pic);
m_Volumes[posVol]=vol;
// get rid of slices - they may point to old volume
ImageDataItemPointer dnull=NULL;
for(unsigned int i = 0; i < m_Dimensions[2]; ++i, ++slicesIt)
{
assert(slicesIt != m_Slices.end());
*slicesIt = dnull;
}
}
}
if(ch->GetPicDescriptor()->info->tags_head==NULL)
mitkIpFuncCopyTags(ch->GetPicDescriptor(), m_Volumes[GetVolumeIndex(0,n)]->GetPicDescriptor());
}
return m_Channels[n]=ch;
}
// channel is unavailable. Can we calculate it?
if((GetSource()!=NULL) && (GetSource()->Updating()==false))
{
// ... wir muessen rechnen!!! ....
m_RequestedRegion.SetIndex(0, 0);
m_RequestedRegion.SetIndex(1, 0);
m_RequestedRegion.SetIndex(2, 0);
m_RequestedRegion.SetIndex(3, 0);
m_RequestedRegion.SetIndex(4, n);
m_RequestedRegion.SetSize(0, m_Dimensions[0]);
m_RequestedRegion.SetSize(1, m_Dimensions[1]);
m_RequestedRegion.SetSize(2, m_Dimensions[2]);
m_RequestedRegion.SetSize(3, m_Dimensions[3]);
m_RequestedRegion.SetSize(4, 1);
m_RequestedRegionInitialized=true;
GetSource()->Update();
// did it work?
if(IsChannelSet(n))
//yes: now we can call ourselves without the risk of a endless loop (see "if" above)
return GetChannelData(n,data,importMemoryManagement);
else
return NULL;
}
else
{
ImageDataItemPointer item = AllocateChannelData(n,data,importMemoryManagement);
item->SetComplete(true);
return item;
}
}
| virtual const char* mitk::Image::GetClassName | ( | ) | const [virtual] |
Reimplemented from mitk::SlicedData.
Reimplemented in mitk::DiffusionImage< TPixelType >, mitk::QBallImage, mitk::TensorImage, mitk::SeedsImage, and mitk::DiffusionImage< DiffusionImagePixelType >.
| mitk::ScalarType mitk::Image::GetCountOfMaxValuedVoxels | ( | int | t = 0 ) |
const |
Get the count of voxels with the largest scalar value in the dataset.
Definition at line 1372 of file mitkImage.cpp.
References QuadProgPP::t().
{
ComputeImageStatistics(t);
return m_CountOfMaxValuedVoxels[t];
}
| virtual unsigned int mitk::Image::GetCountOfMaxValuedVoxelsNoRecompute | ( | unsigned int | t = 0 ) |
const [inline, virtual] |
Get the count of voxels with the largest scalar value in the dataset.
Definition at line 527 of file mitkImage.h.
References QuadProgPP::t().
Referenced by mitk::ImageMapperGL2D::Paint(), and mitk::LevelWindow::SetAuto().
{
if ( t < m_CountOfMaxValuedVoxels.size() )
return m_CountOfMaxValuedVoxels[t];
else return 0;
}
| mitk::ScalarType mitk::Image::GetCountOfMinValuedVoxels | ( | int | t = 0 ) |
const |
Get the count of voxels with the smallest scalar value in the dataset.
Definition at line 1366 of file mitkImage.cpp.
References QuadProgPP::t().
{
ComputeImageStatistics(t);
return m_CountOfMinValuedVoxels[t];
}
| virtual unsigned int mitk::Image::GetCountOfMinValuedVoxelsNoRecompute | ( | unsigned int | t = 0 ) |
const [inline, virtual] |
Get the count of voxels with the smallest scalar value in the dataset.
Definition at line 536 of file mitkImage.h.
References QuadProgPP::t().
Referenced by mitk::LevelWindow::SetAuto().
{
if ( t < m_CountOfMinValuedVoxels.size() )
return m_CountOfMinValuedVoxels[t];
else return 0;
}
| void * mitk::Image::GetData | ( | ) | [virtual] |
Definition at line 83 of file mitkImage.cpp.
Referenced by mitk::PlaneCutFilter::GenerateData(), mitk::SegmentationInterpolationController::ScanWholeVolume(), testImageToItkAndBack(), and mitk::ImageWriter::WriteByITK().
{
if(m_Initialized==false)
{
if(GetSource()==NULL)
return NULL;
if(GetSource()->Updating()==false)
GetSource()->UpdateOutputInformation();
}
m_CompleteData=GetChannelData();
return m_CompleteData->GetData();
}
| unsigned int mitk::Image::GetDimension | ( | ) | const |
Get dimension of the image.
Definition at line 71 of file mitkImage.cpp.
Referenced by QmitkSlicesInterpolator::AcceptAllInterpolations(), mitk::ImageToOpenCVImageFilter::CheckImage(), mitk::NodePredicateDimension::CheckNode(), CompareImageSliceTestHelper::CompareSlice(), mitk::AutoCropImageFilter::ComputeNewImageBounds(), mitk::Tool::CreateEmptySegmentationNode(), mitk::SegTool2D::DetermineAffectedImageSlice(), mitk::ImageMapperGL2D::GenerateData(), QmitkVolumetryView::OnCalculateVolume(), QmitkVolumetryView::OnImageSelected(), mitk::ImageMapperGL2D::Paint(), QmitkMeasurement::PlanarFigureSelectionChanged(), mitk::SegmentationInterpolationController::ScanWholeVolume(), mitk::LevelWindow::SetAuto(), mitk::SegmentationInterpolationController::SetChangedVolume(), mitk::VolumeDataVtkMapper3D::SetClippingPlane(), mitk::CompressedImageContainer::SetImage(), mitk::ImageToItk< TOutputImage >::SetInput(), mitk::SegmentationInterpolationController::SetSegmentationVolume(), mitk::ImageSource::SplitRequestedRegion(), mitkCompressedImageContainerTestClass::Test(), mitkOverwriteSliceImageFilterTestClass::Test2D(), mitkExtractImageFilterTestClass::Test2D(), mitkOverwriteSliceImageFilterTestClass::Test3D(), mitkExtractImageFilterTestClass::Test3D(), mitkExtractImageFilterTestClass::Test4D(), mitkOverwriteSliceImageFilterTestClass::TestOtherD(), mitkExtractImageFilterTestClass::TestOtherD(), and mitk::ImageWriter::WriteByITK().
{
return m_Dimension;
}
| unsigned int mitk::Image::GetDimension | ( | int | i ) | const |
Get the size of dimension i (e.g., i=0 results in the number of pixels in x-direction).
Definition at line 76 of file mitkImage.cpp.
{
if((i>=0) && (i<(int)m_Dimension))
return m_Dimensions[i];
return 1;
}
| unsigned int * mitk::Image::GetDimensions | ( | ) | const |
Get the sizes of all dimensions as an integer-array.
Definition at line 1157 of file mitkImage.cpp.
Referenced by QmitkSlicesInterpolator::AcceptAllInterpolations(), mitk::Tool::CreateEmptySegmentationNode(), mitk::VolumeDataVtkMapper3D::EnableMask(), mitk::CorrectorAlgorithm::ItkCalculateDifferenceImage(), mitk::LevelWindow::SetAuto(), and mitk::ImageWriter::WriteByITK().
{
return m_Dimensions;
}
| mitkIpPicDescriptor * mitk::Image::GetPic | ( | ) | [virtual] |
Get the complete image, i.e., all channels linked together, as a mitkIpPicDescriptor.
If you only want to access a slice, volume at a specific time or single channel use one of the SubImageSelector classes.
Definition at line 170 of file mitkImage.cpp.
{
if(m_Initialized==false)
{
if(GetSource()==NULL)
return NULL;
if(GetSource()->Updating()==false)
GetSource()->UpdateOutputInformation();
}
m_CompleteData=GetChannelData();
if(m_CompleteData.GetPointer()==NULL)
return NULL;
return m_CompleteData->GetPicDescriptor();
}
| const mitk::PixelType & mitk::Image::GetPixelType | ( | int | n = 0 ) |
const |
Returns the PixelType of channel n.
Definition at line 66 of file mitkImage.cpp.
Referenced by mitk::NodePredicateDimension::CheckNode(), mitk::RGBToRGBACastImageFilter::GenerateData(), mitk::BoundingObjectCutter::GenerateInputRequestedRegion(), mitk::SurfaceToImageFilter::GenerateOutputInformation(), Initialize(), mitk::RGBToRGBACastImageFilter::IsRGBImage(), CompareImageSliceTestHelper::ItkImageSwitch(), mitk::LevelWindow::SetAuto(), mitk::CompressedImageContainer::SetImage(), mitk::ImageToItk< TOutputImage >::SetInput(), mitk::VolumeDataVtkMapper3D::SetMask(), mitkCompressedImageContainerTestClass::Test(), QmitkImageStatistics::UpdateStatistics(), and mitk::ImageWriter::WriteByITK().
{
return m_PixelType;
}
| double mitk::Image::GetPixelValueByIndex | ( | const mitk::Index3D & | position, |
| unsigned int | timestep = 0 |
||
| ) |
Definition at line 119 of file mitkImage.cpp.
References AccessPixel(), and mitkIpPicDescriptor.
{
mitkIpPicDescriptor* pic = this->GetPic();
double value = 0;
if (this->GetTimeSteps() < timestep)
{
timestep = this->GetTimeSteps();
}
mitkIpPicTypeMultiplex3(AccessPixel, pic, position, value, timestep);
return value;
}
| double mitk::Image::GetPixelValueByWorldCoordinate | ( | const mitk::Point3D & | position, |
| unsigned int | timestep = 0 |
||
| ) |
Definition at line 131 of file mitkImage.cpp.
References AccessPixel(), and mitkIpPicDescriptor.
Referenced by QmitkImageStatistics::ComputeIntensityProfile().
{
mitkIpPicDescriptor* pic = this->GetPic();
double value = 0;
if (this->GetTimeSteps() < timestep)
{
timestep = this->GetTimeSteps();
}
Index3D itkIndex;
this->GetGeometry()->WorldToIndex(position,itkIndex);
mitkIpPicTypeMultiplex3(AccessPixel, pic, itkIndex, value, timestep);
return value;
}
| const mitk::Image::HistogramType * mitk::Image::GetScalarHistogram | ( | int | t = 0 ) |
const [virtual] |
Definition at line 1175 of file mitkImage.cpp.
References mitk::HistogramGenerator::ComputeHistogram(), mitk::HistogramGenerator::GetHistogram(), mitk::ImageSource::GetOutput(), mitk::HistogramGenerator::SetImage(), and mitk::ImageTimeSelector::SetTimeNr().
Referenced by QmitkHistogramWidget::SetHistogram().
{
mitk::ImageTimeSelector* timeSelector = this->GetTimeSelector();
if(timeSelector!=NULL)
{
timeSelector->SetTimeNr(t);
timeSelector->UpdateLargestPossibleRegion();
mitk::HistogramGenerator* generator = static_cast<mitk::HistogramGenerator*>(m_HistogramGeneratorObject.GetPointer());
generator->SetImage(timeSelector->GetOutput());
generator->ComputeHistogram();
return static_cast<const mitk::Image::HistogramType*>(generator->GetHistogram());
}
return NULL;
}
| mitk::ScalarType mitk::Image::GetScalarValue2ndMax | ( | int | t = 0 ) |
const [virtual] |
Get the second largest value for scalar images.
Definition at line 1360 of file mitkImage.cpp.
References QuadProgPP::t().
{
ComputeImageStatistics(t);
return m_Scalar2ndMax[t];
}
| virtual mitk::ScalarType mitk::Image::GetScalarValue2ndMaxNoRecompute | ( | unsigned int | t = 0 ) |
const [inline, virtual] |
Get the second largest value for scalar images, but do not recompute it first.
Definition at line 510 of file mitkImage.h.
References QuadProgPP::t().
Referenced by mitk::LevelWindow::SetAuto().
{
if ( t < m_Scalar2ndMax.size() )
return m_Scalar2ndMax[t];
else return itk::NumericTraits<ScalarType>::NonpositiveMin();
}
| mitk::ScalarType mitk::Image::GetScalarValue2ndMin | ( | int | t = 0 ) |
const [virtual] |
Get the second smallest value for scalar images.
Definition at line 1354 of file mitkImage.cpp.
References QuadProgPP::t().
Referenced by QmitkVolumetryView::OnImageSelected().
{
ComputeImageStatistics(t);
return m_Scalar2ndMin[t];
}
| virtual mitk::ScalarType mitk::Image::GetScalarValue2ndMinNoRecompute | ( | unsigned int | t = 0 ) |
const [inline, virtual] |
Get the second smallest value for scalar images, but do not recompute it first.
Definition at line 488 of file mitkImage.h.
References QuadProgPP::max(), and QuadProgPP::t().
Referenced by mitk::LevelWindow::SetAuto().
{
if ( t < m_Scalar2ndMin.size() )
return m_Scalar2ndMin[t];
else return itk::NumericTraits<ScalarType>::max();
}
| mitk::ScalarType mitk::Image::GetScalarValueMax | ( | int | t = 0 ) |
const [virtual] |
Get the maximum for scalar images.
Definition at line 1348 of file mitkImage.cpp.
References QuadProgPP::t().
Referenced by mitk::ImageMapperGL2D::Paint(), and QmitkImageCropper::SurroundingCheck().
{
ComputeImageStatistics(t);
return m_ScalarMax[t];
}
| virtual mitk::ScalarType mitk::Image::GetScalarValueMaxNoRecompute | ( | unsigned int | t = 0 ) |
const [inline, virtual] |
Get the largest value for scalar images, but do not recompute it first.
Definition at line 501 of file mitkImage.h.
References QuadProgPP::t().
Referenced by QmitkVolumetryView::OnImageSelected(), and mitk::LevelWindow::SetAuto().
{
if ( t < m_ScalarMax.size() )
return m_ScalarMax[t];
else return itk::NumericTraits<ScalarType>::NonpositiveMin();
}
| mitk::ScalarType mitk::Image::GetScalarValueMin | ( | int | t = 0 ) |
const [virtual] |
Get the minimum for scalar images.
Definition at line 1342 of file mitkImage.cpp.
References QuadProgPP::t().
Referenced by mitk::LevelWindow::SetAuto(), and QmitkImageCropper::SurroundingCheck().
{
ComputeImageStatistics(t);
return m_ScalarMin[t];
}
| virtual mitk::ScalarType mitk::Image::GetScalarValueMinNoRecompute | ( | unsigned int | t = 0 ) |
const [inline, virtual] |
Get the smallest value for scalar images, but do not recompute it first.
Definition at line 479 of file mitkImage.h.
References QuadProgPP::max(), and QuadProgPP::t().
{
if ( t < m_ScalarMin.size() )
return m_ScalarMin[t];
else return itk::NumericTraits<ScalarType>::max();
}
| mitk::Image::ImageDataItemPointer mitk::Image::GetSliceData | ( | int | s = 0, |
| int | t = 0, |
||
| int | n = 0, |
||
| void * | data = NULL, |
||
| ImportMemoryManagementType | importMemoryManagement = CopyMemory |
||
| ) | [virtual] |
Definition at line 185 of file mitkImage.cpp.
Referenced by mitk::ContourUtils::FillContourInSlice(), and mitk::SubImageSelector::GetSliceData().
{
if(IsValidSlice(s,t,n)==false) return NULL;
// slice directly available?
int pos=GetSliceIndex(s,t,n);
if(m_Slices[pos].GetPointer()!=NULL)
return m_Slices[pos];
// is slice available as part of a volume that is available?
ImageDataItemPointer sl, ch, vol;
vol=m_Volumes[GetVolumeIndex(t,n)];
if((vol.GetPointer()!=NULL) && (vol->IsComplete()))
{
sl=new ImageDataItem(*vol, 2, data, importMemoryManagement == ManageMemory, ((size_t) s)*m_OffsetTable[2]*(m_PixelType.GetBpe()/8));
sl->SetComplete(true);
return m_Slices[pos]=sl;
}
// is slice available as part of a channel that is available?
ch=m_Channels[n];
if((ch.GetPointer()!=NULL) && (ch->IsComplete()))
{
sl=new ImageDataItem(*ch, 2, data, importMemoryManagement == ManageMemory, (((size_t) s)*m_OffsetTable[2]+((size_t) t)*m_OffsetTable[3])*(m_PixelType.GetBpe()/8));
sl->SetComplete(true);
return m_Slices[pos]=sl;
}
// slice is unavailable. Can we calculate it?
if((GetSource()!=NULL) && (GetSource()->Updating()==false))
{
// ... wir mussen rechnen!!! ....
m_RequestedRegion.SetIndex(0, 0);
m_RequestedRegion.SetIndex(1, 0);
m_RequestedRegion.SetIndex(2, s);
m_RequestedRegion.SetIndex(3, t);
m_RequestedRegion.SetIndex(4, n);
m_RequestedRegion.SetSize(0, m_Dimensions[0]);
m_RequestedRegion.SetSize(1, m_Dimensions[1]);
m_RequestedRegion.SetSize(2, 1);
m_RequestedRegion.SetSize(3, 1);
m_RequestedRegion.SetSize(4, 1);
m_RequestedRegionInitialized=true;
GetSource()->Update();
if(IsSliceSet(s,t,n))
//yes: now we can call ourselves without the risk of a endless loop (see "if" above)
return GetSliceData(s,t,n,data,importMemoryManagement);
else
return NULL;
}
else
{
ImageDataItemPointer item = AllocateSliceData(s,t,n,data,importMemoryManagement);
item->SetComplete(true);
return item;
}
}
| int mitk::Image::GetSliceIndex | ( | int | s = 0, |
| int | t = 0, |
||
| int | n = 0 |
||
| ) | const [protected] |
Definition at line 1061 of file mitkImage.cpp.
{
if(IsValidSlice(s,t,n)==false) return false;
return ((size_t)s)+((size_t) t)*m_Dimensions[2]+((size_t) n)*m_Dimensions[3]*m_Dimensions[2]; //??
}
| mitk::ImageTimeSelector * mitk::Image::GetTimeSelector | ( | ) | const [protected] |
Definition at line 696 of file mitkImage.cpp.
References mitk::ImageTimeSelector::New(), and mitk::ImageToImageFilter::SetInput().
{
if(m_TimeSelectorForExtremaObject.IsNull())
{
m_TimeSelectorForExtremaObject = ImageTimeSelector::New();
ImageTimeSelector* timeSelector = static_cast<mitk::ImageTimeSelector*>( m_TimeSelectorForExtremaObject.GetPointer() );
timeSelector->SetInput(this);
this->UnRegister();
}
return static_cast<ImageTimeSelector*>( m_TimeSelectorForExtremaObject.GetPointer() );
}
| mitk::Image::ImageDataItemPointer mitk::Image::GetVolumeData | ( | int | t = 0, |
| int | n = 0, |
||
| void * | data = NULL, |
||
| ImportMemoryManagementType | importMemoryManagement = CopyMemory |
||
| ) | [virtual] |
Definition at line 243 of file mitkImage.cpp.
References mitkIpPicDescriptor, and mitk::ImageDataItem::SetComplete().
Referenced by mitk::SubImageSelector::GetVolumeData(), mitk::CompressedImageContainer::SetImage(), and mitkCompressedImageContainerTestClass::Test().
{
if(IsValidVolume(t,n)==false) return NULL;
ImageDataItemPointer ch, vol;
// volume directly available?
int pos=GetVolumeIndex(t,n);
vol=m_Volumes[pos];
if((vol.GetPointer()!=NULL) && (vol->IsComplete()))
return vol;
// is volume available as part of a channel that is available?
ch=m_Channels[n];
if((ch.GetPointer()!=NULL) && (ch->IsComplete()))
{
vol=new ImageDataItem(*ch, 3, data, importMemoryManagement == ManageMemory, (((size_t) t)*m_OffsetTable[3])*(m_PixelType.GetBpe()/8));
vol->SetComplete(true);
return m_Volumes[pos]=vol;
}
// let's see if all slices of the volume are set, so that we can (could) combine them to a volume
bool complete=true;
unsigned int s;
for(s=0;s<m_Dimensions[2];++s)
{
if(m_Slices[GetSliceIndex(s,t,n)].GetPointer()==NULL)
{
complete=false;
break;
}
}
if(complete)
{
// if there is only single slice we do not need to combine anything
if(m_Dimensions[2]<=1)
{
ImageDataItemPointer sl;
sl=GetSliceData(0,t,n,data,importMemoryManagement);
vol=new ImageDataItem(*sl, 3, data, importMemoryManagement == ManageMemory);
vol->SetComplete(true);
}
else
{
vol=m_Volumes[pos];
// ok, let's combine the slices!
if(vol.GetPointer()==NULL)
vol=new ImageDataItem(m_PixelType, 3, m_Dimensions, NULL, true);
vol->SetComplete(true);
size_t size=m_OffsetTable[2]*(m_PixelType.GetBpe()/8);
for(s=0;s<m_Dimensions[2];++s)
{
int posSl;
ImageDataItemPointer sl;
posSl=GetSliceIndex(s,t,n);
sl=m_Slices[posSl];
if(sl->GetParent()!=vol)
{
// copy data of slices in volume
size_t offset = ((size_t) s)*size;
std::memcpy(static_cast<char*>(vol->GetData())+offset, sl->GetData(), size);
mitkIpPicDescriptor * pic = sl->GetPicDescriptor();
// replace old slice with reference to volume
sl=new ImageDataItem(*vol, 2, data, importMemoryManagement == ManageMemory, ((size_t) s)*size);
sl->SetComplete(true);
mitkIpFuncCopyTags(sl->GetPicDescriptor(), pic);
m_Slices[posSl]=sl;
}
}
if(vol->GetPicDescriptor()->info->tags_head==NULL)
mitkIpFuncCopyTags(vol->GetPicDescriptor(), m_Slices[GetSliceIndex(0,t,n)]->GetPicDescriptor());
}
return m_Volumes[pos]=vol;
}
// volume is unavailable. Can we calculate it?
if((GetSource()!=NULL) && (GetSource()->Updating()==false))
{
// ... wir muessen rechnen!!! ....
m_RequestedRegion.SetIndex(0, 0);
m_RequestedRegion.SetIndex(1, 0);
m_RequestedRegion.SetIndex(2, 0);
m_RequestedRegion.SetIndex(3, t);
m_RequestedRegion.SetIndex(4, n);
m_RequestedRegion.SetSize(0, m_Dimensions[0]);
m_RequestedRegion.SetSize(1, m_Dimensions[1]);
m_RequestedRegion.SetSize(2, m_Dimensions[2]);
m_RequestedRegion.SetSize(3, 1);
m_RequestedRegion.SetSize(4, 1);
m_RequestedRegionInitialized=true;
GetSource()->Update();
if(IsVolumeSet(t,n))
//yes: now we can call ourselves without the risk of a endless loop (see "if" above)
return GetVolumeData(t,n,data,importMemoryManagement);
else
return NULL;
}
else
{
ImageDataItemPointer item = AllocateVolumeData(t,n,data,importMemoryManagement);
item->SetComplete(true);
return item;
}
}
| int mitk::Image::GetVolumeIndex | ( | int | t = 0, |
| int | n = 0 |
||
| ) | const [protected] |
Definition at line 1067 of file mitkImage.cpp.
{
if(IsValidVolume(t,n)==false) return false;
return ((size_t)t)+((size_t) n)*m_Dimensions[3]; //??
}
| vtkImageData * mitk::Image::GetVtkImageData | ( | int | t = 0, |
| int | n = 0 |
||
| ) | [virtual] |
Get a volume at a specific time t of channel n as a vtkImageData.
Reimplemented in mitk::QBallImage, and mitk::TensorImage.
Definition at line 147 of file mitkImage.cpp.
Referenced by mitk::VolumeDataVtkMapper3D::GenerateData(), mitk::ProbeFilter::GenerateData(), mitk::ManualSegmentationToSurfaceFilter::GenerateData(), mitk::LabeledImageToSurfaceFilter::GenerateData(), mitk::ImageToSurfaceFilter::GenerateData(), mitk::ImageMapperGL2D::GenerateData(), mitk::GPUVolumeMapper3D::GenerateData(), mitk::ExtractDirectedPlaneImageFilter::GenerateData(), mitk::GPUVolumeMapper3D::IsRenderable(), mitk::VolumeDataVtkMapper3D::SetClippingPlane(), and mitk::VolumeDataVtkMapper3D::SetMask().
{
if(m_Initialized==false)
{
if(GetSource()==NULL)
return NULL;
if(GetSource()->Updating()==false)
GetSource()->UpdateOutputInformation();
}
ImageDataItemPointer volume=GetVolumeData(t, n);
if(volume.GetPointer()==NULL || volume->GetVtkImageData() == NULL)
return NULL;
#if ((VTK_MAJOR_VERSION > 4) || ((VTK_MAJOR_VERSION==4) && (VTK_MINOR_VERSION>=4) ))
float *fspacing = const_cast<float *>(GetSlicedGeometry(t)->GetFloatSpacing());
double dspacing[3] = {fspacing[0],fspacing[1],fspacing[2]};
volume->GetVtkImageData()->SetSpacing( dspacing );
#else
volume->GetVtkImageData()->SetSpacing(const_cast<float*>(GetSlicedGeometry(t)->GetFloatSpacing()));
#endif
return volume->GetVtkImageData();
}
| void mitk::Image::Initialize | ( | const mitk::PixelType & | type, |
| int | sDim, | ||
| const mitk::Geometry2D & | geometry2d, | ||
| bool | flipped = false, |
||
| unsigned int | channels = 1, |
||
| int | tDim = -1 |
||
| ) | [virtual] |
initialize new (or re-initialize) image information by a Geometry2D and number of slices
Initializes the bounding box according to the width/height of the Geometry2D and sDim via SlicedGeometry3D::InitializeEvenlySpaced. The spacing is calculated from the Geometry2D.
| tDim | override time dimension (n[3]) if geometry is a TimeSlicedGeometry (if >0) |
Definition at line 837 of file mitkImage.cpp.
References mitk::Geometry2D::Clone(), and mitk::SlicedGeometry3D::New().
{
SlicedGeometry3D::Pointer slicedGeometry = SlicedGeometry3D::New();
slicedGeometry->InitializeEvenlySpaced(static_cast<Geometry2D*>(geometry2d.Clone().GetPointer()), sDim, flipped);
Initialize(type, *slicedGeometry, channels, tDim);
}
| void mitk::Image::Initialize | ( | const mitk::PixelType & | type, |
| unsigned int | dimension, | ||
| unsigned int * | dimensions, | ||
| unsigned int | channels = 1 |
||
| ) | [virtual] |
initialize new (or re-initialize) image information
Definition at line 710 of file mitkImage.cpp.
References mitk::TimeSlicedGeometry::New(), mitk::SlicedGeometry3D::New(), and mitk::PlaneGeometry::New().
Referenced by mitk::PlaneCutFilter::GenerateData(), and mitk::BoundingObjectToSegmentationFilter::GenerateData().
{
Clear();
m_Dimension=dimension;
if(!dimensions)
itkExceptionMacro(<< "invalid zero dimension image");
unsigned int i;
for(i=0;i<dimension;++i)
{
if(dimensions[i]<1)
itkExceptionMacro(<< "invalid dimension[" << i << "]: " << dimensions[i]);
}
m_Dimensions=new unsigned int[m_Dimension>4?m_Dimension:4];
std::memcpy(m_Dimensions, dimensions, sizeof(unsigned int)*m_Dimension);
if(m_Dimension<4)
{
unsigned int *p;
for(i=0,p=m_Dimensions+m_Dimension;i<4-m_Dimension;++i, ++p)
*p=1;
}
for(i=0;i<4;++i)
{
m_LargestPossibleRegion.SetIndex(i, 0);
m_LargestPossibleRegion.SetSize (i, m_Dimensions[i]);
}
m_LargestPossibleRegion.SetIndex(i, 0);
m_LargestPossibleRegion.SetSize(i, channels);
if(m_LargestPossibleRegion.GetNumberOfPixels()==0)
{
delete [] m_Dimensions;
m_Dimensions = NULL;
return;
}
m_PixelType=type;
PlaneGeometry::Pointer planegeometry = PlaneGeometry::New();
planegeometry->InitializeStandardPlane(m_Dimensions[0], m_Dimensions[1]);
SlicedGeometry3D::Pointer slicedGeometry = SlicedGeometry3D::New();
slicedGeometry->InitializeEvenlySpaced(planegeometry, m_Dimensions[2]);
if(dimension>=4)
{
TimeBounds timebounds;
timebounds[0] = 0.0;
timebounds[1] = 1.0;
slicedGeometry->SetTimeBounds(timebounds);
}
TimeSlicedGeometry::Pointer timeSliceGeometry = TimeSlicedGeometry::New();
timeSliceGeometry->InitializeEvenlyTimed(slicedGeometry, m_Dimensions[3]);
SetGeometry(timeSliceGeometry);
ImageDataItemPointer dnull=NULL;
m_Channels.assign(GetNumberOfChannels(), dnull);
m_Volumes.assign(GetNumberOfChannels()*m_Dimensions[3], dnull);
m_Slices.assign(GetNumberOfChannels()*m_Dimensions[3]*m_Dimensions[2], dnull);
ComputeOffsetTable();
Initialize();
m_Initialized = true;
}
| void mitk::Image::Initialize | ( | const mitk::PixelType & | type, |
| const mitk::Geometry3D & | geometry, | ||
| unsigned int | channels = 1, |
||
| int | tDim = -1 |
||
| ) | [virtual] |
initialize new (or re-initialize) image information by a Geometry3D
| tDim | override time dimension (n[3]) if geometry is a TimeSlicedGeometry (if >0) |
Definition at line 786 of file mitkImage.cpp.
References mitk::Geometry3D::Clone(), mitk::Geometry3D::GetBoundingBox(), mitk::Geometry3D::GetExtent(), mitk::Geometry3D::GetIndexToWorldTransform(), mitk::TimeSlicedGeometry::GetTimeSteps(), mitk::Geometry3D::IndexToWorld(), int(), and mitk::Geometry3D::SetBounds().
{
unsigned int dimensions[5];
dimensions[0] = (unsigned int)(geometry.GetExtent(0)+0.5);
dimensions[1] = (unsigned int)(geometry.GetExtent(1)+0.5);
dimensions[2] = (unsigned int)(geometry.GetExtent(2)+0.5);
dimensions[3] = 0;
dimensions[4] = 0;
unsigned int dimension = 2;
if ( dimensions[2] > 1 )
dimension = 3;
if ( tDim > 0)
{
dimensions[3] = tDim;
}
else
{
const mitk::TimeSlicedGeometry* timeGeometry = dynamic_cast<const mitk::TimeSlicedGeometry*>(&geometry);
if ( timeGeometry != NULL )
{
dimensions[3] = timeGeometry->GetTimeSteps();
}
}
if ( dimensions[3] > 1 )
dimension = 4;
Initialize( type, dimension, dimensions, channels );
SetGeometry(static_cast<Geometry3D*>(geometry.Clone().GetPointer()));
mitk::BoundingBox::BoundsArrayType bounds = geometry.GetBoundingBox()->GetBounds();
if( (bounds[0] != 0.0) || (bounds[2] != 0.0) || (bounds[4] != 0.0) )
{
SlicedGeometry3D* slicedGeometry = GetSlicedGeometry(0);
mitk::Point3D origin; origin.Fill(0.0);
slicedGeometry->IndexToWorld(origin, origin);
bounds[1]-=bounds[0]; bounds[3]-=bounds[2]; bounds[5]-=bounds[4];
bounds[0] = 0.0; bounds[2] = 0.0; bounds[4] = 0.0;
slicedGeometry->SetBounds(bounds);
slicedGeometry->GetIndexToWorldTransform()->SetOffset(origin.Get_vnl_vector().data_block());
GetTimeSlicedGeometry()->InitializeEvenlyTimed(slicedGeometry, m_Dimensions[3]);
}
}
| void mitk::Image::Initialize | ( | const mitk::Image * | image ) | [virtual] |
initialize new (or re-initialize) image information by another mitk-image. Only the header is used, not the data vector!
Definition at line 844 of file mitkImage.cpp.
References GetPixelType(), mitk::BaseData::GetTimeSlicedGeometry(), and mitk::PixelType::GetTypeId().
{
Initialize(*image->GetPixelType().GetTypeId(), *image->GetTimeSlicedGeometry());
}
| void mitk::Image::Initialize | ( | const mitkIpPicDescriptor * | pic, |
| int | channels = 1, |
||
| int | tDim = -1, |
||
| int | sDim = -1 |
||
| ) | [virtual] |
initialize new (or re-initialize) image information by pic. Dimensions and Geometry3D /Geometry2D are set according to the tags in pic. Only the header is used, not the data vector! Use SetPicVolume(pic) to set the data vector.
| tDim | override time dimension (n[3]) in pic (if >0) |
| sDim | override z-space dimension (n[2]) in pic (if >0) |
Definition at line 955 of file mitkImage.cpp.
References mitk::PicHelper::InitializeEvenlySpaced(), mitk::TimeSlicedGeometry::New(), and mitk::SlicedGeometry3D::New().
{
if(pic==NULL) return;
Clear();
m_Dimension=pic->dim;
m_Dimensions=new unsigned int[m_Dimension>4?m_Dimension:4];
std::memcpy(m_Dimensions, pic->n, sizeof(unsigned int)*m_Dimension);
if(m_Dimension<4)
{
unsigned int i, *p;
for(i=0,p=m_Dimensions+m_Dimension;i<4-m_Dimension;++i, ++p)
*p=1;
}
if(sDim>=0)
{
m_Dimensions[2]=sDim;
if(m_Dimension < 3)
m_Dimension = 3;
}
if(tDim>=0)
{
m_Dimensions[3]=tDim;
if(m_Dimension < 4)
m_Dimension = 4;
}
unsigned int i;
for(i=0;i<4;++i)
{
m_LargestPossibleRegion.SetIndex(i, 0);
m_LargestPossibleRegion.SetSize (i, m_Dimensions[i]);
}
m_LargestPossibleRegion.SetIndex(i, 0);
m_LargestPossibleRegion.SetSize(i, channels);
m_PixelType=PixelType(pic);
SlicedGeometry3D::Pointer slicedGeometry = SlicedGeometry3D::New();
PicHelper::InitializeEvenlySpaced(pic, m_Dimensions[2], slicedGeometry);
TimeSlicedGeometry::Pointer timeSliceGeometry = TimeSlicedGeometry::New();
timeSliceGeometry->InitializeEvenlyTimed(slicedGeometry, m_Dimensions[3]);
SetGeometry(timeSliceGeometry);
ImageDataItemPointer dnull=NULL;
m_Channels.assign(GetNumberOfChannels(), dnull);
m_Volumes.assign(GetNumberOfChannels()*m_Dimensions[3], dnull);
m_Slices.assign(GetNumberOfChannels()*m_Dimensions[3]*m_Dimensions[2], dnull);
ComputeOffsetTable();
Initialize();
m_Initialized = true;
}
| void mitk::Image::Initialize | ( | vtkImageData * | vtkimagedata, |
| int | channels = 1, |
||
| int | tDim = -1, |
||
| int | sDim = -1 |
||
| ) | [virtual] |
initialize new (or re-initialize) image information by vtkimagedata, a vtk-image. Only the header is used, not the data vector! Use SetVolume(vtkimage->GetScalarPointer()) to set the data vector.
| tDim | override time dimension in vtkimagedata (if >0 and <) |
| sDim | override z-space dimension in vtkimagedata (if >0 and <) |
Definition at line 849 of file mitkImage.cpp.
References mitk::SlicedGeometry3D::GetGeometry2D(), mitk::PixelType::Initialize(), mitk::Geometry3D::SetOrigin(), and mitk::SlicedGeometry3D::SetSpacing().
{
if(vtkimagedata==NULL) return;
m_Dimension=vtkimagedata->GetDataDimension();
unsigned int i, *tmpDimensions=new unsigned int[m_Dimension>4?m_Dimension:4];
for(i=0;i<m_Dimension;++i) tmpDimensions[i]=vtkimagedata->GetDimensions()[i];
if(m_Dimension<4)
{
unsigned int *p;
for(i=0,p=tmpDimensions+m_Dimension;i<4-m_Dimension;++i, ++p)
*p=1;
}
if(sDim>=0)
{
tmpDimensions[2]=sDim;
if(m_Dimension < 3)
m_Dimension = 3;
}
if(tDim>=0)
{
tmpDimensions[3]=tDim;
if(m_Dimension < 4)
m_Dimension = 4;
}
mitk::PixelType pixelType;
switch ( vtkimagedata->GetScalarType() )
{
case VTK_BIT:
case VTK_CHAR:
pixelType.Initialize(typeid(char), vtkimagedata->GetNumberOfScalarComponents());
break;
case VTK_UNSIGNED_CHAR:
pixelType.Initialize(typeid(unsigned char), vtkimagedata->GetNumberOfScalarComponents());
break;
case VTK_SHORT:
pixelType.Initialize(typeid(short), vtkimagedata->GetNumberOfScalarComponents());
break;
case VTK_UNSIGNED_SHORT:
pixelType.Initialize(typeid(unsigned short), vtkimagedata->GetNumberOfScalarComponents());
break;
case VTK_INT:
pixelType.Initialize(typeid(int), vtkimagedata->GetNumberOfScalarComponents());
break;
case VTK_UNSIGNED_INT:
pixelType.Initialize(typeid(unsigned int), vtkimagedata->GetNumberOfScalarComponents());
break;
case VTK_LONG:
pixelType.Initialize(typeid(long), vtkimagedata->GetNumberOfScalarComponents());
break;
case VTK_UNSIGNED_LONG:
pixelType.Initialize(typeid(unsigned long), vtkimagedata->GetNumberOfScalarComponents());
break;
case VTK_FLOAT:
pixelType.Initialize(typeid(float), vtkimagedata->GetNumberOfScalarComponents());
break;
case VTK_DOUBLE:
pixelType.Initialize(typeid(double), vtkimagedata->GetNumberOfScalarComponents());
break;
default:
break;
}
Initialize(pixelType,
m_Dimension,
tmpDimensions,
channels);
#if ((VTK_MAJOR_VERSION > 4) || ((VTK_MAJOR_VERSION==4) && (VTK_MINOR_VERSION>=4) ))
const double *spacinglist = vtkimagedata->GetSpacing();
#else
const float *spacinglist = vtkimagedata->GetSpacing();
#endif
Vector3D spacing;
FillVector3D(spacing, spacinglist[0], 1.0, 1.0);
if(m_Dimension>=2)
spacing[1]=spacinglist[1];
if(m_Dimension>=3)
spacing[2]=spacinglist[2];
// access origin of vtkImage
Point3D origin;
vtkFloatingPointType vtkorigin[3];
vtkimagedata->GetOrigin(vtkorigin);
FillVector3D(origin, vtkorigin[0], 0.0, 0.0);
if(m_Dimension>=2)
origin[1]=vtkorigin[1];
if(m_Dimension>=3)
origin[2]=vtkorigin[2];
SlicedGeometry3D* slicedGeometry = GetSlicedGeometry(0);
// re-initialize PlaneGeometry with origin and direction
PlaneGeometry* planeGeometry = static_cast<PlaneGeometry*>(slicedGeometry->GetGeometry2D(0));
planeGeometry->SetOrigin(origin);
// re-initialize SlicedGeometry3D
slicedGeometry->SetOrigin(origin);
slicedGeometry->SetSpacing(spacing);
GetTimeSlicedGeometry()->InitializeEvenlyTimed(slicedGeometry, m_Dimensions[3]);
delete [] tmpDimensions;
}
| void mitk::Image::Initialize | ( | ) | [protected, virtual] |
Reimplemented in mitk::SeedsImage.
Definition at line 674 of file mitkImage.cpp.
{
ImageDataItemPointerArray::iterator it, end;
for( it=m_Slices.begin(), end=m_Slices.end(); it!=end; ++it )
{
(*it)=NULL;
}
for( it=m_Volumes.begin(), end=m_Volumes.end(); it!=end; ++it )
{
(*it)=NULL;
}
for( it=m_Channels.begin(), end=m_Channels.end(); it!=end; ++it )
{
(*it)=NULL;
}
m_CompleteData = NULL;
this->GetTimeSelector(); // just to create m_TimeSelectorForExtremaObject
SetRequestedRegionToLargestPossibleRegion();
}
| void mitk::Image::InitializeByItk | ( | const itkImageType * | itkimage, |
| int | channels = 1, |
||
| int | tDim = -1, |
||
| int | sDim = -1 |
||
| ) | [inline] |
initialize new (or re-initialize) image information by itkimage, a templated itk-image. Only the header is used, not the data vector! Use SetVolume(itkimage->GetBufferPointer()) to set the data vector.
| tDim | override time dimension in itkimage (if >0 and <) |
| sDim | override z-space dimension in itkimage (if >0 and <) |
Definition at line 306 of file mitkImage.h.
References mitk::Geometry3D::GetIndexToWorldTransform(), mitk::SlicedGeometry3D::InitializeEvenlySpaced(), matrix(), MITK_DEBUG, MITK_ERROR, MITK_WARN, mitk::Geometry3D::SetOrigin(), and mitk::SlicedGeometry3D::SetSpacing().
{
if(itkimage==NULL) return;
MITK_DEBUG << "Initializing MITK image from ITK image.";
// build array with dimensions in each direction with at least 4 entries
m_Dimension=itkimage->GetImageDimension();
unsigned int i, *tmpDimensions=new unsigned int[m_Dimension>4?m_Dimension:4];
for(i=0;i<m_Dimension;++i)
tmpDimensions[i]=itkimage->GetLargestPossibleRegion().GetSize().GetSize()[i];
if(m_Dimension<4)
{
unsigned int *p;
for(i=0,p=tmpDimensions+m_Dimension;i<4-m_Dimension;++i, ++p)
*p=1;
}
// overwrite number of slices if sDim is set
if((m_Dimension>2) && (sDim>=0))
tmpDimensions[2]=sDim;
// overwrite number of time points if tDim is set
if((m_Dimension>3) && (tDim>=0))
tmpDimensions[3]=tDim;
// rough initialization of Image
Initialize(mitk::PixelType(typeid(typename itkImageType::PixelType)),
m_Dimension,
tmpDimensions,
channels);
const typename itkImageType::SpacingType & itkspacing = itkimage->GetSpacing();
MITK_DEBUG << "ITK spacing " << itkspacing;
// access spacing of itk::Image
Vector3D spacing;
FillVector3D(spacing, itkspacing[0], 1.0, 1.0);
if(m_Dimension >= 2)
spacing[1]=itkspacing[1];
if(m_Dimension >= 3)
spacing[2]=itkspacing[2];
// access origin of itk::Image
Point3D origin;
const typename itkImageType::PointType & itkorigin = itkimage->GetOrigin();
MITK_DEBUG << "ITK origin " << itkorigin;
FillVector3D(origin, itkorigin[0], 0.0, 0.0);
if(m_Dimension>=2)
origin[1]=itkorigin[1];
if(m_Dimension>=3)
origin[2]=itkorigin[2];
// access direction of itk::Image and include spacing
const typename itkImageType::DirectionType & itkdirection = itkimage->GetDirection();
MITK_DEBUG << "ITK direction " << itkdirection;
mitk::Matrix3D matrix;
matrix.SetIdentity();
unsigned int j, itkDimMax3 = (m_Dimension >= 3? 3 : m_Dimension);
// check if spacing has no zero entry and itkdirection has no zero columns
bool itkdirectionOk = true;
mitk::ScalarType columnSum;
for( j=0; j < itkDimMax3; ++j )
{
columnSum = 0.0;
for ( i=0; i < itkDimMax3; ++i)
{
columnSum += fabs(itkdirection[i][j]);
}
if(columnSum < mitk::eps)
{
itkdirectionOk = false;
}
if ( (spacing[j] < - mitk::eps) // (normally sized) negative value
&& (j==2) && (m_Dimensions[2] == 1) )
{
// Negative spacings can occur when reading single DICOM slices with ITK via GDCMIO
// In these cases spacing is not determind by ITK correctly (because it distinguishes correctly
// between slice thickness and inter slice distance -- slice distance is meaningless for
// single slices).
// I experienced that ITK produced something meaningful nonetheless because is is
// evaluating the tag "(0018,0088) Spacing between slices" as a fallback. This tag is not
// reliable (http://www.itk.org/pipermail/insight-users/2005-September/014711.html)
// but gives at least a hint.
// In real world cases I experienced that this tag contained the correct inter slice distance
// with a negative sign, so we just invert such negative spacings.
MITK_WARN << "Illegal value of itk::Image::GetSpacing()[" << j <<"]=" << spacing[j] << ". Using inverted value " << -spacing[j];
spacing[j] = -spacing[j];
}
else if (spacing[j] < mitk::eps) // value near zero
{
MITK_ERROR << "Illegal value of itk::Image::GetSpacing()[" << j <<"]=" << spacing[j] << ". Using 1.0 instead.";
spacing[j] = 1.0;
}
}
if(itkdirectionOk == false)
{
MITK_ERROR << "Illegal matrix returned by itk::Image::GetDirection():" << itkdirection << " Using identity instead.";
for ( i=0; i < itkDimMax3; ++i)
for( j=0; j < itkDimMax3; ++j )
if ( i == j )
matrix[i][j] = spacing[j];
else
matrix[i][j] = 0.0;
}
else
{
for ( i=0; i < itkDimMax3; ++i)
for( j=0; j < itkDimMax3; ++j )
matrix[i][j] = itkdirection[i][j]*spacing[j];
}
// re-initialize PlaneGeometry with origin and direction
PlaneGeometry* planeGeometry = static_cast<PlaneGeometry*>(GetSlicedGeometry(0)->GetGeometry2D(0));
planeGeometry->SetOrigin(origin);
planeGeometry->GetIndexToWorldTransform()->SetMatrix(matrix);
// re-initialize SlicedGeometry3D
SlicedGeometry3D* slicedGeometry = GetSlicedGeometry(0);
slicedGeometry->InitializeEvenlySpaced(planeGeometry, m_Dimensions[2]);
slicedGeometry->SetSpacing(spacing);
// re-initialize TimeSlicedGeometry
GetTimeSlicedGeometry()->InitializeEvenlyTimed(slicedGeometry, m_Dimensions[3]);
// clean-up
delete [] tmpDimensions;
this->Initialize();
};
| bool mitk::Image::IsChannelSet | ( | int | n = 0 ) |
const [virtual] |
Check whether the channel n is set.
Implements mitk::SlicedData.
Definition at line 488 of file mitkImage.cpp.
References QuadProgPP::t().
{
if(IsValidChannel(n)==false) return false;
ImageDataItemPointer ch, vol;
ch=m_Channels[n];
if((ch.GetPointer()!=NULL) && (ch->IsComplete()))
return true;
// let's see if all volumes are set, so that we can (could) combine them to a channel
unsigned int t;
for(t=0;t<m_Dimensions[3];++t)
if(IsVolumeSet(t,n)==false)
return false;
return true;
}
| bool mitk::Image::IsRotated | ( | ) | const |
Returns true if an image is rotated, i.e. its geometry's transformation matrix has nonzero elements besides the diagonal. Non-diagonal elements are checked if larger then 1/1000 of the matrix' trace.
Definition at line 1401 of file mitkImage.cpp.
References QuadProgPP::abs(), and mitk::Geometry3D::GetIndexToWorldTransform().
{
const mitk::Geometry3D* geo = this->GetGeometry();
bool ret = false;
if(geo)
{
const vnl_matrix_fixed<float, 3, 3> & mx = geo->GetIndexToWorldTransform()->GetMatrix().GetVnlMatrix();
float ref = 0;
for(short k = 0; k < 3; ++k)
ref += mx[k][k];
ref/=1000; // Arbitrary value; if a non-diagonal (nd) element is bigger then this, matrix is considered nd.
for(short i = 0; i < 3; ++i)
{
for(short j = 0; j < 3; ++j)
{
if(i != j)
{
if(abs(mx[i][j]) > ref) // matrix is nd
ret = true;
}
}
}
}
return ret;
}
| bool mitk::Image::IsSliceSet | ( | int | s = 0, |
| int | t = 0, |
||
| int | n = 0 |
||
| ) | const [virtual] |
Check whether slice s at time t in channel n is set.
Implements mitk::SlicedData.
Definition at line 448 of file mitkImage.cpp.
{
if(IsValidSlice(s,t,n)==false) return false;
if(m_Slices[GetSliceIndex(s,t,n)].GetPointer()!=NULL)
return true;
ImageDataItemPointer ch, vol;
vol=m_Volumes[GetVolumeIndex(t,n)];
if((vol.GetPointer()!=NULL) && (vol->IsComplete()))
return true;
ch=m_Channels[n];
if((ch.GetPointer()!=NULL) && (ch->IsComplete()))
return true;
return false;
}
| bool mitk::Image::IsValidChannel | ( | int | n = 0 ) |
const [virtual] |
Check whether the channel n is valid, i.e., is (or can be) inside of the image.
Definition at line 1034 of file mitkImage.cpp.
{
if(m_Initialized)
return IsValidSlice(0, 0, n);
else
return false;
}
| bool mitk::Image::IsValidSlice | ( | int | s = 0, |
| int | t = 0, |
||
| int | n = 0 |
||
| ) | const [virtual] |
Check whether slice s at time t in channel n is valid, i.e., is (or can be) inside of the image.
Definition at line 1018 of file mitkImage.cpp.
{
if(m_Initialized)
return ((s>=0) && (s<(int)m_Dimensions[2]) && (t>=0) && (t< (int) m_Dimensions[3]) && (n>=0) && (n< (int)GetNumberOfChannels()));
else
return false;
}
| bool mitk::Image::IsValidTimeStep | ( | int | t ) | const [protected, virtual] |
Definition at line 1275 of file mitkImage.cpp.
{
return ( ( m_Dimension >= 4 && t <= (int)m_Dimensions[3] && t > 0 ) || (t == 0) );
}
| bool mitk::Image::IsValidVolume | ( | int | t = 0, |
| int | n = 0 |
||
| ) | const [virtual] |
Check whether volume at time t in channel n is valid, i.e., is (or can be) inside of the image.
Definition at line 1026 of file mitkImage.cpp.
{
if(m_Initialized)
return IsValidSlice(0, t, n);
else
return false;
}
| bool mitk::Image::IsVolumeSet | ( | int | t = 0, |
| int | n = 0 |
||
| ) | const [virtual] |
Check whether volume at time t in channel n is set.
Implements mitk::SlicedData.
Definition at line 465 of file mitkImage.cpp.
Referenced by mitk::ImageMapperGL2D::GenerateData(), and mitk::ExtractDirectedPlaneImageFilter::GenerateData().
{
if(IsValidVolume(t,n)==false) return false;
ImageDataItemPointer ch, vol;
// volume directly available?
vol=m_Volumes[GetVolumeIndex(t,n)];
if((vol.GetPointer()!=NULL) && (vol->IsComplete()))
return true;
// is volume available as part of a channel that is available?
ch=m_Channels[n];
if((ch.GetPointer()!=NULL) && (ch->IsComplete()))
return true;
// let's see if all slices of the volume are set, so that we can (could) combine them to a volume
unsigned int s;
for(s=0;s<m_Dimensions[2];++s)
if(m_Slices[GetSliceIndex(s,t,n)].GetPointer()==NULL)
return false;
return true;
}
| static Pointer mitk::Image::New | ( | ) | [static] |
Reimplemented in mitk::DiffusionImage< TPixelType >, mitk::QBallImage, mitk::TensorImage, mitk::SeedsImage, and mitk::DiffusionImage< DiffusionImagePixelType >.
Referenced by QmitkSlicesInterpolator::AcceptAllInterpolations(), QmitkImageCropper::AddSurrounding(), QmitkDeformableRegistrationView::ApplyDeformationField(), mitk::OpeningTool::ApplyFilter(), mitk::ErodeTool::ApplyFilter(), mitk::DilateTool::ApplyFilter(), mitk::ClosingTool::ApplyFilter(), QmitkPointBasedRegistrationView::calculateLandmarkWarping(), mitk::CastToMitkImage(), mitk::TensorImage::ConstructRgbImage(), mitk::QBallImage::ConstructRgbImage(), mitk::Tool::CreateEmptySegmentationNode(), mitkSegmentationInterpolationTestClass::CreateSegmentation(), CreateTestImage(), QmitkThresholdComponent::CreateThresholdSegmentation(), QmitkDiffusionTensorEstimation::DirectionVolumesAngularErrorButton(), QmitkDiffusionTensorEstimation::DirectionVolumesLoadButton(), QmitkPreprocessingView::DoBrainMask(), QmitkPreprocessingView::DoExtractB0(), mitk::ContourUtils::FillContourInSlice(), mitk::OverwriteSliceImageFilter::GenerateData(), mitk::CorrectorAlgorithm::GenerateData(), mitk::CompressedImageContainer::GetImage(), mitk::VolumeDataVtkMapper3D::GetMask(), mitk::GrabItkImageMemory(), Image(), mitk::ImageRegistrationMethod::ImageRegistrationMethod(), QmitkSegmentationPostProcessing::IncreaseCroppedImageSize(), QmitkAutocropAction::IncreaseCroppedImageSize(), mitk::CorrectorAlgorithm::ItkCalculateDifferenceImage(), mitk::AutoCropImageFilter::ITKCrop3DImage(), mitk::DicomSeriesReader::LoadDicom(), mitkBoundingObjectCutterTest(), mitkDemonsRegistrationTest(), mitkHistogramMatchingTest(), mitkImageMapper2DTest(), mitkImageTest(), mitkImageToItkTest(), mitkLevelWindowTest(), mitkPipelineSmartPointerCorrectnessTest(), mitkPropertySerializationTest(), mitkRegistrationBaseTest(), mitkSurfaceToImageFilterTest(), mitkSymmetricForcesDemonsRegistrationTest(), QmitkQBallReconstructionView::NumericalQBallReconstruction(), mitk::SetRegionTool::OnMousePressed(), mitk::RegionGrowingTool::OnMousePressed(), mitk::MorphologicTool::OnRoiDataChanged(), mitk::BinaryThresholdULTool::OnRoiDataChanged(), mitk::BinaryThresholdTool::OnRoiDataChanged(), mitk::PyramidalRegistrationMethod::PyramidalRegistrationMethod(), QmitkDiffusionTensorEstimation::QBallReconstructionButton(), QmitkDiffusionTensorEstimation::QBallStandardAlgorithmsDeconvolutionButton(), QmitkDiffusionTensorEstimation::QBallStandardAlgorithmsDirectionButton(), QmitkDiffusionTensorEstimation::QBallStandardAlgorithmsGFAButton(), QmitkDiffusionTensorEstimation::QBallVolumesLoadButton(), QmitkDiffusionTensorEstimation::QBallVolumesVisualizeSelectedButton(), QmitkDiffusionQuantificationView::QBIQuantification(), mitk::DataNodeFactory::ReadFileSeriesTypeITKImageSeriesReader(), QmitkDiffusionTensorEstimation::ReconstructAnalytically(), RegionGrowing(), mitk::NonBlockingAlgorithm::SetItkImageAsMITKImagePointerParameter(), QmitkDiffusionTensorEstimation::StandardAlgorithmsDirectionButton(), QmitkDiffusionTensorEstimation::StandardAlgorithmsFAButton(), QmitkDiffusionTensorEstimation::StandardAlgorithmsRAButton(), QmitkQBallReconstructionView::TemplatedAnalyticalQBallReconstruction(), QmitkDiffusionTensorEstimation::TensorEstimationButton(), QmitkDiffusionQuantificationView::TensorQuantification(), QmitkDiffusionTensorEstimation::TensorVolumesLoadButton(), mitkOverwriteSliceImageFilterTestClass::Test3D(), testBackCasting(), mitkDataNodeTestClass::TestDataSetting(), mitk::RawImageFileReader::TypedGenerateData(), mitk::PaintbrushTool::UpdateContour(), and mitk::BinaryThresholdULTool::UpdatePreview().
| void mitk::Image::PrintSelf | ( | std::ostream & | os, |
| itk::Indent | indent | ||
| ) | const [protected, virtual] |
Reimplemented from mitk::BaseData.
Definition at line 1378 of file mitkImage.cpp.
{
unsigned char i;
if(m_Initialized)
{
os << indent << " PixelType: " << m_PixelType.GetTypeId()->name() << std::endl;
os << indent << " BitsPerElement: " << m_PixelType.GetBpe() << std::endl;
os << indent << " NumberOfComponents: " << m_PixelType.GetNumberOfComponents() << std::endl;
os << indent << " BitsPerComponent: " << m_PixelType.GetBitsPerComponent() << std::endl;
os << indent << " Dimension: " << m_Dimension << std::endl;
os << indent << " Dimensions: ";
for(i=0; i < m_Dimension; ++i)
os << GetDimension(i) << " ";
os << std::endl;
}
else
{
os << indent << " Image not initialized: m_Initialized: false" << std::endl;
}
Superclass::PrintSelf(os,indent);
}
| void mitk::Image::ResetImageStatistics | ( | ) | const [protected, virtual] |
Definition at line 1295 of file mitkImage.cpp.
References QuadProgPP::max().
{
m_ScalarMin.assign(1, itk::NumericTraits<ScalarType>::max());
m_ScalarMax.assign(1, itk::NumericTraits<ScalarType>::NonpositiveMin());
m_Scalar2ndMin.assign(1, itk::NumericTraits<ScalarType>::max());
m_Scalar2ndMax.assign(1, itk::NumericTraits<ScalarType>::NonpositiveMin());
m_CountOfMinValuedVoxels.assign(1, 0);
m_CountOfMaxValuedVoxels.assign(1, 0);
}
| bool mitk::Image::SetChannel | ( | const void * | data, |
| int | n = 0 |
||
| ) | [virtual] |
Set data in channel n. It is in the responsibility of the caller to ensure that the data vector data is really a channel (at least is not smaller than a channel), since there is no chance to check this.
The data is copied to an array managed by the image. If the image shall reference the data, use SetImportChannel with ImportMemoryManagementType set to ReferenceMemory. For importing ITK images use of mitk:: ITKImageImport is recommended.
Definition at line 516 of file mitkImage.cpp.
{
// const_cast is no risk for ImportMemoryManagementType == CopyMemory
return SetImportChannel(const_cast<void*>(data), n, CopyMemory);
}
| void mitk::Image::SetGeometry | ( | Geometry3D * | aGeometry3D ) | [virtual] |
Set the Geometry3D of the data, which will be referenced (not copied!). It has to be a sub-class of SlicedGeometry3D.
Reimplemented from mitk::SlicedData.
Definition at line 1169 of file mitkImage.cpp.
{
Superclass::SetGeometry(aGeometry3D);
GetTimeSlicedGeometry()->ImageGeometryOn();
}
| bool mitk::Image::SetImportChannel | ( | void * | data, |
| int | n = 0, |
||
| ImportMemoryManagementType | importMemoryManagement = CopyMemory |
||
| ) | [virtual] |
Set data in channel n. It is in the responsibility of the caller to ensure that the data vector data is really a channel (at least is not smaller than a channel), since there is no chance to check this.
The data is managed according to the parameter importMemoryManagement.
Definition at line 586 of file mitkImage.cpp.
{
if(IsValidChannel(n)==false) return false;
ImageDataItemPointer ch;
if(IsChannelSet(n))
{
ch=GetChannelData(n,data,importMemoryManagement);
if(ch->GetManageMemory()==false)
{
ch=AllocateChannelData(n,data,importMemoryManagement);
if(ch.GetPointer()==NULL) return false;
}
if ( ch->GetData() != data )
std::memcpy(ch->GetData(), data, m_OffsetTable[4]*(m_PixelType.GetBpe()/8));
ch->Modified();
ch->SetComplete(true);
//we have changed the data: call Modified()!
Modified();
}
else
{
ch=AllocateChannelData(n,data,importMemoryManagement);
if(ch.GetPointer()==NULL) return false;
if ( ch->GetData() != data )
std::memcpy(ch->GetData(), data, m_OffsetTable[4]*(m_PixelType.GetBpe()/8));
ch->SetComplete(true);
//we just added a missing Channel, which is not regarded as modification.
//Therefore, we do not call Modified()!
}
return true;
}
| bool mitk::Image::SetImportSlice | ( | void * | data, |
| int | s = 0, |
||
| int | t = 0, |
||
| int | n = 0, |
||
| ImportMemoryManagementType | importMemoryManagement = CopyMemory |
||
| ) | [virtual] |
Set data as slice s at time t in channel n. It is in the responsibility of the caller to ensure that the data vector data is really a slice (at least is not smaller than a slice), since there is no chance to check this.
The data is managed according to the parameter importMemoryManagement.
Definition at line 522 of file mitkImage.cpp.
{
if(IsValidSlice(s,t,n)==false) return false;
ImageDataItemPointer sl;
if(IsSliceSet(s,t,n))
{
sl=GetSliceData(s,t,n,data,importMemoryManagement);
if(sl->GetManageMemory()==false)
{
sl=AllocateSliceData(s,t,n,data,importMemoryManagement);
if(sl.GetPointer()==NULL) return false;
}
if ( sl->GetData() != data )
std::memcpy(sl->GetData(), data, m_OffsetTable[2]*(m_PixelType.GetBpe()/8));
sl->Modified();
//we have changed the data: call Modified()!
Modified();
}
else
{
sl=AllocateSliceData(s,t,n,data,importMemoryManagement);
if(sl.GetPointer()==NULL) return false;
if ( sl->GetData() != data )
std::memcpy(sl->GetData(), data, m_OffsetTable[2]*(m_PixelType.GetBpe()/8));
//we just added a missing slice, which is not regarded as modification.
//Therefore, we do not call Modified()!
}
return true;
}
| bool mitk::Image::SetImportVolume | ( | void * | data, |
| int | t = 0, |
||
| int | n = 0, |
||
| ImportMemoryManagementType | importMemoryManagement = CopyMemory |
||
| ) | [virtual] |
Set data as volume at time t in channel n. It is in the responsibility of the caller to ensure that the data vector data is really a volume (at least is not smaller than a volume), since there is no chance to check this.
The data is managed according to the parameter importMemoryManagement.
Definition at line 552 of file mitkImage.cpp.
Referenced by mitk::PlaneCutFilter::GenerateData().
{
if(IsValidVolume(t,n)==false) return false;
ImageDataItemPointer vol;
if(IsVolumeSet(t,n))
{
vol=GetVolumeData(t,n,data,importMemoryManagement);
if(vol->GetManageMemory()==false)
{
vol=AllocateVolumeData(t,n,data,importMemoryManagement);
if(vol.GetPointer()==NULL) return false;
}
if ( vol->GetData() != data )
std::memcpy(vol->GetData(), data, m_OffsetTable[3]*(m_PixelType.GetBpe()/8));
vol->Modified();
vol->SetComplete(true);
//we have changed the data: call Modified()!
Modified();
}
else
{
vol=AllocateVolumeData(t,n,data,importMemoryManagement);
if(vol.GetPointer()==NULL) return false;
if ( vol->GetData() != data )
{
std::memcpy(vol->GetData(), data, m_OffsetTable[3]*(m_PixelType.GetBpe()/8));
}
vol->SetComplete(true);
//we just added a missing Volume, which is not regarded as modification.
//Therefore, we do not call Modified()!
}
return true;
}
| bool mitk::Image::SetPicChannel | ( | const mitkIpPicDescriptor * | pic, |
| int | n = 0, |
||
| ImportMemoryManagementType | importMemoryManagement = CopyMemory |
||
| ) | [virtual] |
Set pic in channel n.
The data is copied to an array managed by the image.
Definition at line 651 of file mitkImage.cpp.
{
if(pic==NULL) return false;
if(pic->dim<=3) return SetPicVolume(pic, 0, n);
if(pic->dim!=m_Dimension) return false;
unsigned int i;
for(i=0;i<m_Dimension; ++i)
{
if(pic->n[i]!=m_Dimensions[i]) return false;
}
if(SetChannel(pic->data,n)) //@todo: add geometry!
{
ImageDataItemPointer ch;
ch=GetChannelData(n,NULL,CopyMemory);
// commented the next line, because
// it crashes when called from mitkDICOMFileReader for the Live3D data
// mitkIpFuncCopyTags(ch->GetPicDescriptor(), pic);
return true;
}
else
return false;
}
| bool mitk::Image::SetPicSlice | ( | const mitkIpPicDescriptor * | pic, |
| int | s = 0, |
||
| int | t = 0, |
||
| int | n = 0, |
||
| ImportMemoryManagementType | importMemoryManagement = CopyMemory |
||
| ) | [virtual] |
Set pic as slice s at time t in channel n.
The data is copied to an array managed by the image.
Definition at line 618 of file mitkImage.cpp.
References mitkIpPicDescriptor.
{
if(pic==NULL) return false;
if(pic->dim!=2) return false;
if((pic->n[0]!=m_Dimensions[0]) || (pic->n[1]!=m_Dimensions[1])) return false;
if(SetSlice(pic->data,s,t,n)) //@todo: add geometry!
{
ImageDataItemPointer sl;
sl=GetSliceData(s,t,n,NULL,CopyMemory);
mitkIpFuncCopyTags(sl->GetPicDescriptor(), const_cast<mitkIpPicDescriptor *>(pic));
return true;
}
else
return false;
}
| bool mitk::Image::SetPicVolume | ( | const mitkIpPicDescriptor * | pic, |
| int | t = 0, |
||
| int | n = 0, |
||
| ImportMemoryManagementType | importMemoryManagement = CopyMemory |
||
| ) | [virtual] |
Set pic as volume at time t in channel n.
The data is copied to an array managed by the image.
Definition at line 634 of file mitkImage.cpp.
References mitkIpPicDescriptor.
{
if(pic==NULL) return false;
if((pic->dim==2) && ((m_Dimension==2) || ((m_Dimension>2) && (m_Dimensions[2]==1)))) return SetPicSlice(pic, 0, t, n);
if(pic->dim!=3) return false;
if((pic->n[0]!=m_Dimensions[0]) || (pic->n[1]!=m_Dimensions[1]) || (pic->n[2]!=m_Dimensions[2])) return false;
if(SetVolume(pic->data,t,n)) //@todo: add geometry!
{
ImageDataItemPointer vol;
vol=GetVolumeData(t,n,NULL,CopyMemory);
mitkIpFuncCopyTags(vol->GetPicDescriptor(), const_cast<mitkIpPicDescriptor *>(pic));
return true;
}
else
return false;
}
| bool mitk::Image::SetSlice | ( | const void * | data, |
| int | s = 0, |
||
| int | t = 0, |
||
| int | n = 0 |
||
| ) | [virtual] |
Set data as slice s at time t in channel n. It is in the responsibility of the caller to ensure that the data vector data is really a slice (at least is not smaller than a slice), since there is no chance to check this.
The data is copied to an array managed by the image. If the image shall reference the data, use SetImportSlice with ImportMemoryManagementType set to ReferenceMemory. For importing ITK images use of mitk:: ITKImageImport is recommended.
Definition at line 504 of file mitkImage.cpp.
{
// const_cast is no risk for ImportMemoryManagementType == CopyMemory
return SetImportSlice(const_cast<void*>(data), s, t, n, CopyMemory);
}
| bool mitk::Image::SetVolume | ( | const void * | data, |
| int | t = 0, |
||
| int | n = 0 |
||
| ) | [virtual] |
Set data as volume at time t in channel n. It is in the responsibility of the caller to ensure that the data vector data is really a volume (at least is not smaller than a volume), since there is no chance to check this.
The data is copied to an array managed by the image. If the image shall reference the data, use SetImportVolume with ImportMemoryManagementType set to ReferenceMemory. For importing ITK images use of mitk:: ITKImageImport is recommended.
Definition at line 510 of file mitkImage.cpp.
{
// const_cast is no risk for ImportMemoryManagementType == CopyMemory
return SetImportVolume(const_cast<void*>(data), t, n, CopyMemory);
}
| void _ComputeExtremaInItkImage | ( | ItkImageType * | itkImage, |
| mitk::Image * | mitkImage, | ||
| int | t | ||
| ) | [friend] |
friend class SubImageSelector [friend] |
Definition at line 64 of file mitkImage.h.
ImageDataItemPointerArray mitk::Image::m_Channels [mutable, protected] |
Definition at line 593 of file mitkImage.h.
ImageDataItemPointer mitk::Image::m_CompleteData [protected] |
Definition at line 600 of file mitkImage.h.
std::vector<unsigned int> mitk::Image::m_CountOfMaxValuedVoxels [mutable, protected] |
Definition at line 607 of file mitkImage.h.
Referenced by Image().
std::vector<unsigned int> mitk::Image::m_CountOfMinValuedVoxels [mutable, protected] |
Definition at line 606 of file mitkImage.h.
Referenced by Image().
unsigned int mitk::Image::m_Dimension [protected] |
Definition at line 597 of file mitkImage.h.
unsigned int* mitk::Image::m_Dimensions [protected] |
Definition at line 598 of file mitkImage.h.
itk::Object::Pointer mitk::Image::m_HistogramGeneratorObject [mutable, protected] |
Definition at line 603 of file mitkImage.h.
Referenced by Image().
itk::TimeStamp mitk::Image::m_LastRecomputeTimeStamp [protected] |
Definition at line 613 of file mitkImage.h.
vcl_size_t* mitk::Image::m_OffsetTable [protected] |
Definition at line 599 of file mitkImage.h.
PixelType mitk::Image::m_PixelType [protected] |
Definition at line 601 of file mitkImage.h.
std::vector<ScalarType> mitk::Image::m_Scalar2ndMax [mutable, protected] |
Definition at line 611 of file mitkImage.h.
Referenced by Image().
std::vector<ScalarType> mitk::Image::m_Scalar2ndMin [mutable, protected] |
Definition at line 610 of file mitkImage.h.
Referenced by Image().
std::vector<ScalarType> mitk::Image::m_ScalarMax [mutable, protected] |
Definition at line 609 of file mitkImage.h.
Referenced by Image().
std::vector<ScalarType> mitk::Image::m_ScalarMin [mutable, protected] |
Definition at line 608 of file mitkImage.h.
Referenced by Image().
ImageDataItemPointerArray mitk::Image::m_Slices [mutable, protected] |
Definition at line 595 of file mitkImage.h.
itk::Object::Pointer mitk::Image::m_TimeSelectorForExtremaObject [mutable, protected] |
Definition at line 605 of file mitkImage.h.
ImageDataItemPointerArray mitk::Image::m_Volumes [mutable, protected] |
Definition at line 594 of file mitkImage.h.
1.7.2
