Superclass of all classes having one or more Images as input and generating Images as output. More...
#include <mitkImageToImageFilter.h>
Public Types | |
| typedef Superclass::OutputImageRegionType | OutputImageRegionType |
| typedef mitk::Image | InputImageType |
| typedef InputImageType::Pointer | InputImagePointer |
| typedef InputImageType::ConstPointer | InputImageConstPointer |
| typedef SlicedData::RegionType | InputImageRegionType |
Public Member Functions | |
| mitkClassMacro (ImageToImageFilter, ImageSource) | |
| virtual void | SetInput (const InputImageType *image) |
| virtual void | SetInput (unsigned int, const InputImageType *image) |
| const InputImageType * | GetInput (void) |
| const InputImageType * | GetInput (unsigned int idx) |
Static Public Member Functions | |
| static Pointer | New () |
Protected Member Functions | |
| ImageToImageFilter () | |
| virtual | ~ImageToImageFilter () |
| virtual void | PrintSelf (std::ostream &os, itk::Indent indent) const |
| virtual void | GenerateInputRequestedRegion () |
Superclass of all classes having one or more Images as input and generating Images as output.
Definition at line 31 of file mitkImageToImageFilter.h.
Definition at line 45 of file mitkImageToImageFilter.h.
Definition at line 44 of file mitkImageToImageFilter.h.
Definition at line 46 of file mitkImageToImageFilter.h.
Some convenient typedefs.
Definition at line 43 of file mitkImageToImageFilter.h.
| typedef Superclass::OutputImageRegionType mitk::ImageToImageFilter::OutputImageRegionType |
Superclass typedefs.
Reimplemented from mitk::ImageSource.
Definition at line 37 of file mitkImageToImageFilter.h.
| mitk::ImageToImageFilter::ImageToImageFilter | ( | ) | [protected] |
Definition at line 21 of file mitkImageToImageFilter.cpp.
{
// Modify superclass default values, can be overridden by subclasses
this->SetNumberOfRequiredInputs(1);
}
| mitk::ImageToImageFilter::~ImageToImageFilter | ( | ) | [protected, virtual] |
Definition at line 27 of file mitkImageToImageFilter.cpp.
{
}
| void mitk::ImageToImageFilter::GenerateInputRequestedRegion | ( | ) | [protected, virtual] |
What is the input requested region that is required to produce the output requested region? The base assumption for image processing filters is that the input requested region can be set to match the output requested region. If a filter requires more input (for instance a filter that uses neighborhoods needs more input than output to avoid introducing artificial boundary conditions) or less input (for instance a magnify filter) will have to override this method. In doing so, it should call its superclass' implementation as its first step. Note that this imaging filters operate differently than the classes to this point in the class hierachy. Up till now, the base assumption has been that the largest possible region will be requested of the input.
Reimplemented in mitk::ImageChannelSelector, mitk::ImageSliceSelector, mitk::ImageTimeSelector, mitk::RGBToRGBACastImageFilter, mitk::AngleCorrectByPointFilter, mitk::AutoCropImageFilter, mitk::BoundingObjectCutter, mitk::CylindricToCartesianFilter, mitk::DopplerToStrainRateFilter, mitk::ExtractImageFilter, mitk::GeometryClipImageFilter, mitk::HeightFieldSurfaceClipImageFilter, and mitk::MaskImageFilter.
Definition at line 85 of file mitkImageToImageFilter.cpp.
References mitk::SlicedData::SetRequestedRegion().
{
Superclass::GenerateInputRequestedRegion();
for (unsigned int idx = 0; idx < this->GetNumberOfInputs(); ++idx)
{
if (this->GetInput(idx))
{
mitk::ImageToImageFilter::InputImagePointer input =
const_cast< mitk::ImageToImageFilter::InputImageType * > ( this->GetInput(idx) );
// Use the function object RegionCopier to copy the output region
// to the input. The default region copier has default implementations
// to handle the cases where the input and output are the same
// dimension, the input a higher dimension than the output, and the
// input a lower dimension than the output.
InputImageRegionType inputRegion;
// this->CallCopyRegion(inputRegion, this->GetOutput()->GetRequestedRegion()); @FIXME ??
// input->SetRequestedRegion( inputRegion ); @FIXME ??
input->SetRequestedRegion( this->GetOutput() ); // ersatz. @FIXME ??
}
}
}
| const mitk::ImageToImageFilter::InputImageType * mitk::ImageToImageFilter::GetInput | ( | void | ) |
Definition at line 61 of file mitkImageToImageFilter.cpp.
Referenced by mitk::CutImageWithOutputTypeSelect(), mitk::PlaneCutFilter::GenerateData(), mitk::OverwriteSliceImageFilter::GenerateData(), mitk::ExtractImageFilter::GenerateData(), mitk::CorrectorAlgorithm::GenerateData(), mitk::BoundingObjectCutter::GenerateInputRequestedRegion(), mitk::ImageSliceSelector::GenerateOutputInformation(), mitk::HeightFieldSurfaceClipImageFilter::GenerateOutputInformation(), mitk::DopplerToStrainRateFilter::GenerateOutputInformation(), mitk::HeightFieldSurfaceClipImageFilter::SetClippingModeToConstant(), mitkExtractImageFilterTestClass::Test2D(), mitkExtractImageFilterTestClass::Test3D(), and mitkExtractImageFilterTestClass::Test4D().
{
if (this->GetNumberOfInputs() < 1)
{
return 0;
}
return static_cast<const mitk::ImageToImageFilter::InputImageType * >
(this->ProcessObject::GetInput(0) );
}
| const mitk::ImageToImageFilter::InputImageType * mitk::ImageToImageFilter::GetInput | ( | unsigned int | idx ) |
Definition at line 75 of file mitkImageToImageFilter.cpp.
{
return static_cast< const mitk::ImageToImageFilter::InputImageType * >
(this->ProcessObject::GetInput(idx));
}
| mitk::ImageToImageFilter::mitkClassMacro | ( | ImageToImageFilter | , |
| ImageSource | |||
| ) |
| static Pointer mitk::ImageToImageFilter::New | ( | ) | [static] |
Method for creation through the object factory.
Reimplemented from mitk::ImageSource.
Reimplemented in mitk::ImageChannelSelector, mitk::ImageSliceSelector, mitk::ImageTimeSelector, mitk::RGBToRGBACastImageFilter, mitk::SubImageSelector, mitk::BSplineRegistration, mitk::DemonsRegistration, mitk::HistogramMatching, mitk::RegistrationBase, mitk::SymmetricForcesDemonsRegistration, mitk::AngleCorrectByPointFilter, mitk::AutoCropImageFilter, mitk::BoundingObjectCutAndCast< TPixel >, mitk::BoundingObjectCutter, mitk::BoundingObjectToSegmentationFilter, mitk::CorrectorAlgorithm, mitk::CylindricToCartesianFilter, mitk::DopplerToStrainRateFilter, mitk::ExtractDirectedPlaneImageFilter, mitk::ExtractImageFilter, mitk::GeometryClipImageFilter, mitk::HeightFieldSurfaceClipImageFilter, mitk::ItkImageToImageFilterAdapter< TPixel >, mitk::MaskImageFilter, mitk::OverwriteSliceImageFilter, mitk::PadImageFilter, mitk::PlaneCutFilter, mitk::ImageRegistrationMethod, and mitk::PyramidalRegistrationMethod.
| void mitk::ImageToImageFilter::PrintSelf | ( | std::ostream & | os, |
| itk::Indent | indent | ||
| ) | const [protected, virtual] |
Definition at line 109 of file mitkImageToImageFilter.cpp.
{
Superclass::PrintSelf(os, indent);
}
| void mitk::ImageToImageFilter::SetInput | ( | unsigned int | index, |
| const InputImageType * | image | ||
| ) | [virtual] |
Connect one of the operands for pixel-wise addition
Definition at line 45 of file mitkImageToImageFilter.cpp.
{
if( index+1 > this->GetNumberOfInputs() )
{
this->SetNumberOfRequiredInputs( index + 1 );
}
// Process object is not const-correct so the const_cast is required here
this->ProcessObject::SetNthInput(index,
const_cast< mitk::ImageToImageFilter::InputImageType *>( image ) );
}
| void mitk::ImageToImageFilter::SetInput | ( | const InputImageType * | image ) | [virtual] |
Set/Get the image input of this process object.
Definition at line 34 of file mitkImageToImageFilter.cpp.
Referenced by mitk::Image::GetTimeSelector(), mitkOverwriteSliceImageFilterTestClass::Test2D(), mitkExtractImageFilterTestClass::Test2D(), mitkOverwriteSliceImageFilterTestClass::Test3D(), mitkExtractImageFilterTestClass::Test3D(), mitkExtractImageFilterTestClass::Test4D(), mitkOverwriteSliceImageFilterTestClass::TestOtherD(), and mitkExtractImageFilterTestClass::TestOtherD().
{
// Process object is not const-correct so the const_cast is required here
this->ProcessObject::SetNthInput(0,
const_cast< mitk::ImageToImageFilter::InputImageType * >( input ) );
}
