This class performes a demons registration between two images with the same modality.. More...
#include <mitkDemonsRegistration.h>
Public Types | |
| typedef DemonsRegistration | Self |
| typedef RegistrationBase | Superclass |
| typedef itk::SmartPointer< Self > | Pointer |
| typedef itk::SmartPointer < const Self > | ConstPointer |
Public Member Functions | |
| virtual const char * | GetClassName () const |
| void | SetNumberOfIterations (int iterations) |
| Sets the number of iterations which will be performed during the registration process. | |
| void | SetStandardDeviation (float deviation) |
| Sets the standard deviation used by the demons registration. | |
| void | SetSaveDeformationField (bool saveField) |
| Sets whether the resulting deformation field should be saved or not. | |
| void | SetDeformationFieldFileName (const char *fieldName) |
| Sets the filename for the resulting deformation field. | |
| void | SetSaveResult (bool saveResult) |
| Sets whether the result should be saved or not. | |
| void | SetResultFileName (const char *resultName) |
| Sets the filename for the resulting deformed image. | |
| itk::Image< itk::Vector< float, 3 > , 3 >::Pointer | GetDeformationField () |
| Returns the deformation field, which results by the registration. | |
| virtual void | GenerateData () |
| Starts the demons registration. | |
Static Public Member Functions | |
| static Pointer | New () |
| Method for creation through the object factory. | |
Protected Member Functions | |
| DemonsRegistration () | |
| Default constructor. | |
| virtual | ~DemonsRegistration () |
| Default destructor. | |
| template<typename TPixel , unsigned int VImageDimension> | |
| void | GenerateData2 (itk::Image< TPixel, VImageDimension > *itkImage1) |
| Template class to perform the demons registration with any kind of image. Called by GenerateData(). | |
Protected Attributes | |
| int | m_Iterations |
| float | m_StandardDeviation |
| const char * | m_FieldName |
| const char * | m_ResultName |
| bool | m_SaveField |
| bool | m_SaveResult |
| itk::Image< class itk::Vector < float, 3 >, 3 >::Pointer | m_DeformationField |
This class performes a demons registration between two images with the same modality..
Definition at line 38 of file mitkDemonsRegistration.h.
| typedef itk::SmartPointer<const Self> mitk::DemonsRegistration::ConstPointer |
Reimplemented from mitk::RegistrationBase.
Definition at line 43 of file mitkDemonsRegistration.h.
| typedef itk::SmartPointer<Self> mitk::DemonsRegistration::Pointer |
Reimplemented from mitk::RegistrationBase.
Definition at line 43 of file mitkDemonsRegistration.h.
Reimplemented from mitk::RegistrationBase.
Definition at line 43 of file mitkDemonsRegistration.h.
Reimplemented from mitk::RegistrationBase.
Definition at line 43 of file mitkDemonsRegistration.h.
| mitk::DemonsRegistration::DemonsRegistration | ( | ) | [protected] |
Default constructor.
Definition at line 25 of file mitkDemonsRegistration.cpp.
:
m_Iterations(50),
m_StandardDeviation(1.0),
m_FieldName("newField.mhd"),
m_ResultName("deformedImage.mhd"),
m_SaveField(true),
m_SaveResult(true),
m_DeformationField(NULL)
{
| mitk::DemonsRegistration::~DemonsRegistration | ( | ) | [protected, virtual] |
| virtual void mitk::DemonsRegistration::GenerateData | ( | ) | [inline, virtual] |
Starts the demons registration.
Reimplemented from mitk::ImageSource.
Definition at line 88 of file mitkDemonsRegistration.h.
References AccessByItk.
{
if (this->GetInput())
{
AccessByItk(this->GetInput(), GenerateData2);
}
}
| void mitk::DemonsRegistration::GenerateData2 | ( | itk::Image< TPixel, VImageDimension > * | itkImage1 ) | [protected] |
Template class to perform the demons registration with any kind of image. Called by GenerateData().
Definition at line 77 of file mitkDemonsRegistration.cpp.
References mitk::RegistrationBase::AddStepsToDo(), mitk::CastToItkImage(), mitk::CastToMitkImage(), mitk::ImageSource::GetOutput(), m_DeformationField, m_FieldName, m_Iterations, mitk::RegistrationBase::m_ReferenceImage, m_ResultName, m_SaveField, m_SaveResult, m_StandardDeviation, MITK_ERROR, New(), mitk::RegistrationBase::SetProgress(), and mitk::RegistrationBase::SetRemainingProgress().
{
typedef typename itk::Image< TPixel, VImageDimension > FixedImageType;
typedef typename itk::Image< TPixel, VImageDimension > MovingImageType;
typedef float InternalPixelType;
typedef typename itk::Image< InternalPixelType, VImageDimension > InternalImageType;
typedef typename itk::CastImageFilter< FixedImageType,
InternalImageType > FixedImageCasterType;
typedef typename itk::CastImageFilter< MovingImageType,
InternalImageType > MovingImageCasterType;
typedef typename itk::Image< InternalPixelType, VImageDimension > InternalImageType;
typedef typename itk::Vector< float, VImageDimension > VectorPixelType;
typedef typename itk::Image< VectorPixelType, VImageDimension > DeformationFieldType;
typedef typename itk::DemonsRegistrationFilter<
InternalImageType,
InternalImageType,
DeformationFieldType> RegistrationFilterType;
typedef typename itk::WarpImageFilter<
MovingImageType,
MovingImageType,
DeformationFieldType > WarperType;
typedef typename itk::LinearInterpolateImageFunction<
MovingImageType,
double > InterpolatorType;
typedef TPixel OutputPixelType;
typedef typename itk::Image< OutputPixelType, VImageDimension > OutputImageType;
typedef typename itk::CastImageFilter<
MovingImageType,
OutputImageType > CastFilterType;
typedef typename itk::ImageFileWriter< OutputImageType > WriterType;
typedef typename itk::ImageFileWriter< DeformationFieldType > FieldWriterType;
typename FixedImageType::Pointer fixedImage = FixedImageType::New();
mitk::CastToItkImage(m_ReferenceImage, fixedImage);
typename MovingImageType::Pointer movingImage = itkImage1;
if (fixedImage.IsNotNull() && movingImage.IsNotNull())
{
typename RegistrationFilterType::Pointer filter = RegistrationFilterType::New();
this->AddStepsToDo(4);
typename itk::ReceptorMemberCommand<DemonsRegistration>::Pointer command = itk::ReceptorMemberCommand<DemonsRegistration>::New();
command->SetCallbackFunction(this, &DemonsRegistration::SetProgress);
filter->AddObserver( itk::IterationEvent(), command );
typename FixedImageCasterType::Pointer fixedImageCaster = FixedImageCasterType::New();
fixedImageCaster->SetInput(fixedImage);
filter->SetFixedImage( fixedImageCaster->GetOutput() );
typename MovingImageCasterType::Pointer movingImageCaster = MovingImageCasterType::New();
movingImageCaster->SetInput(movingImage);
filter->SetMovingImage(movingImageCaster->GetOutput());
filter->SetNumberOfIterations( m_Iterations );
filter->SetStandardDeviations( m_StandardDeviation );
filter->Update();
typename WarperType::Pointer warper = WarperType::New();
typename InterpolatorType::Pointer interpolator = InterpolatorType::New();
warper->SetInput( movingImage );
warper->SetInterpolator( interpolator );
warper->SetOutputSpacing( fixedImage->GetSpacing() );
warper->SetOutputOrigin( fixedImage->GetOrigin() );
warper->SetOutputDirection( fixedImage->GetDirection());
warper->SetDeformationField( filter->GetOutput() );
warper->Update();
Image::Pointer outputImage = this->GetOutput();
mitk::CastToMitkImage( warper->GetOutput(), outputImage );
typename WriterType::Pointer writer = WriterType::New();
typename CastFilterType::Pointer caster = CastFilterType::New();
writer->SetFileName( m_ResultName );
caster->SetInput( warper->GetOutput() );
writer->SetInput( caster->GetOutput() );
if(m_SaveResult)
{
writer->Update();
}
if (VImageDimension == 2)
{
typedef DeformationFieldType VectorImage2DType;
typedef typename DeformationFieldType::PixelType Vector2DType;
typename VectorImage2DType::ConstPointer vectorImage2D = filter->GetOutput();
typename VectorImage2DType::RegionType region2D = vectorImage2D->GetBufferedRegion();
typename VectorImage2DType::IndexType index2D = region2D.GetIndex();
typename VectorImage2DType::SizeType size2D = region2D.GetSize();
typedef typename itk::Vector< float, 3 > Vector3DType;
typedef typename itk::Image< Vector3DType, 3 > VectorImage3DType;
typedef typename itk::ImageFileWriter< VectorImage3DType > WriterType;
typename WriterType::Pointer writer3D = WriterType::New();
typename VectorImage3DType::Pointer vectorImage3D = VectorImage3DType::New();
typename VectorImage3DType::RegionType region3D;
typename VectorImage3DType::IndexType index3D;
typename VectorImage3DType::SizeType size3D;
index3D[0] = index2D[0];
index3D[1] = index2D[1];
index3D[2] = 0;
size3D[0] = size2D[0];
size3D[1] = size2D[1];
size3D[2] = 1;
region3D.SetSize( size3D );
region3D.SetIndex( index3D );
typename VectorImage2DType::SpacingType spacing2D = vectorImage2D->GetSpacing();
typename VectorImage3DType::SpacingType spacing3D;
spacing3D[0] = spacing2D[0];
spacing3D[1] = spacing2D[1];
spacing3D[2] = 1.0;
vectorImage3D->SetSpacing( spacing3D );
vectorImage3D->SetRegions( region3D );
vectorImage3D->Allocate();
typedef typename itk::ImageRegionConstIterator< VectorImage2DType > Iterator2DType;
typedef typename itk::ImageRegionIterator< VectorImage3DType > Iterator3DType;
Iterator2DType it2( vectorImage2D, region2D );
Iterator3DType it3( vectorImage3D, region3D );
it2.GoToBegin();
it3.GoToBegin();
Vector2DType vector2D;
Vector3DType vector3D;
vector3D[2] = 0; // set Z component to zero.
while( !it2.IsAtEnd() )
{
vector2D = it2.Get();
vector3D[0] = vector2D[0];
vector3D[1] = vector2D[1];
it3.Set( vector3D );
++it2;
++it3;
}
writer3D->SetInput( vectorImage3D );
m_DeformationField = vectorImage3D;
writer3D->SetFileName( m_FieldName );
try
{
if(m_SaveField)
{
writer3D->Update();
}
}
catch( itk::ExceptionObject & excp )
{
MITK_ERROR << excp << std::endl;
}
}
else
{
typename FieldWriterType::Pointer fieldwriter = FieldWriterType::New();
fieldwriter->SetFileName(m_FieldName);
fieldwriter->SetInput( filter->GetOutput() );
m_DeformationField = (itk::Image<itk::Vector<float, 3>,3> *)(filter->GetOutput());
if(m_SaveField)
{
fieldwriter->Update();
}
}
this->SetRemainingProgress(4);
}
| virtual const char* mitk::DemonsRegistration::GetClassName | ( | ) | const [virtual] |
Reimplemented from mitk::RegistrationBase.
| itk::Image< itk::Vector< float, 3 >, 3 >::Pointer mitk::DemonsRegistration::GetDeformationField | ( | ) |
Returns the deformation field, which results by the registration.
Definition at line 71 of file mitkDemonsRegistration.cpp.
References m_DeformationField.
{
return m_DeformationField;
| static Pointer mitk::DemonsRegistration::New | ( | ) | [static] |
Method for creation through the object factory.
Reimplemented from mitk::RegistrationBase.
Referenced by QmitkDemonsRegistrationView::CalculateTransformation(), GenerateData2(), and mitkDemonsRegistrationTest().
| void mitk::DemonsRegistration::SetDeformationFieldFileName | ( | const char * | fieldName ) |
Sets the filename for the resulting deformation field.
Definition at line 56 of file mitkDemonsRegistration.cpp.
References m_FieldName.
{
m_FieldName = fieldName;
| void mitk::DemonsRegistration::SetNumberOfIterations | ( | int | iterations ) |
Sets the number of iterations which will be performed during the registration process.
Definition at line 41 of file mitkDemonsRegistration.cpp.
References m_Iterations.
{
m_Iterations = iterations;
| void mitk::DemonsRegistration::SetResultFileName | ( | const char * | resultName ) |
Sets the filename for the resulting deformed image.
Definition at line 66 of file mitkDemonsRegistration.cpp.
References m_ResultName.
{
m_ResultName = resultName;
| void mitk::DemonsRegistration::SetSaveDeformationField | ( | bool | saveField ) |
Sets whether the resulting deformation field should be saved or not.
Definition at line 51 of file mitkDemonsRegistration.cpp.
References m_SaveField.
{
m_SaveField = saveField;
| void mitk::DemonsRegistration::SetSaveResult | ( | bool | saveResult ) |
Sets whether the result should be saved or not.
Definition at line 61 of file mitkDemonsRegistration.cpp.
References m_SaveResult.
{
m_SaveResult = saveResult;
| void mitk::DemonsRegistration::SetStandardDeviation | ( | float | deviation ) |
Sets the standard deviation used by the demons registration.
Definition at line 46 of file mitkDemonsRegistration.cpp.
References m_StandardDeviation.
{
m_StandardDeviation = deviation;
itk::Image<class itk::Vector<float, 3>,3>::Pointer mitk::DemonsRegistration::m_DeformationField [protected] |
Definition at line 121 of file mitkDemonsRegistration.h.
Referenced by GenerateData2(), and GetDeformationField().
const char* mitk::DemonsRegistration::m_FieldName [protected] |
Definition at line 117 of file mitkDemonsRegistration.h.
Referenced by GenerateData2(), and SetDeformationFieldFileName().
int mitk::DemonsRegistration::m_Iterations [protected] |
Definition at line 115 of file mitkDemonsRegistration.h.
Referenced by GenerateData2(), and SetNumberOfIterations().
const char* mitk::DemonsRegistration::m_ResultName [protected] |
Definition at line 118 of file mitkDemonsRegistration.h.
Referenced by GenerateData2(), and SetResultFileName().
bool mitk::DemonsRegistration::m_SaveField [protected] |
Definition at line 119 of file mitkDemonsRegistration.h.
Referenced by GenerateData2(), and SetSaveDeformationField().
bool mitk::DemonsRegistration::m_SaveResult [protected] |
Definition at line 120 of file mitkDemonsRegistration.h.
Referenced by GenerateData2(), and SetSaveResult().
float mitk::DemonsRegistration::m_StandardDeviation [protected] |
Definition at line 116 of file mitkDemonsRegistration.h.
Referenced by GenerateData2(), and SetStandardDeviation().
1.7.2
