#include <QmitkStdMultiWidget.h>
Definition at line 48 of file QmitkStdMultiWidget.h.
| anonymous enum |
Definition at line 229 of file QmitkStdMultiWidget.h.
| anonymous enum |
Definition at line 230 of file QmitkStdMultiWidget.h.
{ LAYOUT_DEFAULT = 0, LAYOUT_2D_IMAGES_UP, LAYOUT_2D_IMAGES_LEFT,
LAYOUT_BIG_3D, LAYOUT_WIDGET1, LAYOUT_WIDGET2, LAYOUT_WIDGET3,
LAYOUT_2X_2D_AND_3D_WIDGET, LAYOUT_ROW_WIDGET_3_AND_4,
LAYOUT_COLUMN_WIDGET_3_AND_4, LAYOUT_ROW_WIDGET_SMALL3_AND_BIG4 ,
LAYOUT_SMALL_UPPER_WIDGET2_BIG3_AND4,LAYOUT_2D_AND_3D_LEFT_2D_RIGHT_WIDGET,
LAYOUT_2D_UP_AND_3D_DOWN};
| anonymous enum |
Definition at line 237 of file QmitkStdMultiWidget.h.
{
TRANSVERSAL,
SAGITTAL,
CORONAL,
THREE_D
};
| QmitkStdMultiWidget::QmitkStdMultiWidget | ( | QWidget * | parent = 0, |
| Qt::WindowFlags | f = 0 |
||
| ) |
Definition at line 45 of file QmitkStdMultiWidget.cpp.
References ActivateMenuWidget(), CORONAL, InitializeWidget(), levelWindowWidget, m_LayoutSplit, m_MainSplit, m_SubSplit1, m_SubSplit2, mitkWidget1, mitkWidget1Container, mitkWidget2, mitkWidget2Container, mitkWidget3, mitkWidget3Container, mitkWidget4, mitkWidget4Container, OnLayoutDesignChanged(), QmitkStdMultiWidgetLayout, ResetCrosshair(), SAGITTAL, QmitkRenderWindow::SetLayoutIndex(), SetWidgetPlaneMode(), THREE_D, TRANSVERSAL, TRUE, and WidgetNotifyNewCrossHairMode().
: QWidget(parent, f), mitkWidget1(NULL), mitkWidget2(NULL), mitkWidget3(NULL), mitkWidget4(NULL), m_PlaneNode1(NULL), m_PlaneNode2(NULL), m_PlaneNode3(NULL), m_Node(NULL) { /*******************************/ //Create Widget manually /*******************************/ //create Layouts QmitkStdMultiWidgetLayout = new QHBoxLayout( this ); //Set Layout to widget this->setLayout(QmitkStdMultiWidgetLayout); // QmitkNavigationToolBar* toolBar = new QmitkNavigationToolBar(); // QmitkStdMultiWidgetLayout->addWidget( toolBar ); //create main splitter m_MainSplit = new QSplitter( this ); QmitkStdMultiWidgetLayout->addWidget( m_MainSplit ); //create m_LayoutSplit and add to the mainSplit m_LayoutSplit = new QSplitter( Qt::Vertical, m_MainSplit ); m_MainSplit->addWidget( m_LayoutSplit ); //create m_SubSplit1 and m_SubSplit2 m_SubSplit1 = new QSplitter( m_LayoutSplit ); m_SubSplit2 = new QSplitter( m_LayoutSplit ); //creae Widget Container mitkWidget1Container = new QWidget(m_SubSplit1); mitkWidget2Container = new QWidget(m_SubSplit1); mitkWidget3Container = new QWidget(m_SubSplit2); mitkWidget4Container = new QWidget(m_SubSplit2); mitkWidget1Container->setContentsMargins(0,0,0,0); mitkWidget2Container->setContentsMargins(0,0,0,0); mitkWidget3Container->setContentsMargins(0,0,0,0); mitkWidget4Container->setContentsMargins(0,0,0,0); //create Widget Layout QHBoxLayout *mitkWidgetLayout1 = new QHBoxLayout(mitkWidget1Container); QHBoxLayout *mitkWidgetLayout2 = new QHBoxLayout(mitkWidget2Container); QHBoxLayout *mitkWidgetLayout3 = new QHBoxLayout(mitkWidget3Container); QHBoxLayout *mitkWidgetLayout4 = new QHBoxLayout(mitkWidget4Container); mitkWidgetLayout1->setMargin(0); mitkWidgetLayout2->setMargin(0); mitkWidgetLayout3->setMargin(0); mitkWidgetLayout4->setMargin(0); //set Layout to Widget Container mitkWidget1Container->setLayout(mitkWidgetLayout1); mitkWidget2Container->setLayout(mitkWidgetLayout2); mitkWidget3Container->setLayout(mitkWidgetLayout3); mitkWidget4Container->setLayout(mitkWidgetLayout4); //set SizePolicy mitkWidget1Container->setSizePolicy(QSizePolicy::Expanding,QSizePolicy::Expanding); mitkWidget2Container->setSizePolicy(QSizePolicy::Expanding,QSizePolicy::Expanding); mitkWidget3Container->setSizePolicy(QSizePolicy::Expanding,QSizePolicy::Expanding); mitkWidget4Container->setSizePolicy(QSizePolicy::Expanding,QSizePolicy::Expanding); //insert Widget Container into the splitters m_SubSplit1->addWidget( mitkWidget1Container ); m_SubSplit1->addWidget( mitkWidget2Container ); m_SubSplit2->addWidget( mitkWidget3Container ); m_SubSplit2->addWidget( mitkWidget4Container ); // mitk::RenderingManager::GetInstance()->SetGlobalInteraction( mitk::GlobalInteraction::GetInstance() ); //Create RenderWindows 1 mitkWidget1 = new QmitkRenderWindow(mitkWidget1Container, "stdmulti.widget1"); mitkWidget1->setMaximumSize(2000,2000); mitkWidget1->SetLayoutIndex( TRANSVERSAL ); mitkWidgetLayout1->addWidget(mitkWidget1); //Create RenderWindows 2 mitkWidget2 = new QmitkRenderWindow(mitkWidget2Container, "stdmulti.widget2"); mitkWidget2->setMaximumSize(2000,2000); mitkWidget2->setEnabled( TRUE ); mitkWidget2->SetLayoutIndex( SAGITTAL ); mitkWidgetLayout2->addWidget(mitkWidget2); //Create RenderWindows 3 mitkWidget3 = new QmitkRenderWindow(mitkWidget3Container, "stdmulti.widget3"); mitkWidget3->setMaximumSize(2000,2000); mitkWidget3->SetLayoutIndex( CORONAL ); mitkWidgetLayout3->addWidget(mitkWidget3); //Create RenderWindows 4 mitkWidget4 = new QmitkRenderWindow(mitkWidget4Container, "stdmulti.widget4"); mitkWidget4->setMaximumSize(2000,2000); mitkWidget4->SetLayoutIndex( THREE_D ); mitkWidgetLayout4->addWidget(mitkWidget4); //create SignalSlot Connection connect( mitkWidget1, SIGNAL( SignalLayoutDesignChanged(int) ), this, SLOT( OnLayoutDesignChanged(int) ) ); connect( mitkWidget1, SIGNAL( ResetView() ), this, SLOT( ResetCrosshair() ) ); connect( mitkWidget1, SIGNAL( ChangeCrosshairRotationMode(int) ), this, SLOT( SetWidgetPlaneMode(int) ) ); connect( this, SIGNAL(WidgetNotifyNewCrossHairMode(int)), mitkWidget1, SLOT(OnWidgetPlaneModeChanged(int)) ); connect( mitkWidget2, SIGNAL( SignalLayoutDesignChanged(int) ), this, SLOT( OnLayoutDesignChanged(int) ) ); connect( mitkWidget2, SIGNAL( ResetView() ), this, SLOT( ResetCrosshair() ) ); connect( mitkWidget2, SIGNAL( ChangeCrosshairRotationMode(int) ), this, SLOT( SetWidgetPlaneMode(int) ) ); connect( this, SIGNAL(WidgetNotifyNewCrossHairMode(int)), mitkWidget2, SLOT(OnWidgetPlaneModeChanged(int)) ); connect( mitkWidget3, SIGNAL( SignalLayoutDesignChanged(int) ), this, SLOT( OnLayoutDesignChanged(int) ) ); connect( mitkWidget3, SIGNAL( ResetView() ), this, SLOT( ResetCrosshair() ) ); connect( mitkWidget3, SIGNAL( ChangeCrosshairRotationMode(int) ), this, SLOT( SetWidgetPlaneMode(int) ) ); connect( this, SIGNAL(WidgetNotifyNewCrossHairMode(int)), mitkWidget3, SLOT(OnWidgetPlaneModeChanged(int)) ); connect( mitkWidget4, SIGNAL( SignalLayoutDesignChanged(int) ), this, SLOT( OnLayoutDesignChanged(int) ) ); connect( mitkWidget4, SIGNAL( ResetView() ), this, SLOT( ResetCrosshair() ) ); connect( mitkWidget4, SIGNAL( ChangeCrosshairRotationMode(int) ), this, SLOT( SetWidgetPlaneMode(int) ) ); connect( this, SIGNAL(WidgetNotifyNewCrossHairMode(int)), mitkWidget4, SLOT(OnWidgetPlaneModeChanged(int)) ); //Create Level Window Widget levelWindowWidget = new QmitkLevelWindowWidget( m_MainSplit ); //this levelWindowWidget->setObjectName(QString::fromUtf8("levelWindowWidget")); QSizePolicy sizePolicy(QSizePolicy::Preferred, QSizePolicy::Preferred); sizePolicy.setHorizontalStretch(0); sizePolicy.setVerticalStretch(0); sizePolicy.setHeightForWidth(levelWindowWidget->sizePolicy().hasHeightForWidth()); levelWindowWidget->setSizePolicy(sizePolicy); levelWindowWidget->setMaximumSize(QSize(50, 2000)); //add LevelWindow Widget to mainSplitter m_MainSplit->addWidget( levelWindowWidget ); //show mainSplitt and add to Layout m_MainSplit->show(); //resize Image. this->resize( QSize(364, 477).expandedTo(minimumSizeHint()) ); //Initialize the widgets. this->InitializeWidget(); //Activate Widget Menu this->ActivateMenuWidget( true ); }
| QmitkStdMultiWidget::~QmitkStdMultiWidget | ( | ) | [virtual] |
Definition at line 420 of file QmitkStdMultiWidget.cpp.
References DisableNavigationControllerEventListening(), DisablePositionTracking(), mitk::VtkLayerController::GetInstance(), GetRenderWindow1(), GetRenderWindow2(), GetRenderWindow3(), m_CornerAnnotaions, and ren.
{
DisablePositionTracking();
DisableNavigationControllerEventListening();
mitk::VtkLayerController::GetInstance(this->GetRenderWindow1()->GetRenderWindow())->RemoveRenderer( m_CornerAnnotaions[0].ren );
mitk::VtkLayerController::GetInstance(this->GetRenderWindow2()->GetRenderWindow())->RemoveRenderer( m_CornerAnnotaions[1].ren );
mitk::VtkLayerController::GetInstance(this->GetRenderWindow3()->GetRenderWindow())->RemoveRenderer( m_CornerAnnotaions[2].ren );
//Delete CornerAnnotation
m_CornerAnnotaions[0].cornerText->Delete();
m_CornerAnnotaions[0].textProp->Delete();
m_CornerAnnotaions[0].ren->Delete();
m_CornerAnnotaions[1].cornerText->Delete();
m_CornerAnnotaions[1].textProp->Delete();
m_CornerAnnotaions[1].ren->Delete();
m_CornerAnnotaions[2].cornerText->Delete();
m_CornerAnnotaions[2].textProp->Delete();
m_CornerAnnotaions[2].ren->Delete();
}
| void QmitkStdMultiWidget::ActivateMenuWidget | ( | bool | state ) |
activate Menu Widget. true: activated, false: deactivated
Definition at line 1989 of file QmitkStdMultiWidget.cpp.
References QmitkRenderWindow::ActivateMenuWidget(), mitkWidget1, mitkWidget2, mitkWidget3, and mitkWidget4.
Referenced by QmitkStdMultiWidget().
{
mitkWidget1->ActivateMenuWidget( state );
mitkWidget2->ActivateMenuWidget( state );
mitkWidget3->ActivateMenuWidget( state );
mitkWidget4->ActivateMenuWidget( state );
}
| void QmitkStdMultiWidget::AddDisplayPlaneSubTree | ( | ) | [slot] |
Definition at line 1284 of file QmitkStdMultiWidget.cpp.
References mitk::BaseRenderer::GetInstance(), m_Node, m_PlaneNode1, m_PlaneNode2, m_PlaneNode3, mitkWidget1, mitkWidget2, mitkWidget3, mitkWidget4, mitk::DataNode::New(), mitk::Geometry2DDataMapper2D::New(), mitk::StringProperty::New(), mitk::BoolProperty::New(), and mitk::BaseRenderer::Standard2D.
Referenced by QmitkStdMultiWidgetEditor::CreateQtPartControl(), and Step8::SetupWidgets().
{
// add the displayed planes of the multiwidget to a node to which the subtree
// @a planesSubTree points ...
float white[3] = {1.0f,1.0f,1.0f};
mitk::Geometry2DDataMapper2D::Pointer mapper;
// ... of widget 1
m_PlaneNode1 = (mitk::BaseRenderer::GetInstance(mitkWidget1->GetRenderWindow()))->GetCurrentWorldGeometry2DNode();
m_PlaneNode1->SetColor(white, mitk::BaseRenderer::GetInstance(mitkWidget4->GetRenderWindow()));
m_PlaneNode1->SetProperty("visible", mitk::BoolProperty::New(true));
m_PlaneNode1->SetProperty("name", mitk::StringProperty::New("widget1Plane"));
m_PlaneNode1->SetProperty("includeInBoundingBox", mitk::BoolProperty::New(false));
m_PlaneNode1->SetProperty("helper object", mitk::BoolProperty::New(true));
mapper = mitk::Geometry2DDataMapper2D::New();
m_PlaneNode1->SetMapper(mitk::BaseRenderer::Standard2D, mapper);
// ... of widget 2
m_PlaneNode2 =( mitk::BaseRenderer::GetInstance(mitkWidget2->GetRenderWindow()))->GetCurrentWorldGeometry2DNode();
m_PlaneNode2->SetColor(white, mitk::BaseRenderer::GetInstance(mitkWidget4->GetRenderWindow()));
m_PlaneNode2->SetProperty("visible", mitk::BoolProperty::New(true));
m_PlaneNode2->SetProperty("name", mitk::StringProperty::New("widget2Plane"));
m_PlaneNode2->SetProperty("includeInBoundingBox", mitk::BoolProperty::New(false));
m_PlaneNode2->SetProperty("helper object", mitk::BoolProperty::New(true));
mapper = mitk::Geometry2DDataMapper2D::New();
m_PlaneNode2->SetMapper(mitk::BaseRenderer::Standard2D, mapper);
// ... of widget 3
m_PlaneNode3 = (mitk::BaseRenderer::GetInstance(mitkWidget3->GetRenderWindow()))->GetCurrentWorldGeometry2DNode();
m_PlaneNode3->SetColor(white, mitk::BaseRenderer::GetInstance(mitkWidget4->GetRenderWindow()));
m_PlaneNode3->SetProperty("visible", mitk::BoolProperty::New(true));
m_PlaneNode3->SetProperty("name", mitk::StringProperty::New("widget3Plane"));
m_PlaneNode3->SetProperty("includeInBoundingBox", mitk::BoolProperty::New(false));
m_PlaneNode3->SetProperty("helper object", mitk::BoolProperty::New(true));
mapper = mitk::Geometry2DDataMapper2D::New();
m_PlaneNode3->SetMapper(mitk::BaseRenderer::Standard2D, mapper);
m_Node = mitk::DataNode::New();
m_Node->SetProperty("name", mitk::StringProperty::New("Widgets"));
m_Node->SetProperty("helper object", mitk::BoolProperty::New(true));
}
| void QmitkStdMultiWidget::AddPlanesToDataStorage | ( | ) |
Definition at line 457 of file QmitkStdMultiWidget.cpp.
References m_DataStorage, m_Node, m_PlaneNode1, m_PlaneNode2, m_PlaneNode3, and mitk::BaseRenderer::Standard2D.
Referenced by QmitkStdMultiWidgetEditor::PartVisible(), and Step8::SetupWidgets().
{
if (m_PlaneNode1.IsNotNull() && m_PlaneNode2.IsNotNull() && m_PlaneNode3.IsNotNull() && m_Node.IsNotNull())
{
if (m_DataStorage.IsNotNull())
{
m_DataStorage->Add(m_Node);
m_DataStorage->Add(m_PlaneNode1, m_Node);
m_DataStorage->Add(m_PlaneNode2, m_Node);
m_DataStorage->Add(m_PlaneNode3, m_Node);
static_cast<mitk::Geometry2DDataMapper2D*>(m_PlaneNode1->GetMapper(mitk::BaseRenderer::Standard2D))->SetDatastorageAndGeometryBaseNode(m_DataStorage, m_Node);
static_cast<mitk::Geometry2DDataMapper2D*>(m_PlaneNode2->GetMapper(mitk::BaseRenderer::Standard2D))->SetDatastorageAndGeometryBaseNode(m_DataStorage, m_Node);
static_cast<mitk::Geometry2DDataMapper2D*>(m_PlaneNode3->GetMapper(mitk::BaseRenderer::Standard2D))->SetDatastorageAndGeometryBaseNode(m_DataStorage, m_Node);
}
}
}
| void QmitkStdMultiWidget::changeLayoutTo2DImagesLeft | ( | ) | [slot] |
Definition at line 547 of file QmitkStdMultiWidget.cpp.
References HideAllWidgetToolbars(), LAYOUT_2D_IMAGES_LEFT, QmitkRenderWindow::LayoutDesignListChanged(), levelWindowWidget, m_Layout, m_LayoutSplit, m_MainSplit, m_SubSplit1, m_SubSplit2, mitkWidget1, mitkWidget1Container, mitkWidget2, mitkWidget2Container, mitkWidget3, mitkWidget3Container, mitkWidget4, mitkWidget4Container, QmitkStdMultiWidgetLayout, SMW_INFO, and UpdateAllWidgets().
Referenced by OnLayoutDesignChanged().
{
SMW_INFO << "changing layout to 2D images left... " << std::endl;
//Hide all Menu Widgets
this->HideAllWidgetToolbars();
delete QmitkStdMultiWidgetLayout ;
//create Main Layout
QmitkStdMultiWidgetLayout = new QHBoxLayout( this );
//create main splitter
m_MainSplit = new QSplitter( this );
QmitkStdMultiWidgetLayout->addWidget( m_MainSplit );
//create m_LayoutSplit and add to the mainSplit
m_LayoutSplit = new QSplitter( m_MainSplit );
m_MainSplit->addWidget( m_LayoutSplit );
//add LevelWindow Widget to mainSplitter
m_MainSplit->addWidget( levelWindowWidget );
//create m_SubSplit1 and m_SubSplit2
m_SubSplit1 = new QSplitter( Qt::Vertical, m_LayoutSplit );
m_SubSplit2 = new QSplitter( m_LayoutSplit );
//insert Widget into the splitters
m_SubSplit1->addWidget( mitkWidget1Container );
m_SubSplit1->addWidget( mitkWidget2Container );
m_SubSplit1->addWidget( mitkWidget3Container );
//set splitterSize of SubSplit1
QList<int> splitterSize;
splitterSize.push_back(1000);
splitterSize.push_back(1000);
splitterSize.push_back(1000);
m_SubSplit1->setSizes( splitterSize );
m_SubSplit2->addWidget( mitkWidget4Container );
//set splitterSize of Layout Split
splitterSize.clear();
splitterSize.push_back(400);
splitterSize.push_back(1000);
m_LayoutSplit->setSizes( splitterSize );
//show mainSplitt and add to Layout
m_MainSplit->show();
//show Widget if hidden
if ( mitkWidget1->isHidden() ) mitkWidget1->show();
if ( mitkWidget2->isHidden() ) mitkWidget2->show();
if ( mitkWidget3->isHidden() ) mitkWidget3->show();
if ( mitkWidget4->isHidden() ) mitkWidget4->show();
//update Layout Name
m_Layout = LAYOUT_2D_IMAGES_LEFT;
//update Layout Design List
mitkWidget1->LayoutDesignListChanged( LAYOUT_2D_IMAGES_LEFT );
mitkWidget2->LayoutDesignListChanged( LAYOUT_2D_IMAGES_LEFT );
mitkWidget3->LayoutDesignListChanged( LAYOUT_2D_IMAGES_LEFT );
mitkWidget4->LayoutDesignListChanged( LAYOUT_2D_IMAGES_LEFT );
//update Alle Widgets
this->UpdateAllWidgets();
}
| void QmitkStdMultiWidget::changeLayoutTo2DImagesUp | ( | ) | [slot] |
Definition at line 474 of file QmitkStdMultiWidget.cpp.
References HideAllWidgetToolbars(), LAYOUT_2D_IMAGES_UP, QmitkRenderWindow::LayoutDesignListChanged(), levelWindowWidget, m_Layout, m_LayoutSplit, m_MainSplit, m_SubSplit1, m_SubSplit2, mitkWidget1, mitkWidget1Container, mitkWidget2, mitkWidget2Container, mitkWidget3, mitkWidget3Container, mitkWidget4, mitkWidget4Container, QmitkStdMultiWidgetLayout, SMW_INFO, and UpdateAllWidgets().
Referenced by OnLayoutDesignChanged().
{
SMW_INFO << "changing layout to 2D images up... " << std::endl;
//Hide all Menu Widgets
this->HideAllWidgetToolbars();
delete QmitkStdMultiWidgetLayout ;
//create Main Layout
QmitkStdMultiWidgetLayout = new QHBoxLayout( this );
//Set Layout to widget
this->setLayout(QmitkStdMultiWidgetLayout);
//create main splitter
m_MainSplit = new QSplitter( this );
QmitkStdMultiWidgetLayout->addWidget( m_MainSplit );
//create m_LayoutSplit and add to the mainSplit
m_LayoutSplit = new QSplitter( Qt::Vertical, m_MainSplit );
m_MainSplit->addWidget( m_LayoutSplit );
//add LevelWindow Widget to mainSplitter
m_MainSplit->addWidget( levelWindowWidget );
//create m_SubSplit1 and m_SubSplit2
m_SubSplit1 = new QSplitter( m_LayoutSplit );
m_SubSplit2 = new QSplitter( m_LayoutSplit );
//insert Widget Container into splitter top
m_SubSplit1->addWidget( mitkWidget1Container );
m_SubSplit1->addWidget( mitkWidget2Container );
m_SubSplit1->addWidget( mitkWidget3Container );
//set SplitterSize for splitter top
QList<int> splitterSize;
splitterSize.push_back(1000);
splitterSize.push_back(1000);
splitterSize.push_back(1000);
m_SubSplit1->setSizes( splitterSize );
//insert Widget Container into splitter bottom
m_SubSplit2->addWidget( mitkWidget4Container );
//set SplitterSize for splitter m_LayoutSplit
splitterSize.clear();
splitterSize.push_back(400);
splitterSize.push_back(1000);
m_LayoutSplit->setSizes( splitterSize );
//show mainSplitt
m_MainSplit->show();
//show Widget if hidden
if ( mitkWidget1->isHidden() ) mitkWidget1->show();
if ( mitkWidget2->isHidden() ) mitkWidget2->show();
if ( mitkWidget3->isHidden() ) mitkWidget3->show();
if ( mitkWidget4->isHidden() ) mitkWidget4->show();
//Change Layout Name
m_Layout = LAYOUT_2D_IMAGES_UP;
//update Layout Design List
mitkWidget1->LayoutDesignListChanged( LAYOUT_2D_IMAGES_UP );
mitkWidget2->LayoutDesignListChanged( LAYOUT_2D_IMAGES_UP );
mitkWidget3->LayoutDesignListChanged( LAYOUT_2D_IMAGES_UP );
mitkWidget4->LayoutDesignListChanged( LAYOUT_2D_IMAGES_UP );
//update Alle Widgets
this->UpdateAllWidgets();
}
| void QmitkStdMultiWidget::changeLayoutTo2DUpAnd3DDown | ( | ) | [slot] |
Definition at line 1156 of file QmitkStdMultiWidget.cpp.
References HideAllWidgetToolbars(), LAYOUT_2D_UP_AND_3D_DOWN, QmitkRenderWindow::LayoutDesignListChanged(), levelWindowWidget, m_Layout, m_LayoutSplit, m_MainSplit, m_SubSplit1, m_SubSplit2, mitkWidget1, mitkWidget1Container, mitkWidget2, mitkWidget3, mitkWidget4, mitkWidget4Container, QmitkStdMultiWidgetLayout, SMW_INFO, and UpdateAllWidgets().
{
SMW_INFO << "changing layout to 2D up and 3D down" << std::endl;
//Hide all Menu Widgets
this->HideAllWidgetToolbars();
delete QmitkStdMultiWidgetLayout ;
//create Main Layout
QmitkStdMultiWidgetLayout = new QHBoxLayout( this );
//Set Layout to widget
this->setLayout(QmitkStdMultiWidgetLayout);
//create main splitter
m_MainSplit = new QSplitter( this );
QmitkStdMultiWidgetLayout->addWidget( m_MainSplit );
//create m_LayoutSplit and add to the mainSplit
m_LayoutSplit = new QSplitter( Qt::Vertical, m_MainSplit );
m_MainSplit->addWidget( m_LayoutSplit );
//add LevelWindow Widget to mainSplitter
m_MainSplit->addWidget( levelWindowWidget );
//create m_SubSplit1 and m_SubSplit2
m_SubSplit1 = new QSplitter( m_LayoutSplit );
m_SubSplit2 = new QSplitter( m_LayoutSplit );
//insert Widget Container into splitter top
m_SubSplit1->addWidget( mitkWidget1Container );
//set SplitterSize for splitter top
QList<int> splitterSize;
// splitterSize.push_back(1000);
// splitterSize.push_back(1000);
// splitterSize.push_back(1000);
// m_SubSplit1->setSizes( splitterSize );
//insert Widget Container into splitter bottom
m_SubSplit2->addWidget( mitkWidget4Container );
//set SplitterSize for splitter m_LayoutSplit
splitterSize.clear();
splitterSize.push_back(700);
splitterSize.push_back(700);
m_LayoutSplit->setSizes( splitterSize );
//show mainSplitt
m_MainSplit->show();
//show/hide Widgets
if ( mitkWidget1->isHidden() ) mitkWidget1->show();
mitkWidget2->hide();
mitkWidget3->hide();
if ( mitkWidget4->isHidden() ) mitkWidget4->show();
m_Layout = LAYOUT_2D_UP_AND_3D_DOWN;
//update Layout Design List
mitkWidget1->LayoutDesignListChanged( LAYOUT_2D_UP_AND_3D_DOWN );
mitkWidget2->LayoutDesignListChanged( LAYOUT_2D_UP_AND_3D_DOWN );
mitkWidget3->LayoutDesignListChanged( LAYOUT_2D_UP_AND_3D_DOWN );
mitkWidget4->LayoutDesignListChanged( LAYOUT_2D_UP_AND_3D_DOWN );
//update all Widgets
this->UpdateAllWidgets();
}
| void QmitkStdMultiWidget::changeLayoutTo2x2Dand3DWidget | ( | ) | [slot] |
Definition at line 1034 of file QmitkStdMultiWidget.cpp.
References HideAllWidgetToolbars(), LAYOUT_2X_2D_AND_3D_WIDGET, QmitkRenderWindow::LayoutDesignListChanged(), levelWindowWidget, m_Layout, m_LayoutSplit, m_MainSplit, m_SubSplit1, m_SubSplit2, mitkWidget1, mitkWidget1Container, mitkWidget2, mitkWidget2Container, mitkWidget3, mitkWidget4, mitkWidget4Container, QmitkStdMultiWidgetLayout, SMW_INFO, and UpdateAllWidgets().
Referenced by OnLayoutDesignChanged().
{
SMW_INFO << "changing layout to 2 x 2D and 3D Widget" << std::endl;
//Hide all Menu Widgets
this->HideAllWidgetToolbars();
delete QmitkStdMultiWidgetLayout ;
//create Main Layout
QmitkStdMultiWidgetLayout = new QHBoxLayout( this );
//create main splitter
m_MainSplit = new QSplitter( this );
QmitkStdMultiWidgetLayout->addWidget( m_MainSplit );
//create m_LayoutSplit and add to the mainSplit
m_LayoutSplit = new QSplitter( m_MainSplit );
m_MainSplit->addWidget( m_LayoutSplit );
//add LevelWindow Widget to mainSplitter
m_MainSplit->addWidget( levelWindowWidget );
//create m_SubSplit1 and m_SubSplit2
m_SubSplit1 = new QSplitter( Qt::Vertical, m_LayoutSplit );
m_SubSplit2 = new QSplitter( m_LayoutSplit );
//add Widgets to splitter
m_SubSplit1->addWidget( mitkWidget1Container );
m_SubSplit1->addWidget( mitkWidget2Container );
m_SubSplit2->addWidget( mitkWidget4Container );
//set Splitter Size
QList<int> splitterSize;
splitterSize.push_back(1000);
splitterSize.push_back(1000);
m_SubSplit1->setSizes( splitterSize );
m_LayoutSplit->setSizes( splitterSize );
//show mainSplitt and add to Layout
m_MainSplit->show();
//show/hide Widgets
if ( mitkWidget1->isHidden() ) mitkWidget1->show();
if ( mitkWidget2->isHidden() ) mitkWidget2->show();
mitkWidget3->hide();
if ( mitkWidget4->isHidden() ) mitkWidget4->show();
m_Layout = LAYOUT_2X_2D_AND_3D_WIDGET;
//update Layout Design List
mitkWidget1->LayoutDesignListChanged( LAYOUT_2X_2D_AND_3D_WIDGET );
mitkWidget2->LayoutDesignListChanged( LAYOUT_2X_2D_AND_3D_WIDGET );
mitkWidget3->LayoutDesignListChanged( LAYOUT_2X_2D_AND_3D_WIDGET );
mitkWidget4->LayoutDesignListChanged( LAYOUT_2X_2D_AND_3D_WIDGET );
//update Alle Widgets
this->UpdateAllWidgets();
}
| void QmitkStdMultiWidget::changeLayoutToBig3D | ( | ) | [slot] |
Definition at line 679 of file QmitkStdMultiWidget.cpp.
References HideAllWidgetToolbars(), LAYOUT_BIG_3D, QmitkRenderWindow::LayoutDesignListChanged(), levelWindowWidget, m_Layout, m_MainSplit, mitkWidget1, mitkWidget2, mitkWidget3, mitkWidget4, mitkWidget4Container, QmitkStdMultiWidgetLayout, SMW_INFO, and UpdateAllWidgets().
Referenced by OnLayoutDesignChanged().
{
SMW_INFO << "changing layout to big 3D ..." << std::endl;
//Hide all Menu Widgets
this->HideAllWidgetToolbars();
delete QmitkStdMultiWidgetLayout ;
//create Main Layout
QmitkStdMultiWidgetLayout = new QHBoxLayout( this );
//create main splitter
m_MainSplit = new QSplitter( this );
QmitkStdMultiWidgetLayout->addWidget( m_MainSplit );
//add widget Splitter to main Splitter
m_MainSplit->addWidget( mitkWidget4Container );
//add LevelWindow Widget to mainSplitter
m_MainSplit->addWidget( levelWindowWidget );
//show mainSplitt and add to Layout
m_MainSplit->show();
//show/hide Widgets
mitkWidget1->hide();
mitkWidget2->hide();
mitkWidget3->hide();
if ( mitkWidget4->isHidden() ) mitkWidget4->show();
m_Layout = LAYOUT_BIG_3D;
//update Layout Design List
mitkWidget1->LayoutDesignListChanged( LAYOUT_BIG_3D );
mitkWidget2->LayoutDesignListChanged( LAYOUT_BIG_3D );
mitkWidget3->LayoutDesignListChanged( LAYOUT_BIG_3D );
mitkWidget4->LayoutDesignListChanged( LAYOUT_BIG_3D );
//update Alle Widgets
this->UpdateAllWidgets();
}
| void QmitkStdMultiWidget::changeLayoutToColumnWidget3And4 | ( | ) | [slot] |
Definition at line 905 of file QmitkStdMultiWidget.cpp.
References HideAllWidgetToolbars(), LAYOUT_COLUMN_WIDGET_3_AND_4, QmitkRenderWindow::LayoutDesignListChanged(), levelWindowWidget, m_Layout, m_LayoutSplit, m_MainSplit, mitkWidget1, mitkWidget2, mitkWidget3, mitkWidget3Container, mitkWidget4, mitkWidget4Container, QmitkStdMultiWidgetLayout, SMW_INFO, and UpdateAllWidgets().
Referenced by OnLayoutDesignChanged().
{
SMW_INFO << "changing layout to Widget3 and 4 in one Column..." << std::endl;
//Hide all Menu Widgets
this->HideAllWidgetToolbars();
delete QmitkStdMultiWidgetLayout ;
//create Main Layout
QmitkStdMultiWidgetLayout = new QHBoxLayout( this );
//create main splitter
m_MainSplit = new QSplitter( this );
QmitkStdMultiWidgetLayout->addWidget( m_MainSplit );
//create m_LayoutSplit and add to the mainSplit
m_LayoutSplit = new QSplitter( m_MainSplit );
m_MainSplit->addWidget( m_LayoutSplit );
//add LevelWindow Widget to mainSplitter
m_MainSplit->addWidget( levelWindowWidget );
//add Widgets to splitter
m_LayoutSplit->addWidget( mitkWidget3Container );
m_LayoutSplit->addWidget( mitkWidget4Container );
//set SplitterSize
QList<int> splitterSize;
splitterSize.push_back(1000);
splitterSize.push_back(1000);
m_LayoutSplit->setSizes( splitterSize );
//show mainSplitt and add to Layout
m_MainSplit->show();
//show/hide Widgets
mitkWidget1->hide();
mitkWidget2->hide();
if ( mitkWidget3->isHidden() ) mitkWidget3->show();
if ( mitkWidget4->isHidden() ) mitkWidget4->show();
m_Layout = LAYOUT_COLUMN_WIDGET_3_AND_4;
//update Layout Design List
mitkWidget1->LayoutDesignListChanged( LAYOUT_COLUMN_WIDGET_3_AND_4 );
mitkWidget2->LayoutDesignListChanged( LAYOUT_COLUMN_WIDGET_3_AND_4 );
mitkWidget3->LayoutDesignListChanged( LAYOUT_COLUMN_WIDGET_3_AND_4 );
mitkWidget4->LayoutDesignListChanged( LAYOUT_COLUMN_WIDGET_3_AND_4 );
//update Alle Widgets
this->UpdateAllWidgets();
}
| void QmitkStdMultiWidget::changeLayoutToDefault | ( | ) | [slot] |
Definition at line 616 of file QmitkStdMultiWidget.cpp.
References HideAllWidgetToolbars(), LAYOUT_DEFAULT, QmitkRenderWindow::LayoutDesignListChanged(), levelWindowWidget, m_Layout, m_LayoutSplit, m_MainSplit, m_SubSplit1, m_SubSplit2, mitkWidget1, mitkWidget1Container, mitkWidget2, mitkWidget2Container, mitkWidget3, mitkWidget3Container, mitkWidget4, mitkWidget4Container, QmitkStdMultiWidgetLayout, SMW_INFO, and UpdateAllWidgets().
Referenced by OnLayoutDesignChanged().
{
SMW_INFO << "changing layout to default... " << std::endl;
//Hide all Menu Widgets
this->HideAllWidgetToolbars();
delete QmitkStdMultiWidgetLayout ;
//create Main Layout
QmitkStdMultiWidgetLayout = new QHBoxLayout( this );
//create main splitter
m_MainSplit = new QSplitter( this );
QmitkStdMultiWidgetLayout->addWidget( m_MainSplit );
//create m_LayoutSplit and add to the mainSplit
m_LayoutSplit = new QSplitter( Qt::Vertical, m_MainSplit );
m_MainSplit->addWidget( m_LayoutSplit );
//add LevelWindow Widget to mainSplitter
m_MainSplit->addWidget( levelWindowWidget );
//create m_SubSplit1 and m_SubSplit2
m_SubSplit1 = new QSplitter( m_LayoutSplit );
m_SubSplit2 = new QSplitter( m_LayoutSplit );
//insert Widget container into the splitters
m_SubSplit1->addWidget( mitkWidget1Container );
m_SubSplit1->addWidget( mitkWidget2Container );
m_SubSplit2->addWidget( mitkWidget3Container );
m_SubSplit2->addWidget( mitkWidget4Container );
//set splitter Size
QList<int> splitterSize;
splitterSize.push_back(1000);
splitterSize.push_back(1000);
m_SubSplit1->setSizes( splitterSize );
m_SubSplit2->setSizes( splitterSize );
m_LayoutSplit->setSizes( splitterSize );
//show mainSplitt and add to Layout
m_MainSplit->show();
//show Widget if hidden
if ( mitkWidget1->isHidden() ) mitkWidget1->show();
if ( mitkWidget2->isHidden() ) mitkWidget2->show();
if ( mitkWidget3->isHidden() ) mitkWidget3->show();
if ( mitkWidget4->isHidden() ) mitkWidget4->show();
m_Layout = LAYOUT_DEFAULT;
//update Layout Design List
mitkWidget1->LayoutDesignListChanged( LAYOUT_DEFAULT );
mitkWidget2->LayoutDesignListChanged( LAYOUT_DEFAULT );
mitkWidget3->LayoutDesignListChanged( LAYOUT_DEFAULT );
mitkWidget4->LayoutDesignListChanged( LAYOUT_DEFAULT );
//update Alle Widgets
this->UpdateAllWidgets();
}
| void QmitkStdMultiWidget::changeLayoutToLeft2Dand3DRight2D | ( | ) | [slot] |
Definition at line 1095 of file QmitkStdMultiWidget.cpp.
References HideAllWidgetToolbars(), LAYOUT_2D_AND_3D_LEFT_2D_RIGHT_WIDGET, QmitkRenderWindow::LayoutDesignListChanged(), levelWindowWidget, m_Layout, m_LayoutSplit, m_MainSplit, m_SubSplit1, m_SubSplit2, mitkWidget1, mitkWidget1Container, mitkWidget2, mitkWidget2Container, mitkWidget3, mitkWidget4, mitkWidget4Container, QmitkStdMultiWidgetLayout, SMW_INFO, and UpdateAllWidgets().
Referenced by OnLayoutDesignChanged().
{
SMW_INFO << "changing layout to 2D and 3D left, 2D right Widget" << std::endl;
//Hide all Menu Widgets
this->HideAllWidgetToolbars();
delete QmitkStdMultiWidgetLayout ;
//create Main Layout
QmitkStdMultiWidgetLayout = new QHBoxLayout( this );
//create main splitter
m_MainSplit = new QSplitter( this );
QmitkStdMultiWidgetLayout->addWidget( m_MainSplit );
//create m_LayoutSplit and add to the mainSplit
m_LayoutSplit = new QSplitter( m_MainSplit );
m_MainSplit->addWidget( m_LayoutSplit );
//add LevelWindow Widget to mainSplitter
m_MainSplit->addWidget( levelWindowWidget );
//create m_SubSplit1 and m_SubSplit2
m_SubSplit1 = new QSplitter( Qt::Vertical, m_LayoutSplit );
m_SubSplit2 = new QSplitter( m_LayoutSplit );
//add Widgets to splitter
m_SubSplit1->addWidget( mitkWidget1Container );
m_SubSplit1->addWidget( mitkWidget4Container );
m_SubSplit2->addWidget( mitkWidget2Container );
//set Splitter Size
QList<int> splitterSize;
splitterSize.push_back(1000);
splitterSize.push_back(1000);
m_SubSplit1->setSizes( splitterSize );
m_LayoutSplit->setSizes( splitterSize );
//show mainSplitt and add to Layout
m_MainSplit->show();
//show/hide Widgets
if ( mitkWidget1->isHidden() ) mitkWidget1->show();
if ( mitkWidget2->isHidden() ) mitkWidget2->show();
mitkWidget3->hide();
if ( mitkWidget4->isHidden() ) mitkWidget4->show();
m_Layout = LAYOUT_2D_AND_3D_LEFT_2D_RIGHT_WIDGET;
//update Layout Design List
mitkWidget1->LayoutDesignListChanged( LAYOUT_2D_AND_3D_LEFT_2D_RIGHT_WIDGET );
mitkWidget2->LayoutDesignListChanged( LAYOUT_2D_AND_3D_LEFT_2D_RIGHT_WIDGET );
mitkWidget3->LayoutDesignListChanged( LAYOUT_2D_AND_3D_LEFT_2D_RIGHT_WIDGET );
mitkWidget4->LayoutDesignListChanged( LAYOUT_2D_AND_3D_LEFT_2D_RIGHT_WIDGET );
//update Alle Widgets
this->UpdateAllWidgets();
}
| void QmitkStdMultiWidget::changeLayoutToRowWidget3And4 | ( | ) | [slot] |
Definition at line 851 of file QmitkStdMultiWidget.cpp.
References HideAllWidgetToolbars(), LAYOUT_ROW_WIDGET_3_AND_4, QmitkRenderWindow::LayoutDesignListChanged(), levelWindowWidget, m_Layout, m_LayoutSplit, m_MainSplit, mitkWidget1, mitkWidget2, mitkWidget3, mitkWidget3Container, mitkWidget4, mitkWidget4Container, QmitkStdMultiWidgetLayout, SMW_INFO, and UpdateAllWidgets().
Referenced by changeLayoutToRowWidgetSmall3andBig4(), and OnLayoutDesignChanged().
{
SMW_INFO << "changing layout to Widget3 and 4 in a Row..." << std::endl;
//Hide all Menu Widgets
this->HideAllWidgetToolbars();
delete QmitkStdMultiWidgetLayout ;
//create Main Layout
QmitkStdMultiWidgetLayout = new QHBoxLayout( this );
//create main splitter
m_MainSplit = new QSplitter( this );
QmitkStdMultiWidgetLayout->addWidget( m_MainSplit );
//create m_LayoutSplit and add to the mainSplit
m_LayoutSplit = new QSplitter( Qt::Vertical, m_MainSplit );
m_MainSplit->addWidget( m_LayoutSplit );
//add LevelWindow Widget to mainSplitter
m_MainSplit->addWidget( levelWindowWidget );
//add Widgets to splitter
m_LayoutSplit->addWidget( mitkWidget3Container );
m_LayoutSplit->addWidget( mitkWidget4Container );
//set Splitter Size
QList<int> splitterSize;
splitterSize.push_back(1000);
splitterSize.push_back(1000);
m_LayoutSplit->setSizes( splitterSize );
//show mainSplitt and add to Layout
m_MainSplit->show();
//show/hide Widgets
mitkWidget1->hide();
mitkWidget2->hide();
if ( mitkWidget3->isHidden() ) mitkWidget3->show();
if ( mitkWidget4->isHidden() ) mitkWidget4->show();
m_Layout = LAYOUT_ROW_WIDGET_3_AND_4;
//update Layout Design List
mitkWidget1->LayoutDesignListChanged( LAYOUT_ROW_WIDGET_3_AND_4 );
mitkWidget2->LayoutDesignListChanged( LAYOUT_ROW_WIDGET_3_AND_4 );
mitkWidget3->LayoutDesignListChanged( LAYOUT_ROW_WIDGET_3_AND_4 );
mitkWidget4->LayoutDesignListChanged( LAYOUT_ROW_WIDGET_3_AND_4 );
//update Alle Widgets
this->UpdateAllWidgets();
}
| void QmitkStdMultiWidget::changeLayoutToRowWidgetSmall3andBig4 | ( | ) | [slot] |
Definition at line 959 of file QmitkStdMultiWidget.cpp.
References changeLayoutToRowWidget3And4(), LAYOUT_ROW_WIDGET_SMALL3_AND_BIG4, m_Layout, and SMW_INFO.
Referenced by OnLayoutDesignChanged().
{
SMW_INFO << "changing layout to Widget3 and 4 in a Row..." << std::endl;
this->changeLayoutToRowWidget3And4();
m_Layout = LAYOUT_ROW_WIDGET_SMALL3_AND_BIG4;
}
| void QmitkStdMultiWidget::changeLayoutToSmallUpperWidget2Big3and4 | ( | ) | [slot] |
Definition at line 969 of file QmitkStdMultiWidget.cpp.
References HideAllWidgetToolbars(), LAYOUT_SMALL_UPPER_WIDGET2_BIG3_AND4, QmitkRenderWindow::LayoutDesignListChanged(), levelWindowWidget, m_Layout, m_LayoutSplit, m_MainSplit, m_SubSplit1, m_SubSplit2, mitkWidget1, mitkWidget2, mitkWidget2Container, mitkWidget3, mitkWidget3Container, mitkWidget4, mitkWidget4Container, QmitkStdMultiWidgetLayout, SMW_INFO, and UpdateAllWidgets().
Referenced by OnLayoutDesignChanged().
{
SMW_INFO << "changing layout to Widget3 and 4 in a Row..." << std::endl;
//Hide all Menu Widgets
this->HideAllWidgetToolbars();
delete QmitkStdMultiWidgetLayout ;
//create Main Layout
QmitkStdMultiWidgetLayout = new QHBoxLayout( this );
//create main splitter
m_MainSplit = new QSplitter( this );
QmitkStdMultiWidgetLayout->addWidget( m_MainSplit );
//create m_LayoutSplit and add to the mainSplit
m_LayoutSplit = new QSplitter( Qt::Vertical, m_MainSplit );
m_MainSplit->addWidget( m_LayoutSplit );
//add LevelWindow Widget to mainSplitter
m_MainSplit->addWidget( levelWindowWidget );
//create m_SubSplit1 and m_SubSplit2
m_SubSplit1 = new QSplitter( Qt::Vertical, m_LayoutSplit );
m_SubSplit2 = new QSplitter( m_LayoutSplit );
//insert Widget into the splitters
m_SubSplit1->addWidget( mitkWidget2Container );
m_SubSplit2->addWidget( mitkWidget3Container );
m_SubSplit2->addWidget( mitkWidget4Container );
//set Splitter Size
QList<int> splitterSize;
splitterSize.push_back(1000);
splitterSize.push_back(1000);
m_SubSplit2->setSizes( splitterSize );
splitterSize.clear();
splitterSize.push_back(500);
splitterSize.push_back(1000);
m_LayoutSplit->setSizes( splitterSize );
//show mainSplitt
m_MainSplit->show();
//show Widget if hidden
mitkWidget1->hide();
if ( mitkWidget2->isHidden() ) mitkWidget2->show();
if ( mitkWidget3->isHidden() ) mitkWidget3->show();
if ( mitkWidget4->isHidden() ) mitkWidget4->show();
m_Layout = LAYOUT_SMALL_UPPER_WIDGET2_BIG3_AND4;
//update Layout Design List
mitkWidget1->LayoutDesignListChanged( LAYOUT_SMALL_UPPER_WIDGET2_BIG3_AND4 );
mitkWidget2->LayoutDesignListChanged( LAYOUT_SMALL_UPPER_WIDGET2_BIG3_AND4 );
mitkWidget3->LayoutDesignListChanged( LAYOUT_SMALL_UPPER_WIDGET2_BIG3_AND4 );
mitkWidget4->LayoutDesignListChanged( LAYOUT_SMALL_UPPER_WIDGET2_BIG3_AND4 );
//update Alle Widgets
this->UpdateAllWidgets();
}
| void QmitkStdMultiWidget::changeLayoutToWidget1 | ( | ) | [slot] |
Definition at line 722 of file QmitkStdMultiWidget.cpp.
References HideAllWidgetToolbars(), LAYOUT_WIDGET1, QmitkRenderWindow::LayoutDesignListChanged(), levelWindowWidget, m_Layout, m_MainSplit, mitkWidget1, mitkWidget1Container, mitkWidget2, mitkWidget3, mitkWidget4, QmitkStdMultiWidgetLayout, SMW_INFO, and UpdateAllWidgets().
Referenced by OnLayoutDesignChanged().
{
SMW_INFO << "changing layout to big Widget1 ..." << std::endl;
//Hide all Menu Widgets
this->HideAllWidgetToolbars();
delete QmitkStdMultiWidgetLayout ;
//create Main Layout
QmitkStdMultiWidgetLayout = new QHBoxLayout( this );
//create main splitter
m_MainSplit = new QSplitter( this );
QmitkStdMultiWidgetLayout->addWidget( m_MainSplit );
//add widget Splitter to main Splitter
m_MainSplit->addWidget( mitkWidget1Container );
//add LevelWindow Widget to mainSplitter
m_MainSplit->addWidget( levelWindowWidget );
//show mainSplitt and add to Layout
m_MainSplit->show();
//show/hide Widgets
if ( mitkWidget1->isHidden() ) mitkWidget1->show();
mitkWidget2->hide();
mitkWidget3->hide();
mitkWidget4->hide();
m_Layout = LAYOUT_WIDGET1;
//update Layout Design List
mitkWidget1->LayoutDesignListChanged( LAYOUT_WIDGET1 );
mitkWidget2->LayoutDesignListChanged( LAYOUT_WIDGET1 );
mitkWidget3->LayoutDesignListChanged( LAYOUT_WIDGET1 );
mitkWidget4->LayoutDesignListChanged( LAYOUT_WIDGET1 );
//update Alle Widgets
this->UpdateAllWidgets();
}
| void QmitkStdMultiWidget::changeLayoutToWidget2 | ( | ) | [slot] |
Definition at line 765 of file QmitkStdMultiWidget.cpp.
References HideAllWidgetToolbars(), LAYOUT_WIDGET2, QmitkRenderWindow::LayoutDesignListChanged(), levelWindowWidget, m_Layout, m_MainSplit, mitkWidget1, mitkWidget2, mitkWidget2Container, mitkWidget3, mitkWidget4, QmitkStdMultiWidgetLayout, SMW_INFO, and UpdateAllWidgets().
Referenced by OnLayoutDesignChanged().
{
SMW_INFO << "changing layout to big Widget2 ..." << std::endl;
//Hide all Menu Widgets
this->HideAllWidgetToolbars();
delete QmitkStdMultiWidgetLayout ;
//create Main Layout
QmitkStdMultiWidgetLayout = new QHBoxLayout( this );
//create main splitter
m_MainSplit = new QSplitter( this );
QmitkStdMultiWidgetLayout->addWidget( m_MainSplit );
//add widget Splitter to main Splitter
m_MainSplit->addWidget( mitkWidget2Container );
//add LevelWindow Widget to mainSplitter
m_MainSplit->addWidget( levelWindowWidget );
//show mainSplitt and add to Layout
m_MainSplit->show();
//show/hide Widgets
mitkWidget1->hide();
if ( mitkWidget2->isHidden() ) mitkWidget2->show();
mitkWidget3->hide();
mitkWidget4->hide();
m_Layout = LAYOUT_WIDGET2;
//update Layout Design List
mitkWidget1->LayoutDesignListChanged( LAYOUT_WIDGET2 );
mitkWidget2->LayoutDesignListChanged( LAYOUT_WIDGET2 );
mitkWidget3->LayoutDesignListChanged( LAYOUT_WIDGET2 );
mitkWidget4->LayoutDesignListChanged( LAYOUT_WIDGET2 );
//update Alle Widgets
this->UpdateAllWidgets();
}
| void QmitkStdMultiWidget::changeLayoutToWidget3 | ( | ) | [slot] |
Definition at line 808 of file QmitkStdMultiWidget.cpp.
References HideAllWidgetToolbars(), LAYOUT_WIDGET3, QmitkRenderWindow::LayoutDesignListChanged(), levelWindowWidget, m_Layout, m_MainSplit, mitkWidget1, mitkWidget2, mitkWidget3, mitkWidget3Container, mitkWidget4, QmitkStdMultiWidgetLayout, SMW_INFO, and UpdateAllWidgets().
Referenced by OnLayoutDesignChanged().
{
SMW_INFO << "changing layout to big Widget3 ..." << std::endl;
//Hide all Menu Widgets
this->HideAllWidgetToolbars();
delete QmitkStdMultiWidgetLayout ;
//create Main Layout
QmitkStdMultiWidgetLayout = new QHBoxLayout( this );
//create main splitter
m_MainSplit = new QSplitter( this );
QmitkStdMultiWidgetLayout->addWidget( m_MainSplit );
//add widget Splitter to main Splitter
m_MainSplit->addWidget( mitkWidget3Container );
//add LevelWindow Widget to mainSplitter
m_MainSplit->addWidget( levelWindowWidget );
//show mainSplitt and add to Layout
m_MainSplit->show();
//show/hide Widgets
mitkWidget1->hide();
mitkWidget2->hide();
if ( mitkWidget3->isHidden() ) mitkWidget3->show();
mitkWidget4->hide();
m_Layout = LAYOUT_WIDGET3;
//update Layout Design List
mitkWidget1->LayoutDesignListChanged( LAYOUT_WIDGET3 );
mitkWidget2->LayoutDesignListChanged( LAYOUT_WIDGET3 );
mitkWidget3->LayoutDesignListChanged( LAYOUT_WIDGET3 );
mitkWidget4->LayoutDesignListChanged( LAYOUT_WIDGET3 );
//update Alle Widgets
this->UpdateAllWidgets();
}
| void QmitkStdMultiWidget::DisableColoredRectangles | ( | ) | [slot] |
Definition at line 2015 of file QmitkStdMultiWidget.cpp.
References m_RectangleRendering1, m_RectangleRendering2, m_RectangleRendering3, and m_RectangleRendering4.
Referenced by QmitkSimpleExampleView::TakeScreenshot().
{
m_RectangleRendering1->Disable();
m_RectangleRendering2->Disable();
m_RectangleRendering3->Disable();
m_RectangleRendering4->Disable();
}| void QmitkStdMultiWidget::DisableDepartmentLogo | ( | ) | [slot] |
Definition at line 1666 of file QmitkStdMultiWidget.cpp.
References m_LogoRendering4.
Referenced by QmitkStdMultiWidgetEditor::CreateQtPartControl(), QmitkSimpleExampleView::stereoSelectionChanged(), and QmitkSimpleExampleView::TakeScreenshot().
{
m_LogoRendering4->Disable();
}
| void QmitkStdMultiWidget::DisableGradientBackground | ( | ) | [slot] |
Definition at line 1651 of file QmitkStdMultiWidget.cpp.
References m_GradientBackground4.
Referenced by QmitkOpenCVVideoControls::on_PlayButton_clicked(), and QmitkSimpleExampleView::TakeScreenshot().
{
//m_GradientBackground1->Disable();
//m_GradientBackground2->Disable();
//m_GradientBackground3->Disable();
m_GradientBackground4->Disable();
}
| void QmitkStdMultiWidget::DisableNavigationControllerEventListening | ( | ) | [slot] |
Definition at line 1604 of file QmitkStdMultiWidget.cpp.
References mitk::GlobalInteraction::GetInstance(), mitk::RenderWindowBase::GetSliceNavigationController(), m_PlaneMode, m_SlicesRotator, m_SlicesSwiveller, m_TimeNavigationController, mitkWidget1, mitkWidget2, mitkWidget3, mitkWidget4, PLANE_MODE_ROTATION, PLANE_MODE_SLICING, PLANE_MODE_SWIVEL, and mitk::GlobalInteraction::RemoveListener().
Referenced by QmitkSegmentationView::ManualToolSelected(), and ~QmitkStdMultiWidget().
{
// Do not let NavigationControllers listen to GlobalInteraction
mitk::GlobalInteraction *gi = mitk::GlobalInteraction::GetInstance();
switch ( m_PlaneMode )
{
default:
case PLANE_MODE_SLICING:
gi->RemoveListener( mitkWidget1->GetSliceNavigationController() );
gi->RemoveListener( mitkWidget2->GetSliceNavigationController() );
gi->RemoveListener( mitkWidget3->GetSliceNavigationController() );
gi->RemoveListener( mitkWidget4->GetSliceNavigationController() );
break;
case PLANE_MODE_ROTATION:
m_SlicesRotator->ResetMouseCursor();
gi->RemoveListener( m_SlicesRotator );
break;
case PLANE_MODE_SWIVEL:
m_SlicesSwiveller->ResetMouseCursor();
gi->RemoveListener( m_SlicesSwiveller );
break;
}
gi->RemoveListener( m_TimeNavigationController );
}
| void QmitkStdMultiWidget::DisablePositionTracking | ( | ) |
Definition at line 1479 of file QmitkStdMultiWidget.cpp.
References mitk::GlobalInteraction::GetInstance(), m_DataStorage, m_PositionTracker, m_PositionTrackerNode, and mitk::GlobalInteraction::RemoveListener().
Referenced by ~QmitkStdMultiWidget().
{
mitk::GlobalInteraction* globalInteraction =
mitk::GlobalInteraction::GetInstance();
if(globalInteraction)
{
if (m_DataStorage.IsNotNull())
m_DataStorage->Remove(m_PositionTrackerNode);
globalInteraction->RemoveListener(m_PositionTracker);
}
}
| void QmitkStdMultiWidget::DisableStandardLevelWindow | ( | ) | [slot] |
Definition at line 1342 of file QmitkStdMultiWidget.cpp.
References levelWindowWidget.
{
levelWindowWidget->disconnect(this);
levelWindowWidget->hide();
}
| void QmitkStdMultiWidget::EnableColoredRectangles | ( | ) | [slot] |
Definition at line 2007 of file QmitkStdMultiWidget.cpp.
References m_RectangleRendering1, m_RectangleRendering2, m_RectangleRendering3, and m_RectangleRendering4.
Referenced by QmitkSimpleExampleView::TakeScreenshot().
{
m_RectangleRendering1->Enable(1.0, 0.0, 0.0);
m_RectangleRendering2->Enable(0.0, 1.0, 0.0);
m_RectangleRendering3->Enable(0.0, 0.0, 1.0);
m_RectangleRendering4->Enable(1.0, 1.0, 0.0);
}
| void QmitkStdMultiWidget::EnableDepartmentLogo | ( | ) | [slot] |
Definition at line 1660 of file QmitkStdMultiWidget.cpp.
References m_LogoRendering4.
Referenced by QmitkStdMultiWidgetEditor::CreateQtPartControl(), and QmitkSimpleExampleView::TakeScreenshot().
{
m_LogoRendering4->Enable();
}
| void QmitkStdMultiWidget::EnableGradientBackground | ( | ) | [slot] |
Definition at line 1640 of file QmitkStdMultiWidget.cpp.
References m_GradientBackground4.
Referenced by QmitkOpenCVVideoControls::Stop(), and QmitkSimpleExampleView::TakeScreenshot().
{
// gradient background is by default only in widget 4, otherwise
// interferences between 2D rendering and VTK rendering may occur.
//m_GradientBackground1->Enable();
//m_GradientBackground2->Enable();
//m_GradientBackground3->Enable();
m_GradientBackground4->Enable();
}
| void QmitkStdMultiWidget::EnableNavigationControllerEventListening | ( | ) | [slot] |
Definition at line 1577 of file QmitkStdMultiWidget.cpp.
References mitk::GlobalInteraction::AddListener(), mitk::GlobalInteraction::GetInstance(), mitk::RenderWindowBase::GetSliceNavigationController(), m_PlaneMode, m_SlicesRotator, m_SlicesSwiveller, m_TimeNavigationController, mitkWidget1, mitkWidget2, mitkWidget3, mitkWidget4, PLANE_MODE_ROTATION, PLANE_MODE_SLICING, and PLANE_MODE_SWIVEL.
Referenced by QmitkStdMultiWidgetEditor::CreateQtPartControl(), QmitkSegmentationView::ManualToolSelected(), and Step8::SetupWidgets().
{
// Let NavigationControllers listen to GlobalInteraction
mitk::GlobalInteraction *gi = mitk::GlobalInteraction::GetInstance();
switch ( m_PlaneMode )
{
default:
case PLANE_MODE_SLICING:
gi->AddListener( mitkWidget1->GetSliceNavigationController() );
gi->AddListener( mitkWidget2->GetSliceNavigationController() );
gi->AddListener( mitkWidget3->GetSliceNavigationController() );
gi->AddListener( mitkWidget4->GetSliceNavigationController() );
break;
case PLANE_MODE_ROTATION:
gi->AddListener( m_SlicesRotator );
break;
case PLANE_MODE_SWIVEL:
gi->AddListener( m_SlicesSwiveller );
break;
}
gi->AddListener( m_TimeNavigationController );
}
| void QmitkStdMultiWidget::EnablePositionTracking | ( | ) |
Definition at line 1463 of file QmitkStdMultiWidget.cpp.
References mitk::GlobalInteraction::AddListener(), mitk::GlobalInteraction::GetInstance(), m_DataStorage, m_PositionTracker, m_PositionTrackerNode, and mitk::PositionTracker::New().
{
if (!m_PositionTracker)
{
m_PositionTracker = mitk::PositionTracker::New("PositionTracker", NULL);
}
mitk::GlobalInteraction* globalInteraction = mitk::GlobalInteraction::GetInstance();
if (globalInteraction)
{
if(m_DataStorage.IsNotNull())
m_DataStorage->Add(m_PositionTrackerNode);
globalInteraction->AddListener(m_PositionTracker);
}
}
| void QmitkStdMultiWidget::EnableStandardLevelWindow | ( | ) | [slot] |
Definition at line 1334 of file QmitkStdMultiWidget.cpp.
References mitk::BaseRenderer::GetInstance(), levelWindowWidget, mitkWidget1, and QmitkLevelWindowWidget::SetDataStorage().
Referenced by QmitkStdMultiWidgetEditor::CreateQtPartControl(), and Step8::SetupWidgets().
{
levelWindowWidget->disconnect(this);
levelWindowWidget->SetDataStorage(mitk::BaseRenderer::GetInstance(mitkWidget1->GetRenderWindow())->GetDataStorage());
levelWindowWidget->show();
}
| void QmitkStdMultiWidget::EnsureDisplayContainsPoint | ( | mitk::DisplayGeometry * | displayGeometry, |
| const mitk::Point3D & | p | ||
| ) | [slot] |
Definition at line 1493 of file QmitkStdMultiWidget.cpp.
References mitk::DisplayGeometry::GetOriginInMM(), mitk::DisplayGeometry::GetScaleFactorMMPerDisplayUnit(), mitk::DisplayGeometry::GetSizeInMM(), mitk::DisplayGeometry::Map(), and mitk::DisplayGeometry::MoveBy().
Referenced by MoveCrossToPosition().
{
mitk::Point2D pointOnPlane;
displayGeometry->Map( p, pointOnPlane );
// point minus origin < width or height ==> outside ?
mitk::Vector2D pointOnRenderWindow_MM;
pointOnRenderWindow_MM = pointOnPlane.GetVectorFromOrigin()
- displayGeometry->GetOriginInMM();
mitk::Vector2D sizeOfDisplay( displayGeometry->GetSizeInMM() );
if ( sizeOfDisplay[0] < pointOnRenderWindow_MM[0]
|| 0 > pointOnRenderWindow_MM[0]
|| sizeOfDisplay[1] < pointOnRenderWindow_MM[1]
|| 0 > pointOnRenderWindow_MM[1] )
{
// point is not visible -> move geometry
mitk::Vector2D offset( (pointOnRenderWindow_MM - sizeOfDisplay / 2.0)
/ displayGeometry->GetScaleFactorMMPerDisplayUnit() );
displayGeometry->MoveBy( offset );
}
}
| void QmitkStdMultiWidget::Fit | ( | ) | [slot] |
Definition at line 1238 of file QmitkStdMultiWidget.cpp.
References mitk::BaseRenderer::GetInstance(), mitkWidget1, mitkWidget2, mitkWidget3, and mitkWidget4.
{
vtkRenderer * vtkrenderer;
mitk::BaseRenderer::GetInstance(mitkWidget1->GetRenderWindow())->GetDisplayGeometry()->Fit();
mitk::BaseRenderer::GetInstance(mitkWidget2->GetRenderWindow())->GetDisplayGeometry()->Fit();
mitk::BaseRenderer::GetInstance(mitkWidget3->GetRenderWindow())->GetDisplayGeometry()->Fit();
mitk::BaseRenderer::GetInstance(mitkWidget4->GetRenderWindow())->GetDisplayGeometry()->Fit();
int w = vtkObject::GetGlobalWarningDisplay();
vtkObject::GlobalWarningDisplayOff();
vtkrenderer = mitk::BaseRenderer::GetInstance(mitkWidget1->GetRenderWindow())->GetVtkRenderer();
if ( vtkrenderer!= NULL )
vtkrenderer->ResetCamera();
vtkrenderer = mitk::BaseRenderer::GetInstance(mitkWidget2->GetRenderWindow())->GetVtkRenderer();
if ( vtkrenderer!= NULL )
vtkrenderer->ResetCamera();
vtkrenderer = mitk::BaseRenderer::GetInstance(mitkWidget3->GetRenderWindow())->GetVtkRenderer();
if ( vtkrenderer!= NULL )
vtkrenderer->ResetCamera();
vtkrenderer = mitk::BaseRenderer::GetInstance(mitkWidget4->GetRenderWindow())->GetVtkRenderer();
if ( vtkrenderer!= NULL )
vtkrenderer->ResetCamera();
vtkObject::SetGlobalWarningDisplay(w);
}
| void QmitkStdMultiWidget::ForceImmediateUpdate | ( | ) |
Definition at line 1366 of file QmitkStdMultiWidget.cpp.
References mitk::RenderingManager::GetInstance(), mitkWidget1, mitkWidget2, mitkWidget3, and mitkWidget4.
{
mitk::RenderingManager::GetInstance()->ForceImmediateUpdate(mitkWidget1->GetRenderWindow());
mitk::RenderingManager::GetInstance()->ForceImmediateUpdate(mitkWidget2->GetRenderWindow());
mitk::RenderingManager::GetInstance()->ForceImmediateUpdate(mitkWidget3->GetRenderWindow());
mitk::RenderingManager::GetInstance()->ForceImmediateUpdate(mitkWidget4->GetRenderWindow());
}
| const mitk::Point3D QmitkStdMultiWidget::GetCrossPosition | ( | ) | const |
Definition at line 1439 of file QmitkStdMultiWidget.cpp.
References mitk::SliceNavigationController::GetCurrentPlaneGeometry(), mitk::RenderWindowBase::GetSliceNavigationController(), mitk::PlaneGeometry::IntersectionLine(), mitk::PlaneGeometry::IntersectionPoint(), m_LastLeftClickPositionSupplier, mitkWidget1, mitkWidget2, and mitkWidget3.
{
const mitk::PlaneGeometry *plane1 =
mitkWidget1->GetSliceNavigationController()->GetCurrentPlaneGeometry();
const mitk::PlaneGeometry *plane2 =
mitkWidget2->GetSliceNavigationController()->GetCurrentPlaneGeometry();
const mitk::PlaneGeometry *plane3 =
mitkWidget3->GetSliceNavigationController()->GetCurrentPlaneGeometry();
mitk::Line3D line;
if ( (plane1 != NULL) && (plane2 != NULL)
&& (plane1->IntersectionLine( plane2, line )) )
{
mitk::Point3D point;
if ( (plane3 != NULL)
&& (plane3->IntersectionPoint( line, point )) )
{
return point;
}
}
return m_LastLeftClickPositionSupplier->GetCurrentPoint();
}
| const mitk::Point3D & QmitkStdMultiWidget::GetLastLeftClickPosition | ( | ) | const |
Definition at line 1433 of file QmitkStdMultiWidget.cpp.
References m_LastLeftClickPositionSupplier.
Referenced by mousePressEvent().
{
return m_LastLeftClickPositionSupplier->GetCurrentPoint();
}
| int QmitkStdMultiWidget::GetLayout | ( | ) | const |
| mitk::DisplayVectorInteractor * QmitkStdMultiWidget::GetMoveAndZoomInteractor | ( | ) |
Definition at line 1403 of file QmitkStdMultiWidget.cpp.
References m_MoveAndZoomInteractor.
Referenced by QmitkStdMultiWidgetEditor::CreateQtPartControl(), and Step8::SetupWidgets().
{
return m_MoveAndZoomInteractor.GetPointer();
}
| QmitkRenderWindow * QmitkStdMultiWidget::GetRenderWindow1 | ( | ) | const |
Definition at line 1409 of file QmitkStdMultiWidget.cpp.
References mitkWidget1.
Referenced by QmitkSegmentationView::CheckImageAlignment(), InitializeWidget(), QmitkMeasurement::PlanarFigureSelectionChanged(), SetWidgetPlanesLocked(), SetWidgetPlanesRotationLocked(), and ~QmitkStdMultiWidget().
{
return mitkWidget1;
}
| QmitkRenderWindow * QmitkStdMultiWidget::GetRenderWindow2 | ( | ) | const |
Definition at line 1415 of file QmitkStdMultiWidget.cpp.
References mitkWidget2.
Referenced by QmitkSegmentationView::CheckImageAlignment(), InitializeWidget(), QmitkMeasurement::PlanarFigureSelectionChanged(), SetWidgetPlanesLocked(), SetWidgetPlanesRotationLocked(), and ~QmitkStdMultiWidget().
{
return mitkWidget2;
}
| QmitkRenderWindow * QmitkStdMultiWidget::GetRenderWindow3 | ( | ) | const |
Definition at line 1421 of file QmitkStdMultiWidget.cpp.
References mitkWidget3.
Referenced by QmitkSegmentationView::CheckImageAlignment(), InitializeWidget(), QmitkMeasurement::PlanarFigureSelectionChanged(), SetWidgetPlanesLocked(), SetWidgetPlanesRotationLocked(), and ~QmitkStdMultiWidget().
{
return mitkWidget3;
}
| QmitkRenderWindow * QmitkStdMultiWidget::GetRenderWindow4 | ( | ) | const |
Definition at line 1427 of file QmitkStdMultiWidget.cpp.
References mitkWidget4.
Referenced by QmitkStdMultiWidgetEditor::CreateQtPartControl(), QmitkOpenCVVideoControls::on_PlayButton_clicked(), QmitkMeasurement::PlanarFigureSelectionChanged(), Step8::SetupWidgets(), and QmitkOpenCVVideoControls::Stop().
{
return mitkWidget4;
}
| mitk::SlicesRotator * QmitkStdMultiWidget::GetSlicesRotator | ( | ) | const |
Definition at line 1672 of file QmitkStdMultiWidget.cpp.
References m_SlicesRotator.
Referenced by QmitkSegmentationView::SetMultiWidget().
{
return m_SlicesRotator;
}
| mitk::SlicesSwiveller * QmitkStdMultiWidget::GetSlicesSwiveller | ( | ) | const |
Definition at line 1678 of file QmitkStdMultiWidget.cpp.
References m_SlicesSwiveller.
Referenced by QmitkSegmentationView::SetMultiWidget().
{
return m_SlicesSwiveller;
}
| mitk::SliceNavigationController * QmitkStdMultiWidget::GetTimeNavigationController | ( | ) |
Definition at line 1328 of file QmitkStdMultiWidget.cpp.
References m_TimeNavigationController.
Referenced by QmitkImageNavigatorView::CreateQtPartControl(), QmitkRigidRegistrationView::FixedSelected(), QmitkSimpleExampleView::StdMultiWidgetAvailable(), and QmitkImageStatistics::UpdateStatistics().
{
return m_TimeNavigationController.GetPointer();
}
| void QmitkStdMultiWidget::HideAllWidgetToolbars | ( | ) | [protected] |
Definition at line 1981 of file QmitkStdMultiWidget.cpp.
References QmitkRenderWindow::HideRenderWindowMenu(), mitkWidget1, mitkWidget2, mitkWidget3, and mitkWidget4.
Referenced by changeLayoutTo2DImagesLeft(), changeLayoutTo2DImagesUp(), changeLayoutTo2DUpAnd3DDown(), changeLayoutTo2x2Dand3DWidget(), changeLayoutToBig3D(), changeLayoutToColumnWidget3And4(), changeLayoutToDefault(), changeLayoutToLeft2Dand3DRight2D(), changeLayoutToRowWidget3And4(), changeLayoutToSmallUpperWidget2Big3and4(), changeLayoutToWidget1(), changeLayoutToWidget2(), and changeLayoutToWidget3().
| bool QmitkStdMultiWidget::InitializeStandardViews | ( | const mitk::Geometry3D * | geometry ) | [slot] |
Definition at line 1351 of file QmitkStdMultiWidget.cpp.
References mitk::RenderingManager::GetInstance().
{
return mitk::RenderingManager::GetInstance()->InitializeViews( geometry );
}
| void QmitkStdMultiWidget::InitializeWidget | ( | ) |
Definition at line 197 of file QmitkStdMultiWidget.cpp.
References mitk::SliceNavigationController::ConnectGeometrySendEvent(), mitk::SliceNavigationController::ConnectGeometryTimeEvent(), cornerText, mitk::SliceNavigationController::Frontal, mitk::GlobalInteraction::GetInstance(), mitk::RenderingManager::GetInstance(), mitk::VtkLayerController::GetInstance(), mitk::BaseRenderer::GetInstance(), GetRenderWindow1(), GetRenderWindow2(), GetRenderWindow3(), mitk::RenderWindowBase::GetSliceNavigationController(), m_CornerAnnotaions, m_GradientBackground1, m_GradientBackground2, m_GradientBackground3, m_GradientBackground4, m_LastLeftClickPositionSupplier, m_LogoRendering1, m_LogoRendering2, m_LogoRendering3, m_LogoRendering4, m_MoveAndZoomInteractor, m_PlaneMode, m_PositionTracker, m_RectangleRendering1, m_RectangleRendering2, m_RectangleRendering3, m_RectangleRendering4, m_SlicesRotator, m_SlicesSwiveller, m_TimeNavigationController, mitkWidget1, mitkWidget2, mitkWidget3, mitkWidget4, mitk::RenderWindowFrame::New(), mitk::ManufacturerLogo::New(), mitk::GradientBackground::New(), mitk::CoordinateSupplier::New(), mitk::DisplayVectorInteractor::New(), mitk::SliceNavigationController::New(), mitk::SlicesSwiveller::New(), mitk::SlicesRotator::New(), mitk::IntProperty::New(), mitk::SliceNavigationController::Original, PLANE_MODE_SLICING, ren, mitk::SliceNavigationController::Sagittal, mitk::SliceNavigationController::SetDefaultViewDirection(), mitk::BaseRenderer::Standard3D, textProp, and mitk::SliceNavigationController::Transversal.
Referenced by QmitkStdMultiWidget().
{
m_PositionTracker = NULL;
// transfer colors in WorldGeometry-Nodes of the associated Renderer
QColor qcolor;
//float color[3] = {1.0f,1.0f,1.0f};
mitk::DataNode::Pointer planeNode;
mitk::IntProperty::Pointer layer;
// of widget 1
planeNode = mitk::BaseRenderer::GetInstance(mitkWidget1->GetRenderWindow())->GetCurrentWorldGeometry2DNode();
planeNode->SetColor(1.0,0.0,0.0);
layer = mitk::IntProperty::New(1000);
planeNode->SetProperty("layer",layer);
// ... of widget 2
planeNode = mitk::BaseRenderer::GetInstance(mitkWidget2->GetRenderWindow())->GetCurrentWorldGeometry2DNode();
planeNode->SetColor(0.0,1.0,0.0);
layer = mitk::IntProperty::New(1000);
planeNode->SetProperty("layer",layer);
// ... of widget 3
planeNode = mitk::BaseRenderer::GetInstance(mitkWidget3->GetRenderWindow())->GetCurrentWorldGeometry2DNode();
planeNode->SetColor(0.0,0.0,1.0);
layer = mitk::IntProperty::New(1000);
planeNode->SetProperty("layer",layer);
// ... of widget 4
planeNode = mitk::BaseRenderer::GetInstance(mitkWidget4->GetRenderWindow())->GetCurrentWorldGeometry2DNode();
planeNode->SetColor(1.0,1.0,0.0);
layer = mitk::IntProperty::New(1000);
planeNode->SetProperty("layer",layer);
mitk::BaseRenderer::GetInstance(mitkWidget4->GetRenderWindow())->SetMapperID(mitk::BaseRenderer::Standard3D);
// Set plane mode (slicing/rotation behavior) to slicing (default)
m_PlaneMode = PLANE_MODE_SLICING;
// Set default view directions for SNCs
mitkWidget1->GetSliceNavigationController()->SetDefaultViewDirection(
mitk::SliceNavigationController::Transversal );
mitkWidget2->GetSliceNavigationController()->SetDefaultViewDirection(
mitk::SliceNavigationController::Sagittal );
mitkWidget3->GetSliceNavigationController()->SetDefaultViewDirection(
mitk::SliceNavigationController::Frontal );
mitkWidget4->GetSliceNavigationController()->SetDefaultViewDirection(
mitk::SliceNavigationController::Original );
/*************************************************/
//Write Layout Names into the viewers -- hardCoded
//Info for later:
//int view = this->GetRenderWindow1()->GetSliceNavigationController()->GetDefaultViewDirection();
//QString layoutName;
//if( view == mitk::SliceNavigationController::Transversal )
// layoutName = "Transversal";
//else if( view == mitk::SliceNavigationController::Sagittal )
// layoutName = "Sagittal";
//else if( view == mitk::SliceNavigationController::Frontal )
// layoutName = "Coronal";
//else if( view == mitk::SliceNavigationController::Original )
// layoutName = "Original";
//if( view >= 0 && view < 4 )
// //write LayoutName --> Viewer 3D shoudn't write the layoutName.
//Render Window 1 == transversal
m_CornerAnnotaions[0].cornerText = vtkCornerAnnotation::New();
m_CornerAnnotaions[0].cornerText->SetText(0, "Transversal");
m_CornerAnnotaions[0].cornerText->SetMaximumFontSize(12);
m_CornerAnnotaions[0].textProp = vtkTextProperty::New();
m_CornerAnnotaions[0].textProp->SetColor( 1.0, 0.0, 0.0 );
m_CornerAnnotaions[0].cornerText->SetTextProperty( m_CornerAnnotaions[0].textProp );
m_CornerAnnotaions[0].ren = vtkRenderer::New();
m_CornerAnnotaions[0].ren->AddActor(m_CornerAnnotaions[0].cornerText);
mitk::VtkLayerController::GetInstance(this->GetRenderWindow1()->GetRenderWindow())->InsertForegroundRenderer(m_CornerAnnotaions[0].ren,true);
//Render Window 2 == sagittal
m_CornerAnnotaions[1].cornerText = vtkCornerAnnotation::New();
m_CornerAnnotaions[1].cornerText->SetText(0, "Sagittal");
m_CornerAnnotaions[1].cornerText->SetMaximumFontSize(12);
m_CornerAnnotaions[1].textProp = vtkTextProperty::New();
m_CornerAnnotaions[1].textProp->SetColor( 0.0, 1.0, 0.0 );
m_CornerAnnotaions[1].cornerText->SetTextProperty( m_CornerAnnotaions[1].textProp );
m_CornerAnnotaions[1].ren = vtkRenderer::New();
m_CornerAnnotaions[1].ren->AddActor(m_CornerAnnotaions[1].cornerText);
mitk::VtkLayerController::GetInstance(this->GetRenderWindow2()->GetRenderWindow())->InsertForegroundRenderer(m_CornerAnnotaions[1].ren,true);
//Render Window 3 == coronal
m_CornerAnnotaions[2].cornerText = vtkCornerAnnotation::New();
m_CornerAnnotaions[2].cornerText->SetText(0, "Coronal");
m_CornerAnnotaions[2].cornerText->SetMaximumFontSize(12);
m_CornerAnnotaions[2].textProp = vtkTextProperty::New();
m_CornerAnnotaions[2].textProp->SetColor( 0.295, 0.295, 1.0 );
m_CornerAnnotaions[2].cornerText->SetTextProperty( m_CornerAnnotaions[2].textProp );
m_CornerAnnotaions[2].ren = vtkRenderer::New();
m_CornerAnnotaions[2].ren->AddActor(m_CornerAnnotaions[2].cornerText);
mitk::VtkLayerController::GetInstance(this->GetRenderWindow3()->GetRenderWindow())->InsertForegroundRenderer(m_CornerAnnotaions[2].ren,true);
/*************************************************/
// create a slice rotator
// m_SlicesRotator = mitk::SlicesRotator::New();
// @TODO next line causes sure memory leak
// rotator will be created nonetheless (will be switched on and off)
m_SlicesRotator = mitk::SlicesRotator::New("slices-rotator");
m_SlicesRotator->AddSliceController(
mitkWidget1->GetSliceNavigationController() );
m_SlicesRotator->AddSliceController(
mitkWidget2->GetSliceNavigationController() );
m_SlicesRotator->AddSliceController(
mitkWidget3->GetSliceNavigationController() );
// create a slice swiveller (using the same state-machine as SlicesRotator)
m_SlicesSwiveller = mitk::SlicesSwiveller::New("slices-rotator");
m_SlicesSwiveller->AddSliceController(
mitkWidget1->GetSliceNavigationController() );
m_SlicesSwiveller->AddSliceController(
mitkWidget2->GetSliceNavigationController() );
m_SlicesSwiveller->AddSliceController(
mitkWidget3->GetSliceNavigationController() );
//initialize m_TimeNavigationController: send time via sliceNavigationControllers
m_TimeNavigationController = mitk::SliceNavigationController::New("dummy");
m_TimeNavigationController->ConnectGeometryTimeEvent(
mitkWidget1->GetSliceNavigationController() , false);
m_TimeNavigationController->ConnectGeometryTimeEvent(
mitkWidget2->GetSliceNavigationController() , false);
m_TimeNavigationController->ConnectGeometryTimeEvent(
mitkWidget3->GetSliceNavigationController() , false);
m_TimeNavigationController->ConnectGeometryTimeEvent(
mitkWidget4->GetSliceNavigationController() , false);
mitkWidget1->GetSliceNavigationController()
->ConnectGeometrySendEvent(mitk::BaseRenderer::GetInstance(mitkWidget4->GetRenderWindow()));
// Set TimeNavigationController to RenderingManager
// (which uses it internally for views initialization!)
mitk::RenderingManager::GetInstance()->SetTimeNavigationController(
m_TimeNavigationController );
//reverse connection between sliceNavigationControllers and m_TimeNavigationController
mitkWidget1->GetSliceNavigationController()
->ConnectGeometryTimeEvent(m_TimeNavigationController.GetPointer(), false);
mitkWidget2->GetSliceNavigationController()
->ConnectGeometryTimeEvent(m_TimeNavigationController.GetPointer(), false);
mitkWidget3->GetSliceNavigationController()
->ConnectGeometryTimeEvent(m_TimeNavigationController.GetPointer(), false);
mitkWidget4->GetSliceNavigationController()
->ConnectGeometryTimeEvent(m_TimeNavigationController.GetPointer(), false);
// instantiate display interactor
m_MoveAndZoomInteractor = mitk::DisplayVectorInteractor::New(
"moveNzoom", new mitk::DisplayInteractor() );
m_LastLeftClickPositionSupplier =
mitk::CoordinateSupplier::New("navigation", NULL);
mitk::GlobalInteraction::GetInstance()->AddListener(
m_LastLeftClickPositionSupplier
);
// setup gradient background
m_GradientBackground1 = mitk::GradientBackground::New();
m_GradientBackground1->SetRenderWindow(
mitkWidget1->GetRenderWindow() );
m_GradientBackground1->Disable();
m_GradientBackground2 = mitk::GradientBackground::New();
m_GradientBackground2->SetRenderWindow(
mitkWidget2->GetRenderWindow() );
m_GradientBackground2->Disable();
m_GradientBackground3 = mitk::GradientBackground::New();
m_GradientBackground3->SetRenderWindow(
mitkWidget3->GetRenderWindow() );
m_GradientBackground3->Disable();
m_GradientBackground4 = mitk::GradientBackground::New();
m_GradientBackground4->SetRenderWindow(
mitkWidget4->GetRenderWindow() );
m_GradientBackground4->SetGradientColors(0.1,0.1,0.1,0.5,0.5,0.5);
m_GradientBackground4->Enable();
// setup the department logo rendering
m_LogoRendering1 = mitk::ManufacturerLogo::New();
m_LogoRendering1->SetRenderWindow(
mitkWidget1->GetRenderWindow() );
m_LogoRendering1->Disable();
m_LogoRendering2 = mitk::ManufacturerLogo::New();
m_LogoRendering2->SetRenderWindow(
mitkWidget2->GetRenderWindow() );
m_LogoRendering2->Disable();
m_LogoRendering3 = mitk::ManufacturerLogo::New();
m_LogoRendering3->SetRenderWindow(
mitkWidget3->GetRenderWindow() );
m_LogoRendering3->Disable();
m_LogoRendering4 = mitk::ManufacturerLogo::New();
m_LogoRendering4->SetRenderWindow(
mitkWidget4->GetRenderWindow() );
m_LogoRendering4->Enable();
m_RectangleRendering1 = mitk::RenderWindowFrame::New();
m_RectangleRendering1->SetRenderWindow(
mitkWidget1->GetRenderWindow() );
m_RectangleRendering1->Enable(1.0,0.0,0.0);
m_RectangleRendering2 = mitk::RenderWindowFrame::New();
m_RectangleRendering2->SetRenderWindow(
mitkWidget2->GetRenderWindow() );
m_RectangleRendering2->Enable(0.0,1.0,0.0);
m_RectangleRendering3 = mitk::RenderWindowFrame::New();
m_RectangleRendering3->SetRenderWindow(
mitkWidget3->GetRenderWindow() );
m_RectangleRendering3->Enable(0.0,0.0,1.0);
m_RectangleRendering4 = mitk::RenderWindowFrame::New();
m_RectangleRendering4->SetRenderWindow(
mitkWidget4->GetRenderWindow() );
m_RectangleRendering4->Enable(1.0,1.0,0.0);
}
| void QmitkStdMultiWidget::InitPositionTracking | ( | ) | [slot] |
Definition at line 1269 of file QmitkStdMultiWidget.cpp.
References m_PositionTrackerNode, mitk::BoolProperty::New(), mitk::IntProperty::New(), mitk::PointSet::New(), mitk::StringProperty::New(), and mitk::DataNode::New().
{
//PoinSetNode for MouseOrientation
m_PositionTrackerNode = mitk::DataNode::New();
m_PositionTrackerNode->SetProperty("name", mitk::StringProperty::New("Mouse Position"));
m_PositionTrackerNode->SetData( mitk::PointSet::New() );
m_PositionTrackerNode->SetColor(1.0,0.33,0.0);
m_PositionTrackerNode->SetProperty("layer", mitk::IntProperty::New(1001));
m_PositionTrackerNode->SetVisibility(true);
m_PositionTrackerNode->SetProperty("inputdevice", mitk::BoolProperty::New(true) );
m_PositionTrackerNode->SetProperty("BaseRendererMapperID", mitk::IntProperty::New(0) );//point position 2D mouse
m_PositionTrackerNode->SetProperty("baserenderer", mitk::StringProperty::New("N/A"));
}
| void QmitkStdMultiWidget::leaveEvent | ( | QEvent * | e ) | [slot] |
Definition at line 1397 of file QmitkStdMultiWidget.cpp.
References m_SlicesRotator.
{
//set cursor back to initial state
m_SlicesRotator->ResetMouseCursor();
}
| void QmitkStdMultiWidget::LeftMouseClicked | ( | mitk::Point3D | pointValue ) | [signal] |
Referenced by mousePressEvent().
| void QmitkStdMultiWidget::mousePressEvent | ( | QMouseEvent * | e ) | [slot] |
Definition at line 1380 of file QmitkStdMultiWidget.cpp.
References GetLastLeftClickPosition(), and LeftMouseClicked().
{
if (e->button() == Qt::LeftButton) {
mitk::Point3D pointValue = this->GetLastLeftClickPosition();
emit LeftMouseClicked(pointValue);
}
}
| void QmitkStdMultiWidget::MoveCrossToPosition | ( | const mitk::Point3D & | newPosition ) | [slot] |
Definition at line 1520 of file QmitkStdMultiWidget.cpp.
References mitk::EIDLEFTMOUSEBTN, mitk::EIDLEFTMOUSERELEASE, EnsureDisplayContainsPoint(), mitk::RenderingManager::GetInstance(), mitk::BaseRenderer::GetInstance(), mitk::RenderWindowBase::GetSliceNavigationController(), mitk::StateMachine::HandleEvent(), mitk::Key_unknown, m_PlaneMode, m_SlicesRotator, m_SlicesSwiveller, mitkWidget1, mitkWidget2, mitkWidget3, PLANE_MODE_ROTATION, PLANE_MODE_SLICING, and PLANE_MODE_SWIVEL.
Referenced by QmitkPointListView::OnListViewSelectionChanged().
{
// create a PositionEvent with the given position and
// tell the slice navigation controllers to move there
mitk::Point2D p2d;
mitk::PositionEvent event( mitk::BaseRenderer::GetInstance(mitkWidget1->GetRenderWindow()), 0, 0, 0,
mitk::Key_unknown, p2d, newPosition );
mitk::StateEvent stateEvent(mitk::EIDLEFTMOUSEBTN, &event);
mitk::StateEvent stateEvent2(mitk::EIDLEFTMOUSERELEASE, &event);
switch ( m_PlaneMode )
{
default:
case PLANE_MODE_SLICING:
mitkWidget1->GetSliceNavigationController()->HandleEvent( &stateEvent );
mitkWidget2->GetSliceNavigationController()->HandleEvent( &stateEvent );
mitkWidget3->GetSliceNavigationController()->HandleEvent( &stateEvent );
// just in case SNCs will develop something that depends on the mouse
// button being released again
mitkWidget1->GetSliceNavigationController()->HandleEvent( &stateEvent2 );
mitkWidget2->GetSliceNavigationController()->HandleEvent( &stateEvent2 );
mitkWidget3->GetSliceNavigationController()->HandleEvent( &stateEvent2 );
break;
case PLANE_MODE_ROTATION:
m_SlicesRotator->HandleEvent( &stateEvent );
// just in case SNCs will develop something that depends on the mouse
// button being released again
m_SlicesRotator->HandleEvent( &stateEvent2 );
break;
case PLANE_MODE_SWIVEL:
m_SlicesSwiveller->HandleEvent( &stateEvent );
// just in case SNCs will develop something that depends on the mouse
// button being released again
m_SlicesSwiveller->HandleEvent( &stateEvent2 );
break;
}
// determine if cross is now out of display
// if so, move the display window
EnsureDisplayContainsPoint( mitk::BaseRenderer::GetInstance(mitkWidget1->GetRenderWindow())
->GetDisplayGeometry(), newPosition );
EnsureDisplayContainsPoint( mitk::BaseRenderer::GetInstance(mitkWidget2->GetRenderWindow())
->GetDisplayGeometry(), newPosition );
EnsureDisplayContainsPoint( mitk::BaseRenderer::GetInstance(mitkWidget3->GetRenderWindow())
->GetDisplayGeometry(), newPosition );
// update displays
mitk::RenderingManager::GetInstance()->RequestUpdateAll();
}
| void QmitkStdMultiWidget::Moved | ( | ) | [signal] |
Referenced by moveEvent().
| void QmitkStdMultiWidget::moveEvent | ( | QMoveEvent * | e ) | [slot] |
Definition at line 1388 of file QmitkStdMultiWidget.cpp.
References Moved().
{
QWidget::moveEvent( e );
// it is necessary to readjust the position of the overlays as the StdMultiWidget has moved
// unfortunately it's not done by QmitkRenderWindow::moveEvent -> must be done here
emit Moved();
}
| void QmitkStdMultiWidget::OnLayoutDesignChanged | ( | int | layoutDesignIndex ) | [slot] |
Definition at line 1889 of file QmitkStdMultiWidget.cpp.
References changeLayoutTo2DImagesLeft(), changeLayoutTo2DImagesUp(), changeLayoutTo2x2Dand3DWidget(), changeLayoutToBig3D(), changeLayoutToColumnWidget3And4(), changeLayoutToDefault(), changeLayoutToLeft2Dand3DRight2D(), changeLayoutToRowWidget3And4(), changeLayoutToRowWidgetSmall3andBig4(), changeLayoutToSmallUpperWidget2Big3and4(), changeLayoutToWidget1(), changeLayoutToWidget2(), changeLayoutToWidget3(), LAYOUT_2D_AND_3D_LEFT_2D_RIGHT_WIDGET, LAYOUT_2D_IMAGES_LEFT, LAYOUT_2D_IMAGES_UP, LAYOUT_2X_2D_AND_3D_WIDGET, LAYOUT_BIG_3D, LAYOUT_COLUMN_WIDGET_3_AND_4, LAYOUT_DEFAULT, LAYOUT_ROW_WIDGET_3_AND_4, LAYOUT_ROW_WIDGET_SMALL3_AND_BIG4, LAYOUT_SMALL_UPPER_WIDGET2_BIG3_AND4, LAYOUT_WIDGET1, LAYOUT_WIDGET2, and LAYOUT_WIDGET3.
Referenced by QmitkStdMultiWidget().
{
switch( layoutDesignIndex )
{
case LAYOUT_DEFAULT:
{
this->changeLayoutToDefault();
break;
}
case LAYOUT_2D_IMAGES_UP:
{
this->changeLayoutTo2DImagesUp();
break;
}
case LAYOUT_2D_IMAGES_LEFT:
{
this->changeLayoutTo2DImagesLeft();
break;
}
case LAYOUT_BIG_3D:
{
this->changeLayoutToBig3D();
break;
}
case LAYOUT_WIDGET1:
{
this->changeLayoutToWidget1();
break;
}
case LAYOUT_WIDGET2:
{
this->changeLayoutToWidget2();
break;
}
case LAYOUT_WIDGET3:
{
this->changeLayoutToWidget3();
break;
}
case LAYOUT_2X_2D_AND_3D_WIDGET:
{
this->changeLayoutTo2x2Dand3DWidget();
break;
}
case LAYOUT_ROW_WIDGET_3_AND_4:
{
this->changeLayoutToRowWidget3And4();
break;
}
case LAYOUT_COLUMN_WIDGET_3_AND_4:
{
this->changeLayoutToColumnWidget3And4();
break;
}
case LAYOUT_ROW_WIDGET_SMALL3_AND_BIG4:
{
this->changeLayoutToRowWidgetSmall3andBig4();
break;
}
case LAYOUT_SMALL_UPPER_WIDGET2_BIG3_AND4:
{
this->changeLayoutToSmallUpperWidget2Big3and4();
break;
}
case LAYOUT_2D_AND_3D_LEFT_2D_RIGHT_WIDGET:
{
this->changeLayoutToLeft2Dand3DRight2D();
break;
}
};
}
| void QmitkStdMultiWidget::RemovePlanesFromDataStorage | ( | ) |
called when the StdMultiWidget is closed to remove the 3 widget planes and the helper node from the DataStorage
Definition at line 443 of file QmitkStdMultiWidget.cpp.
References m_DataStorage, m_Node, m_PlaneNode1, m_PlaneNode2, and m_PlaneNode3.
Referenced by QmitkStdMultiWidgetEditor::PartClosed(), and QmitkStdMultiWidgetEditor::PartHidden().
{
if (m_PlaneNode1.IsNotNull() && m_PlaneNode2.IsNotNull() && m_PlaneNode3.IsNotNull() && m_Node.IsNotNull())
{
if(m_DataStorage.IsNotNull())
{
m_DataStorage->Remove(m_PlaneNode1);
m_DataStorage->Remove(m_PlaneNode2);
m_DataStorage->Remove(m_PlaneNode3);
m_DataStorage->Remove(m_Node);
}
}
}
| void QmitkStdMultiWidget::RequestUpdate | ( | ) |
Definition at line 1357 of file QmitkStdMultiWidget.cpp.
References mitk::RenderingManager::GetInstance(), mitkWidget1, mitkWidget2, mitkWidget3, and mitkWidget4.
Referenced by QmitkControlVisualizationPropertiesView::AdditionalScaling(), QmitkQBallReconstructionView::AnalyticalQBallReconstruction(), QmitkIsoSurface::CreateSurface(), QmitkControlVisualizationPropertiesView::IndexParam1Changed(), QmitkControlVisualizationPropertiesView::IndexParam2Changed(), QmitkControlVisualizationPropertiesView::NormalizationDropdownChanged(), QmitkControlVisualizationPropertiesView::OpacityMaxFaChanged(), QmitkControlVisualizationPropertiesView::OpacityMinFaChanged(), QmitkDiffusionTensorEstimation::QBallReconstructionAnalyticalButton(), QmitkDiffusionTensorEstimation::QBallReconstructionButton(), QmitkDiffusionTensorEstimation::QBallStandardAlgorithmsDeconvolutionButton(), QmitkDiffusionTensorEstimation::QBallStandardAlgorithmsDirectionButton(), QmitkDiffusionTensorEstimation::QBallStandardAlgorithmsGFAButton(), QmitkDiffusionTensorEstimation::QBallVolumesVisualizeSelectedButton(), QmitkDiffusionQuantificationView::QBIQuantification(), QmitkControlVisualizationPropertiesView::ScalingFactorChanged(), QmitkControlVisualizationPropertiesView::ShowMaxNumberChanged(), QmitkDiffusionTensorEstimation::StandardAlgorithmsDirectionButton(), QmitkDiffusionTensorEstimation::StandardAlgorithmsFAButton(), QmitkDiffusionTensorEstimation::StandardAlgorithmsRAButton(), QmitkSimpleExampleView::stereoSelectionChanged(), QmitkDiffusionQuantificationView::TensorQuantification(), QmitkControlVisualizationPropertiesView::TextIntON(), and QmitkControlVisualizationPropertiesView::VisibleOdfsON().
{
mitk::RenderingManager::GetInstance()->RequestUpdate(mitkWidget1->GetRenderWindow());
mitk::RenderingManager::GetInstance()->RequestUpdate(mitkWidget2->GetRenderWindow());
mitk::RenderingManager::GetInstance()->RequestUpdate(mitkWidget3->GetRenderWindow());
mitk::RenderingManager::GetInstance()->RequestUpdate(mitkWidget4->GetRenderWindow());
}
| void QmitkStdMultiWidget::ResetCrosshair | ( | ) | [slot] |
Definition at line 1997 of file QmitkStdMultiWidget.cpp.
References mitk::RenderingManager::GetInstance(), m_DataStorage, PLANE_MODE_SLICING, and SetWidgetPlaneMode().
Referenced by QmitkStdMultiWidget().
{
if (m_DataStorage.IsNotNull())
{
mitk::RenderingManager::GetInstance()->InitializeViews( m_DataStorage->ComputeVisibleBoundingGeometry3D() );
// reset interactor to normal slicing
this->SetWidgetPlaneMode(PLANE_MODE_SLICING);
}
}
| void QmitkStdMultiWidget::SetDataStorage | ( | mitk::DataStorage * | ds ) |
Definition at line 1228 of file QmitkStdMultiWidget.cpp.
References mitk::BaseRenderer::GetInstance(), m_DataStorage, mitkWidget1, mitkWidget2, mitkWidget3, and mitkWidget4.
Referenced by QmitkStdMultiWidgetEditor::CreateQtPartControl(), and Step8::SetupWidgets().
{
mitk::BaseRenderer::GetInstance(mitkWidget1->GetRenderWindow())->SetDataStorage(ds);
mitk::BaseRenderer::GetInstance(mitkWidget2->GetRenderWindow())->SetDataStorage(ds);
mitk::BaseRenderer::GetInstance(mitkWidget3->GetRenderWindow())->SetDataStorage(ds);
mitk::BaseRenderer::GetInstance(mitkWidget4->GetRenderWindow())->SetDataStorage(ds);
m_DataStorage = ds;
}
| void QmitkStdMultiWidget::SetDepartmentLogoPath | ( | const char * | path ) | [slot] |
Definition at line 1854 of file QmitkStdMultiWidget.cpp.
References m_LogoRendering1, m_LogoRendering2, m_LogoRendering3, and m_LogoRendering4.
Referenced by QmitkStdMultiWidgetEditor::CreateQtPartControl().
{
m_LogoRendering1->SetLogoSource(path);
m_LogoRendering2->SetLogoSource(path);
m_LogoRendering3->SetLogoSource(path);
m_LogoRendering4->SetLogoSource(path);
}
| void QmitkStdMultiWidget::SetGradientBackgroundColors | ( | const mitk::Color & | upper, |
| const mitk::Color & | lower | ||
| ) | [slot] |
Definition at line 1845 of file QmitkStdMultiWidget.cpp.
References m_GradientBackground1, m_GradientBackground2, m_GradientBackground3, and m_GradientBackground4.
{
m_GradientBackground1->SetGradientColors(upper[0], upper[1], upper[2], lower[0], lower[1], lower[2]);
m_GradientBackground2->SetGradientColors(upper[0], upper[1], upper[2], lower[0], lower[1], lower[2]);
m_GradientBackground3->SetGradientColors(upper[0], upper[1], upper[2], lower[0], lower[1], lower[2]);
m_GradientBackground4->SetGradientColors(upper[0], upper[1], upper[2], lower[0], lower[1], lower[2]);
}
| void QmitkStdMultiWidget::SetWidgetPlaneMode | ( | int | mode ) | [slot] |
Definition at line 1730 of file QmitkStdMultiWidget.cpp.
References mitk::GlobalInteraction::AddListener(), mitk::RenderingManager::GetInstance(), mitk::GlobalInteraction::GetInstance(), mitk::RenderWindowBase::GetSliceNavigationController(), m_PlaneMode, m_SlicesRotator, m_SlicesSwiveller, MITK_DEBUG, mitkWidget1, mitkWidget2, mitkWidget3, mitkWidget4, PLANE_MODE_ROTATION, PLANE_MODE_SLICING, PLANE_MODE_SWIVEL, mitk::GlobalInteraction::RemoveListener(), WidgetNotifyNewCrossHairMode(), WidgetPlaneModeRotation(), WidgetPlaneModeSlicing(), and WidgetPlaneModeSwivel().
Referenced by QmitkStdMultiWidget(), ResetCrosshair(), SetWidgetPlaneModeToRotation(), SetWidgetPlaneModeToSlicing(), and SetWidgetPlaneModeToSwivel().
{
MITK_DEBUG << "Changing crosshair mode to " << userMode;
emit WidgetNotifyNewCrossHairMode( userMode );
int mode = m_PlaneMode;
bool link = false;
// Convert user interface mode to actual mode
{
switch(userMode)
{
case 0:
mode = PLANE_MODE_SLICING;
link = false;
break;
case 1:
mode = PLANE_MODE_ROTATION;
link = false;
break;
case 2:
mode = PLANE_MODE_ROTATION;
link = true;
break;
case 3:
mode = PLANE_MODE_SWIVEL;
link = false;
break;
}
}
// Slice rotation linked
m_SlicesRotator->SetLinkPlanes( link );
m_SlicesSwiveller->SetLinkPlanes( link );
// Do nothing if mode didn't change
if ( m_PlaneMode == mode )
{
return;
}
mitk::GlobalInteraction *gi = mitk::GlobalInteraction::GetInstance();
// Remove listeners of previous mode
switch ( m_PlaneMode )
{
default:
case PLANE_MODE_SLICING:
// Notify MainTemplate GUI that this mode has been deselected
emit WidgetPlaneModeSlicing( false );
gi->RemoveListener( mitkWidget1->GetSliceNavigationController() );
gi->RemoveListener( mitkWidget2->GetSliceNavigationController() );
gi->RemoveListener( mitkWidget3->GetSliceNavigationController() );
gi->RemoveListener( mitkWidget4->GetSliceNavigationController() );
break;
case PLANE_MODE_ROTATION:
// Notify MainTemplate GUI that this mode has been deselected
emit WidgetPlaneModeRotation( false );
m_SlicesRotator->ResetMouseCursor();
gi->RemoveListener( m_SlicesRotator );
break;
case PLANE_MODE_SWIVEL:
// Notify MainTemplate GUI that this mode has been deselected
emit WidgetPlaneModeSwivel( false );
m_SlicesSwiveller->ResetMouseCursor();
gi->RemoveListener( m_SlicesSwiveller );
break;
}
// Set new mode and add corresponding listener to GlobalInteraction
m_PlaneMode = mode;
switch ( m_PlaneMode )
{
default:
case PLANE_MODE_SLICING:
// Notify MainTemplate GUI that this mode has been selected
emit WidgetPlaneModeSlicing( true );
// Add listeners
gi->AddListener( mitkWidget1->GetSliceNavigationController() );
gi->AddListener( mitkWidget2->GetSliceNavigationController() );
gi->AddListener( mitkWidget3->GetSliceNavigationController() );
gi->AddListener( mitkWidget4->GetSliceNavigationController() );
mitk::RenderingManager::GetInstance()->InitializeViews();
break;
case PLANE_MODE_ROTATION:
// Notify MainTemplate GUI that this mode has been selected
emit WidgetPlaneModeRotation( true );
// Add listener
gi->AddListener( m_SlicesRotator );
break;
case PLANE_MODE_SWIVEL:
// Notify MainTemplate GUI that this mode has been selected
emit WidgetPlaneModeSwivel( true );
// Add listener
gi->AddListener( m_SlicesSwiveller );
break;
}
}
| void QmitkStdMultiWidget::SetWidgetPlaneModeToRotation | ( | bool | activate ) | [slot] |
Definition at line 1872 of file QmitkStdMultiWidget.cpp.
References PLANE_MODE_ROTATION, and SetWidgetPlaneMode().
{
if ( activate )
{
this->SetWidgetPlaneMode( PLANE_MODE_ROTATION );
}
}
| void QmitkStdMultiWidget::SetWidgetPlaneModeToSlicing | ( | bool | activate ) | [slot] |
Definition at line 1863 of file QmitkStdMultiWidget.cpp.
References PLANE_MODE_SLICING, and SetWidgetPlaneMode().
{
if ( activate )
{
this->SetWidgetPlaneMode( PLANE_MODE_SLICING );
}
}
| void QmitkStdMultiWidget::SetWidgetPlaneModeToSwivel | ( | bool | activate ) | [slot] |
Definition at line 1881 of file QmitkStdMultiWidget.cpp.
References PLANE_MODE_SWIVEL, and SetWidgetPlaneMode().
{
if ( activate )
{
this->SetWidgetPlaneMode( PLANE_MODE_SWIVEL );
}
}
| void QmitkStdMultiWidget::SetWidgetPlanesLocked | ( | bool | locked ) | [slot] |
Definition at line 1704 of file QmitkStdMultiWidget.cpp.
References GetRenderWindow1(), GetRenderWindow2(), GetRenderWindow3(), mitk::RenderWindowBase::GetSliceNavigationController(), and mitk::SliceNavigationController::SetSliceLocked().
{
//do your job and lock or unlock slices.
GetRenderWindow1()->GetSliceNavigationController()->SetSliceLocked(locked);
GetRenderWindow2()->GetSliceNavigationController()->SetSliceLocked(locked);
GetRenderWindow3()->GetSliceNavigationController()->SetSliceLocked(locked);
}
| void QmitkStdMultiWidget::SetWidgetPlanesRotationLinked | ( | bool | link ) | [slot] |
Definition at line 1722 of file QmitkStdMultiWidget.cpp.
References m_SlicesRotator, m_SlicesSwiveller, and WidgetPlanesRotationLinked().
{
m_SlicesRotator->SetLinkPlanes( link );
m_SlicesSwiveller->SetLinkPlanes( link );
emit WidgetPlanesRotationLinked( link );
}
| void QmitkStdMultiWidget::SetWidgetPlanesRotationLocked | ( | bool | locked ) | [slot] |
Definition at line 1713 of file QmitkStdMultiWidget.cpp.
References GetRenderWindow1(), GetRenderWindow2(), GetRenderWindow3(), mitk::RenderWindowBase::GetSliceNavigationController(), and mitk::SliceNavigationController::SetSliceRotationLocked().
{
//do your job and lock or unlock slices.
GetRenderWindow1()->GetSliceNavigationController()->SetSliceRotationLocked(locked);
GetRenderWindow2()->GetSliceNavigationController()->SetSliceRotationLocked(locked);
GetRenderWindow3()->GetSliceNavigationController()->SetSliceRotationLocked(locked);
}
| void QmitkStdMultiWidget::SetWidgetPlanesVisibility | ( | bool | visible, |
| mitk::BaseRenderer * | renderer = NULL |
||
| ) | [slot] |
Definition at line 1695 of file QmitkStdMultiWidget.cpp.
References mitk::RenderingManager::GetInstance(), and SetWidgetPlaneVisibility().
Referenced by QmitkMeasurement::Activated(), QmitkMeasurement::AssertDrawingIsPossible(), QmitkMeasurement::Deactivated(), QmitkIGTRecorderView::OnStartRecording(), Step8::SetupWidgets(), QmitkRigidRegistrationView::StdMultiWidgetAvailable(), QmitkPointBasedRegistrationView::StdMultiWidgetAvailable(), and QmitkDeformableRegistrationView::StdMultiWidgetAvailable().
{
SetWidgetPlaneVisibility("widget1Plane", visible, renderer);
SetWidgetPlaneVisibility("widget2Plane", visible, renderer);
SetWidgetPlaneVisibility("widget3Plane", visible, renderer);
mitk::RenderingManager::GetInstance()->RequestUpdateAll();
}
| void QmitkStdMultiWidget::SetWidgetPlaneVisibility | ( | const char * | widgetName, |
| bool | visible, | ||
| mitk::BaseRenderer * | renderer = NULL |
||
| ) | [slot] |
Definition at line 1684 of file QmitkStdMultiWidget.cpp.
References m_DataStorage, and mitk::DataNode::SetVisibility().
Referenced by SetWidgetPlanesVisibility().
{
if (m_DataStorage.IsNotNull())
{
mitk::DataNode* n = m_DataStorage->GetNamedNode(widgetName);
if (n != NULL)
n->SetVisibility(visible, renderer);
}
}
| void QmitkStdMultiWidget::UpdateAllWidgets | ( | ) | [protected] |
Definition at line 1964 of file QmitkStdMultiWidget.cpp.
References mitkWidget1, mitkWidget1Container, mitkWidget2, mitkWidget2Container, mitkWidget3, mitkWidget3Container, mitkWidget4, and mitkWidget4Container.
Referenced by changeLayoutTo2DImagesLeft(), changeLayoutTo2DImagesUp(), changeLayoutTo2DUpAnd3DDown(), changeLayoutTo2x2Dand3DWidget(), changeLayoutToBig3D(), changeLayoutToColumnWidget3And4(), changeLayoutToDefault(), changeLayoutToLeft2Dand3DRight2D(), changeLayoutToRowWidget3And4(), changeLayoutToSmallUpperWidget2Big3and4(), changeLayoutToWidget1(), changeLayoutToWidget2(), and changeLayoutToWidget3().
{
mitkWidget1->resize( mitkWidget1Container->frameSize().width()-1, mitkWidget1Container->frameSize().height() );
mitkWidget1->resize( mitkWidget1Container->frameSize().width(), mitkWidget1Container->frameSize().height() );
mitkWidget2->resize( mitkWidget2Container->frameSize().width()-1, mitkWidget2Container->frameSize().height() );
mitkWidget2->resize( mitkWidget2Container->frameSize().width(), mitkWidget2Container->frameSize().height() );
mitkWidget3->resize( mitkWidget3Container->frameSize().width()-1, mitkWidget3Container->frameSize().height() );
mitkWidget3->resize( mitkWidget3Container->frameSize().width(), mitkWidget3Container->frameSize().height() );
mitkWidget4->resize( mitkWidget4Container->frameSize().width()-1, mitkWidget4Container->frameSize().height() );
mitkWidget4->resize( mitkWidget4Container->frameSize().width(), mitkWidget4Container->frameSize().height() );
}
| void QmitkStdMultiWidget::ViewsInitialized | ( | ) | [signal] |
| void QmitkStdMultiWidget::wheelEvent | ( | QWheelEvent * | e ) | [slot] |
Definition at line 1375 of file QmitkStdMultiWidget.cpp.
References WheelMoved().
{
emit WheelMoved( e );
}
| void QmitkStdMultiWidget::WheelMoved | ( | QWheelEvent * | ) | [signal] |
Referenced by wheelEvent().
| void QmitkStdMultiWidget::WidgetNotifyNewCrossHairMode | ( | int | ) | [signal] |
Referenced by QmitkStdMultiWidget(), and SetWidgetPlaneMode().
| void QmitkStdMultiWidget::WidgetPlaneModeChange | ( | int | ) | [signal] |
| void QmitkStdMultiWidget::WidgetPlaneModeRotation | ( | bool | ) | [signal] |
Referenced by SetWidgetPlaneMode().
| void QmitkStdMultiWidget::WidgetPlaneModeSlicing | ( | bool | ) | [signal] |
Referenced by SetWidgetPlaneMode().
| void QmitkStdMultiWidget::WidgetPlaneModeSwivel | ( | bool | ) | [signal] |
Referenced by SetWidgetPlaneMode().
| void QmitkStdMultiWidget::WidgetPlanesRotationEnabled | ( | bool | ) | [signal] |
| void QmitkStdMultiWidget::WidgetPlanesRotationLinked | ( | bool | ) | [signal] |
Referenced by SetWidgetPlanesRotationLinked().
| vtkCornerAnnotation* QmitkStdMultiWidget::cornerText |
Definition at line 294 of file QmitkStdMultiWidget.h.
Referenced by InitializeWidget().
Definition at line 226 of file QmitkStdMultiWidget.h.
Referenced by changeLayoutTo2DImagesLeft(), changeLayoutTo2DImagesUp(), changeLayoutTo2DUpAnd3DDown(), changeLayoutTo2x2Dand3DWidget(), changeLayoutToBig3D(), changeLayoutToColumnWidget3And4(), changeLayoutToDefault(), changeLayoutToLeft2Dand3DRight2D(), changeLayoutToRowWidget3And4(), changeLayoutToSmallUpperWidget2Big3and4(), changeLayoutToWidget1(), changeLayoutToWidget2(), changeLayoutToWidget3(), DisableStandardLevelWindow(), EnableStandardLevelWindow(), and QmitkStdMultiWidget().
struct { ... } QmitkStdMultiWidget::m_CornerAnnotaions[3] [protected] |
Referenced by InitializeWidget(), and ~QmitkStdMultiWidget().
Definition at line 275 of file QmitkStdMultiWidget.h.
Referenced by AddPlanesToDataStorage(), DisablePositionTracking(), EnablePositionTracking(), RemovePlanesFromDataStorage(), ResetCrosshair(), SetDataStorage(), and SetWidgetPlaneVisibility().
Definition at line 262 of file QmitkStdMultiWidget.h.
Referenced by InitializeWidget(), and SetGradientBackgroundColors().
Definition at line 263 of file QmitkStdMultiWidget.h.
Referenced by InitializeWidget(), and SetGradientBackgroundColors().
Definition at line 265 of file QmitkStdMultiWidget.h.
Referenced by InitializeWidget(), and SetGradientBackgroundColors().
Definition at line 264 of file QmitkStdMultiWidget.h.
Referenced by DisableGradientBackground(), EnableGradientBackground(), InitializeWidget(), and SetGradientBackgroundColors().
Definition at line 268 of file QmitkStdMultiWidget.h.
Referenced by GetCrossPosition(), GetLastLeftClickPosition(), and InitializeWidget().
int QmitkStdMultiWidget::m_Layout [protected] |
Definition at line 249 of file QmitkStdMultiWidget.h.
Referenced by changeLayoutTo2DImagesLeft(), changeLayoutTo2DImagesUp(), changeLayoutTo2DUpAnd3DDown(), changeLayoutTo2x2Dand3DWidget(), changeLayoutToBig3D(), changeLayoutToColumnWidget3And4(), changeLayoutToDefault(), changeLayoutToLeft2Dand3DRight2D(), changeLayoutToRowWidget3And4(), changeLayoutToRowWidgetSmall3andBig4(), changeLayoutToSmallUpperWidget2Big3and4(), changeLayoutToWidget1(), changeLayoutToWidget2(), changeLayoutToWidget3(), and GetLayout().
QSplitter* QmitkStdMultiWidget::m_LayoutSplit [protected] |
Definition at line 283 of file QmitkStdMultiWidget.h.
Referenced by changeLayoutTo2DImagesLeft(), changeLayoutTo2DImagesUp(), changeLayoutTo2DUpAnd3DDown(), changeLayoutTo2x2Dand3DWidget(), changeLayoutToColumnWidget3And4(), changeLayoutToDefault(), changeLayoutToLeft2Dand3DRight2D(), changeLayoutToRowWidget3And4(), changeLayoutToSmallUpperWidget2Big3and4(), and QmitkStdMultiWidget().
Definition at line 257 of file QmitkStdMultiWidget.h.
Referenced by InitializeWidget(), and SetDepartmentLogoPath().
Definition at line 258 of file QmitkStdMultiWidget.h.
Referenced by InitializeWidget(), and SetDepartmentLogoPath().
Definition at line 259 of file QmitkStdMultiWidget.h.
Referenced by InitializeWidget(), and SetDepartmentLogoPath().
Definition at line 260 of file QmitkStdMultiWidget.h.
Referenced by DisableDepartmentLogo(), EnableDepartmentLogo(), InitializeWidget(), and SetDepartmentLogoPath().
QSplitter* QmitkStdMultiWidget::m_MainSplit [protected] |
Definition at line 282 of file QmitkStdMultiWidget.h.
Referenced by changeLayoutTo2DImagesLeft(), changeLayoutTo2DImagesUp(), changeLayoutTo2DUpAnd3DDown(), changeLayoutTo2x2Dand3DWidget(), changeLayoutToBig3D(), changeLayoutToColumnWidget3And4(), changeLayoutToDefault(), changeLayoutToLeft2Dand3DRight2D(), changeLayoutToRowWidget3And4(), changeLayoutToSmallUpperWidget2Big3and4(), changeLayoutToWidget1(), changeLayoutToWidget2(), changeLayoutToWidget3(), and QmitkStdMultiWidget().
Definition at line 267 of file QmitkStdMultiWidget.h.
Referenced by GetMoveAndZoomInteractor(), and InitializeWidget().
mitk::DataNode::Pointer QmitkStdMultiWidget::m_Node [protected] |
Definition at line 280 of file QmitkStdMultiWidget.h.
Referenced by AddDisplayPlaneSubTree(), AddPlanesToDataStorage(), and RemovePlanesFromDataStorage().
int QmitkStdMultiWidget::m_PlaneMode [protected] |
Definition at line 250 of file QmitkStdMultiWidget.h.
Referenced by DisableNavigationControllerEventListening(), EnableNavigationControllerEventListening(), InitializeWidget(), MoveCrossToPosition(), and SetWidgetPlaneMode().
Definition at line 277 of file QmitkStdMultiWidget.h.
Referenced by AddDisplayPlaneSubTree(), AddPlanesToDataStorage(), and RemovePlanesFromDataStorage().
Definition at line 278 of file QmitkStdMultiWidget.h.
Referenced by AddDisplayPlaneSubTree(), AddPlanesToDataStorage(), and RemovePlanesFromDataStorage().
Definition at line 279 of file QmitkStdMultiWidget.h.
Referenced by AddDisplayPlaneSubTree(), AddPlanesToDataStorage(), and RemovePlanesFromDataStorage().
Definition at line 269 of file QmitkStdMultiWidget.h.
Referenced by DisablePositionTracking(), EnablePositionTracking(), and InitializeWidget().
Definition at line 274 of file QmitkStdMultiWidget.h.
Referenced by DisablePositionTracking(), EnablePositionTracking(), and InitPositionTracking().
Definition at line 254 of file QmitkStdMultiWidget.h.
Referenced by DisableColoredRectangles(), EnableColoredRectangles(), and InitializeWidget().
Definition at line 253 of file QmitkStdMultiWidget.h.
Referenced by DisableColoredRectangles(), EnableColoredRectangles(), and InitializeWidget().
Definition at line 252 of file QmitkStdMultiWidget.h.
Referenced by DisableColoredRectangles(), EnableColoredRectangles(), and InitializeWidget().
Definition at line 255 of file QmitkStdMultiWidget.h.
Referenced by DisableColoredRectangles(), EnableColoredRectangles(), and InitializeWidget().
Definition at line 271 of file QmitkStdMultiWidget.h.
Referenced by DisableNavigationControllerEventListening(), EnableNavigationControllerEventListening(), GetSlicesRotator(), InitializeWidget(), leaveEvent(), MoveCrossToPosition(), SetWidgetPlaneMode(), and SetWidgetPlanesRotationLinked().
Definition at line 272 of file QmitkStdMultiWidget.h.
Referenced by DisableNavigationControllerEventListening(), EnableNavigationControllerEventListening(), GetSlicesSwiveller(), InitializeWidget(), MoveCrossToPosition(), SetWidgetPlaneMode(), and SetWidgetPlanesRotationLinked().
QSplitter* QmitkStdMultiWidget::m_SubSplit1 [protected] |
Definition at line 284 of file QmitkStdMultiWidget.h.
Referenced by changeLayoutTo2DImagesLeft(), changeLayoutTo2DImagesUp(), changeLayoutTo2DUpAnd3DDown(), changeLayoutTo2x2Dand3DWidget(), changeLayoutToDefault(), changeLayoutToLeft2Dand3DRight2D(), changeLayoutToSmallUpperWidget2Big3and4(), and QmitkStdMultiWidget().
QSplitter* QmitkStdMultiWidget::m_SubSplit2 [protected] |
Definition at line 285 of file QmitkStdMultiWidget.h.
Referenced by changeLayoutTo2DImagesLeft(), changeLayoutTo2DImagesUp(), changeLayoutTo2DUpAnd3DDown(), changeLayoutTo2x2Dand3DWidget(), changeLayoutToDefault(), changeLayoutToLeft2Dand3DRight2D(), changeLayoutToSmallUpperWidget2Big3and4(), and QmitkStdMultiWidget().
mitk::SliceNavigationController::Pointer QmitkStdMultiWidget::m_TimeNavigationController [protected] |
Definition at line 270 of file QmitkStdMultiWidget.h.
Referenced by DisableNavigationControllerEventListening(), EnableNavigationControllerEventListening(), GetTimeNavigationController(), and InitializeWidget().
Define RenderWindow (public)
Definition at line 222 of file QmitkStdMultiWidget.h.
Referenced by ActivateMenuWidget(), AddDisplayPlaneSubTree(), changeLayoutTo2DImagesLeft(), changeLayoutTo2DImagesUp(), changeLayoutTo2DUpAnd3DDown(), changeLayoutTo2x2Dand3DWidget(), changeLayoutToBig3D(), changeLayoutToColumnWidget3And4(), changeLayoutToDefault(), changeLayoutToLeft2Dand3DRight2D(), changeLayoutToRowWidget3And4(), changeLayoutToSmallUpperWidget2Big3and4(), changeLayoutToWidget1(), changeLayoutToWidget2(), changeLayoutToWidget3(), QmitkImageNavigatorView::CreateQtPartControl(), DisableNavigationControllerEventListening(), EnableNavigationControllerEventListening(), EnableStandardLevelWindow(), Fit(), ForceImmediateUpdate(), GetCrossPosition(), QmitkSimpleExampleView::GetMovieRenderWindow(), GetRenderWindow1(), QmitkSlicesInterpolator::GetSliceForWindowsID(), HideAllWidgetToolbars(), QmitkSlicesInterpolator::Initialize(), InitializeWidget(), MoveCrossToPosition(), QmitkSlicesInterpolator::OnTransversalSliceChanged(), QmitkStdMultiWidget(), RequestUpdate(), SetDataStorage(), SetWidgetPlaneMode(), QmitkSimpleExampleView::StdMultiWidgetAvailable(), UpdateAllWidgets(), and QmitkSlicesInterpolator::~QmitkSlicesInterpolator().
QWidget* QmitkStdMultiWidget::mitkWidget1Container [protected] |
Definition at line 287 of file QmitkStdMultiWidget.h.
Referenced by changeLayoutTo2DImagesLeft(), changeLayoutTo2DImagesUp(), changeLayoutTo2DUpAnd3DDown(), changeLayoutTo2x2Dand3DWidget(), changeLayoutToDefault(), changeLayoutToLeft2Dand3DRight2D(), changeLayoutToWidget1(), QmitkStdMultiWidget(), and UpdateAllWidgets().
Definition at line 223 of file QmitkStdMultiWidget.h.
Referenced by QmitkToolPairNavigationView::Activated(), ActivateMenuWidget(), AddDisplayPlaneSubTree(), changeLayoutTo2DImagesLeft(), changeLayoutTo2DImagesUp(), changeLayoutTo2DUpAnd3DDown(), changeLayoutTo2x2Dand3DWidget(), changeLayoutToBig3D(), changeLayoutToColumnWidget3And4(), changeLayoutToDefault(), changeLayoutToLeft2Dand3DRight2D(), changeLayoutToRowWidget3And4(), changeLayoutToSmallUpperWidget2Big3and4(), changeLayoutToWidget1(), changeLayoutToWidget2(), changeLayoutToWidget3(), QmitkImageNavigatorView::CreateQtPartControl(), QmitkToolPairNavigationView::Deactivated(), DisableNavigationControllerEventListening(), EnableNavigationControllerEventListening(), Fit(), ForceImmediateUpdate(), GetCrossPosition(), QmitkSimpleExampleView::GetMovieRenderWindow(), GetRenderWindow2(), QmitkSlicesInterpolator::GetSliceForWindowsID(), HideAllWidgetToolbars(), QmitkSlicesInterpolator::Initialize(), InitializeWidget(), MoveCrossToPosition(), QmitkSlicesInterpolator::OnSagittalSliceChanged(), QmitkStdMultiWidget(), RequestUpdate(), SetDataStorage(), SetWidgetPlaneMode(), QmitkSimpleExampleView::StdMultiWidgetAvailable(), UpdateAllWidgets(), and QmitkSlicesInterpolator::~QmitkSlicesInterpolator().
QWidget* QmitkStdMultiWidget::mitkWidget2Container [protected] |
Definition at line 288 of file QmitkStdMultiWidget.h.
Referenced by changeLayoutTo2DImagesLeft(), changeLayoutTo2DImagesUp(), changeLayoutTo2x2Dand3DWidget(), changeLayoutToDefault(), changeLayoutToLeft2Dand3DRight2D(), changeLayoutToSmallUpperWidget2Big3and4(), changeLayoutToWidget2(), QmitkStdMultiWidget(), and UpdateAllWidgets().
Definition at line 224 of file QmitkStdMultiWidget.h.
Referenced by QmitkToolPairNavigationView::Activated(), ActivateMenuWidget(), AddDisplayPlaneSubTree(), changeLayoutTo2DImagesLeft(), changeLayoutTo2DImagesUp(), changeLayoutTo2DUpAnd3DDown(), changeLayoutTo2x2Dand3DWidget(), changeLayoutToBig3D(), changeLayoutToColumnWidget3And4(), changeLayoutToDefault(), changeLayoutToLeft2Dand3DRight2D(), changeLayoutToRowWidget3And4(), changeLayoutToSmallUpperWidget2Big3and4(), changeLayoutToWidget1(), changeLayoutToWidget2(), changeLayoutToWidget3(), QmitkToolPairNavigationView::CreateConeAsInstrumentVisualization(), QmitkImageNavigatorView::CreateQtPartControl(), QmitkToolPairNavigationView::Deactivated(), DisableNavigationControllerEventListening(), EnableNavigationControllerEventListening(), Fit(), ForceImmediateUpdate(), GetCrossPosition(), QmitkSimpleExampleView::GetMovieRenderWindow(), GetRenderWindow3(), QmitkSlicesInterpolator::GetSliceForWindowsID(), HideAllWidgetToolbars(), QmitkSlicesInterpolator::Initialize(), InitializeWidget(), MoveCrossToPosition(), QmitkSlicesInterpolator::OnFrontalSliceChanged(), QmitkStdMultiWidget(), RequestUpdate(), SetDataStorage(), QmitkToolPairNavigationView::SetupIGTPipeline(), SetWidgetPlaneMode(), QmitkSimpleExampleView::StdMultiWidgetAvailable(), UpdateAllWidgets(), and QmitkSlicesInterpolator::~QmitkSlicesInterpolator().
QWidget* QmitkStdMultiWidget::mitkWidget3Container [protected] |
Definition at line 289 of file QmitkStdMultiWidget.h.
Referenced by changeLayoutTo2DImagesLeft(), changeLayoutTo2DImagesUp(), changeLayoutToColumnWidget3And4(), changeLayoutToDefault(), changeLayoutToRowWidget3And4(), changeLayoutToSmallUpperWidget2Big3and4(), changeLayoutToWidget3(), QmitkStdMultiWidget(), and UpdateAllWidgets().
Definition at line 225 of file QmitkStdMultiWidget.h.
Referenced by ActivateMenuWidget(), AddDisplayPlaneSubTree(), changeLayoutTo2DImagesLeft(), changeLayoutTo2DImagesUp(), changeLayoutTo2DUpAnd3DDown(), changeLayoutTo2x2Dand3DWidget(), changeLayoutToBig3D(), changeLayoutToColumnWidget3And4(), changeLayoutToDefault(), changeLayoutToLeft2Dand3DRight2D(), changeLayoutToRowWidget3And4(), changeLayoutToSmallUpperWidget2Big3and4(), changeLayoutToWidget1(), changeLayoutToWidget2(), changeLayoutToWidget3(), DisableNavigationControllerEventListening(), EnableNavigationControllerEventListening(), Fit(), ForceImmediateUpdate(), QmitkMovieMaker::GenerateHR3DScreenshot(), QmitkSimpleExampleView::GetMovieRenderWindow(), GetRenderWindow4(), HideAllWidgetToolbars(), InitializeWidget(), QmitkPointListWidget::OnBtnAddPoint(), QmitkIGTExampleView::OnMeasure(), QmitkIGTExampleView::OnPlaying(), QmitkSimpleExampleView::OnTakeHighResolutionScreenshot(), QmitkStdMultiWidget(), QmitkRigidRegistrationView::RedoTransformation(), QmitkPointBasedRegistrationView::RedoTransformation(), RequestUpdate(), SetDataStorage(), SetWidgetPlaneMode(), QmitkSimpleExampleView::stereoSelectionChanged(), QmitkRigidRegistrationView::UndoTransformation(), QmitkPointBasedRegistrationView::UndoTransformation(), and UpdateAllWidgets().
QWidget* QmitkStdMultiWidget::mitkWidget4Container [protected] |
Definition at line 290 of file QmitkStdMultiWidget.h.
Referenced by changeLayoutTo2DImagesLeft(), changeLayoutTo2DImagesUp(), changeLayoutTo2DUpAnd3DDown(), changeLayoutTo2x2Dand3DWidget(), changeLayoutToBig3D(), changeLayoutToColumnWidget3And4(), changeLayoutToDefault(), changeLayoutToLeft2Dand3DRight2D(), changeLayoutToRowWidget3And4(), changeLayoutToSmallUpperWidget2Big3and4(), QmitkStdMultiWidget(), and UpdateAllWidgets().
QHBoxLayout* QmitkStdMultiWidget::QmitkStdMultiWidgetLayout [protected] |
Definition at line 247 of file QmitkStdMultiWidget.h.
Referenced by changeLayoutTo2DImagesLeft(), changeLayoutTo2DImagesUp(), changeLayoutTo2DUpAnd3DDown(), changeLayoutTo2x2Dand3DWidget(), changeLayoutToBig3D(), changeLayoutToColumnWidget3And4(), changeLayoutToDefault(), changeLayoutToLeft2Dand3DRight2D(), changeLayoutToRowWidget3And4(), changeLayoutToSmallUpperWidget2Big3and4(), changeLayoutToWidget1(), changeLayoutToWidget2(), changeLayoutToWidget3(), and QmitkStdMultiWidget().
| vtkRenderer* QmitkStdMultiWidget::ren |
Definition at line 296 of file QmitkStdMultiWidget.h.
Referenced by InitializeWidget(), and ~QmitkStdMultiWidget().
| vtkTextProperty* QmitkStdMultiWidget::textProp |
Definition at line 295 of file QmitkStdMultiWidget.h.
Referenced by InitializeWidget().
1.7.2
