Interaction with a set of points. More...
#include <mitkPointSetInteractor.h>
Public Types | |
| typedef PointSetInteractor | Self |
| typedef Interactor | Superclass |
| typedef itk::SmartPointer< Self > | Pointer |
| typedef itk::SmartPointer < const Self > | ConstPointer |
Public Member Functions | |
| virtual const char * | GetClassName () const |
| void | Clear (unsigned int timeStep=0, ScalarType timeInMS=0.0) |
| Clears all the elements from the given timeStep in the list with undo-functionality and resets the statemachine. | |
| void | SetPrecision (unsigned int precision) |
| Sets the amount of precision. | |
| virtual float | CanHandleEvent (StateEvent const *stateEvent) const |
| calculates how good the data, this statemachine handles, is hit by the event. | |
| virtual void | DataChanged () |
| If data changed then initialize according to numbers of loaded points. | |
Static Public Member Functions | |
| static Pointer | New (const char *_arga, DataNode *_argb, int _argc) |
| static Pointer | New (const char *_arga, DataNode *_argb) |
| NewMacro with two parameters for calling itk::Lightobject::New(..) method. | |
Protected Member Functions | |
| PointSetInteractor (const char *type, DataNode *dataNode, int n=-1) | |
| Constructor with Param n for limited Set of Points. | |
| virtual | ~PointSetInteractor () |
| Default Destructor. | |
| virtual bool | ExecuteAction (Action *action, mitk::StateEvent const *stateEvent) |
| Convert the given Actions to Operations and send to data and UndoController. | |
| void | UnselectAll (unsigned int timeStep=0, ScalarType timeInMS=0.0) |
| Deselects the Points in the PointSet. supports Undo if enabled. | |
| void | SelectPoint (int position, unsigned int timeStep=0, ScalarType timeInMS=0.0) |
| Selects the point. supports Undo if enabled. | |
Protected Attributes | |
| Point3D | m_LastPoint |
| to calculate a direction vector from last point and actual point | |
| Vector3D | m_SumVec |
| summ-vector for Movement | |
Interaction with a set of points.
Points can be added, removed and moved. In case the interaction shall be done on a loaded set of points, the associated data object (mitkPointSet) needs to be loaded prior to the instanciation of this object. The number of points are checked and the internal statemachine set to the apropriate state. The management of 0 points is not supported. In this case, the amount of managed points is set to 1.
Definition at line 44 of file mitkPointSetInteractor.h.
| typedef itk::SmartPointer<const Self> mitk::PointSetInteractor::ConstPointer |
Reimplemented from mitk::Interactor.
Reimplemented in mitk::MouseMovePointSetInteractor, and mitk::DisplayPointSetInteractor.
Definition at line 47 of file mitkPointSetInteractor.h.
| typedef itk::SmartPointer<Self> mitk::PointSetInteractor::Pointer |
Reimplemented from mitk::Interactor.
Reimplemented in mitk::MouseMovePointSetInteractor, and mitk::DisplayPointSetInteractor.
Definition at line 47 of file mitkPointSetInteractor.h.
Reimplemented from mitk::Interactor.
Reimplemented in mitk::MouseMovePointSetInteractor, and mitk::DisplayPointSetInteractor.
Definition at line 47 of file mitkPointSetInteractor.h.
Reimplemented from mitk::Interactor.
Reimplemented in mitk::MouseMovePointSetInteractor, and mitk::DisplayPointSetInteractor.
Definition at line 47 of file mitkPointSetInteractor.h.
| mitk::PointSetInteractor::PointSetInteractor | ( | const char * | type, |
| DataNode * | dataNode, | ||
| int | n = -1 |
||
| ) | [protected] |
Constructor with Param n for limited Set of Points.
If no n is set, then the number of points is unlimited n=0 is not supported. In this case, n is set to 1.
Definition at line 41 of file mitkPointSetInteractor.cpp.
References m_LastPoint, m_SumVec, and STATEMACHINE_WARN.
:Interactor(type, dataNode), m_N(n), m_Precision(PRECISION) { if (m_N==0) { STATEMACHINE_WARN<<"Instanciation of PointSetInteractor which takes care of 0 points does't make sense!\n"; STATEMACHINE_WARN<<"Setting number of points to 1!\n"; m_N = 1; } m_LastPoint.Fill(0); m_SumVec.Fill(0); this->InitAccordingToNumberOfPoints(); }
| mitk::PointSetInteractor::~PointSetInteractor | ( | ) | [protected, virtual] |
| float mitk::PointSetInteractor::CanHandleEvent | ( | StateEvent const * | stateEvent ) | const [virtual] |
calculates how good the data, this statemachine handles, is hit by the event.
overwritten, cause we don't look at the boundingbox, we look at each point
overwritten cause this class can handle it better!
Reimplemented from mitk::Interactor.
Reimplemented in mitk::MouseMovePointSetInteractor.
Definition at line 67 of file mitkPointSetInteractor.cpp.
References mitk::StateEvent::GetEvent(), mitk::StateEvent::GetId(), mitk::Event::GetSender(), mitk::PointSet::GetSize(), mitk::BaseRenderer::GetTimeStep(), mitk::State::GetTransition(), mitk::Event::GetType(), mitk::DisplayPositionEvent::GetWorldPosition(), mitk::PointSet::SearchPoint(), and mitk::Type_MouseMove.
{
float returnValue = 0.0;
//if it is a key event that can be handled in the current state, then return 0.5
mitk::DisplayPositionEvent const *disPosEvent =
dynamic_cast <const mitk::DisplayPositionEvent *> (stateEvent->GetEvent());
//Key event handling:
if (disPosEvent == NULL)
{
//check, if the current state has a transition waiting for that key event.
if (this->GetCurrentState()->GetTransition(stateEvent->GetId())!=NULL)
{
return 0.5;
}
else
{
return 0;
}
}
//on MouseMove do nothing!
if (stateEvent->GetEvent()->GetType() == mitk::Type_MouseMove)
{
return 0;
}
//get the time of the sender to look for the right transition.
mitk::BaseRenderer* sender = stateEvent->GetEvent()->GetSender();
if (sender != NULL)
{
unsigned int timeStep = sender->GetTimeStep(m_DataNode->GetData());
//if the event can be understood and if there is a transition waiting for that event
mitk::State const* state = this->GetCurrentState(timeStep);
if (state!= NULL)
if (state->GetTransition(stateEvent->GetId())!=NULL)
returnValue = 0.5;//it can be understood
mitk::PointSet *pointSet = dynamic_cast<mitk::PointSet*>(m_DataNode->GetData());
if ( pointSet != NULL )
{
//if we have one point or more, then check if the have been picked
if ( (pointSet->GetSize( timeStep ) > 0)
&& (pointSet->SearchPoint(
disPosEvent->GetWorldPosition(), m_Precision, timeStep) > -1) )
{
returnValue = 1.0;
}
}
}
return returnValue;
}
| void mitk::PointSetInteractor::Clear | ( | unsigned int | timeStep = 0, |
| ScalarType | timeInMS = 0.0 |
||
| ) |
Clears all the elements from the given timeStep in the list with undo-functionality and resets the statemachine.
Definition at line 1060 of file mitkPointSetInteractor.cpp.
References mitk::PointSet::ExecuteOperation(), mitk::PointSet::GetPoint(), mitk::PointSet::GetPointSet(), mitk::PointSet::GetSize(), mitk::OpINSERT, and mitk::OpREMOVE.
{
mitk::Point3D point;
point.Fill(0);
mitk::PointSet *pointSet =
dynamic_cast<mitk::PointSet*>(m_DataNode->GetData());
if ( pointSet == NULL )
{
return;
}
mitk::PointSet::DataType *itkPointSet = pointSet->GetPointSet( timeStep );
if ( itkPointSet == NULL )
{
return;
}
//for reading on the points, Id's etc
mitk::PointSet::PointsContainer *points = itkPointSet->GetPoints();
mitk::PointSet::PointsIterator it, end;
it = points->Begin();
end = points->End();
while( (it != end) && (pointSet->GetSize( timeStep ) > 0) )
{
point = pointSet->GetPoint( it->Index(), timeStep );
PointOperation *doOp = new mitk::PointOperation(
OpREMOVE, timeInMS, point, it->Index());
//write to UndoMechanism
if ( m_UndoEnabled )
{
PointOperation *undoOp = new mitk::PointOperation(
OpINSERT, timeInMS, point, it->Index());
OperationEvent *operationEvent =
new OperationEvent( pointSet, doOp, undoOp );
m_UndoController->SetOperationEvent( operationEvent );
}
//execute the Operation
++it;
pointSet->ExecuteOperation( doOp );
if ( !m_UndoEnabled )
delete doOp;
}
//reset the statemachine
this->ResetStatemachineToStartState(timeStep);
}
| void mitk::PointSetInteractor::DataChanged | ( | ) | [virtual] |
If data changed then initialize according to numbers of loaded points.
Reimplemented from mitk::Interactor.
Definition at line 1170 of file mitkPointSetInteractor.cpp.
{
this->InitAccordingToNumberOfPoints();
return;
}
| bool mitk::PointSetInteractor::ExecuteAction | ( | Action * | action, |
| mitk::StateEvent const * | stateEvent | ||
| ) | [protected, virtual] |
Convert the given Actions to Operations and send to data and UndoController.
Reimplemented from mitk::StateMachine.
Reimplemented in mitk::DisplayPointSetInteractor.
Definition at line 225 of file mitkPointSetInteractor.cpp.
References mitk::AcADDPOINT, mitk::AcCHECKELEMENT, mitk::AcCHECKEQUALS1, mitk::AcCHECKNMINUS1, mitk::AcCHECKNUMBEROFPOINTS, mitk::AcCHECKONESELECTED, mitk::AcCHECKOPERATION, mitk::AcCHECKSELECTED, mitk::AcCLEAR, mitk::AcDESELECTALL, mitk::AcDESELECTOBJECT, mitk::AcDONOTHING, mitk::AcFINISHMOVEMENT, mitk::AcINITMOVEMENT, mitk::AcMOVESELECTED, mitk::AcREMOVEALL, mitk::AcREMOVEPOINT, mitk::AcSELECTPICKEDOBJECT, mitk::BS_NoButton, mitk::EIDEMPTY, mitk::EIDEQUALSN, mitk::EIDNO, mitk::EIDSMALLERN, mitk::EIDSTLARGERNMINUS1, mitk::EIDSTSMALERNMINUS1, mitk::EIDYES, mitk::PointSet::ExecuteOperation(), mitk::Action::GetActionId(), mitk::Event::GetButton(), mitk::Event::GetButtonState(), mitk::DisplayPositionEvent::GetDisplayPosition(), mitk::StateEvent::GetEvent(), mitk::RenderingManager::GetInstance(), mitk::Event::GetKey(), mitk::PointSet::GetNumberOfSelected(), mitk::PointSet::GetPoint(), mitk::PointSet::GetPointSet(), mitk::PointSet::GetSelectInfo(), mitk::Event::GetSender(), mitk::PointSet::GetSize(), mitk::BaseRenderer::GetTime(), mitk::Event::GetType(), mitk::DisplayPositionEvent::GetWorldPosition(), int(), mitk::Key_none, mitk::OpDESELECTPOINT, mitk::OpINSERT, mitk::OpMOVE, mitk::OpREMOVE, mitk::OpSELECTPOINT, mitk::RenderingManager::RequestUpdateAll(), mitk::PointSet::SearchPoint(), STATEMACHINE_DEBUG, and mitk::Type_None.
{
bool ok = false;//for return type bool
//checking corresponding Data; has to be a PointSet or a subclass
mitk::PointSet* pointSet =
dynamic_cast<mitk::PointSet*>(m_DataNode->GetData());
if ( pointSet == NULL )
{
return false;
}
//get the timestep to support 3D+T
const mitk::Event *theEvent = stateEvent->GetEvent();
mitk::ScalarType timeInMS = 0.0;
//check if the current timestep has to be changed
if ( theEvent )
{
if (theEvent->GetSender() != NULL)
{
//additionaly to m_TimeStep we need timeInMS to satisfy the execution of the operations
timeInMS = theEvent->GetSender()->GetTime();
}
}
//for reading on the points, Id's etc
mitk::PointSet::DataType *itkPointSet = pointSet->GetPointSet( m_TimeStep );
if ( itkPointSet == NULL )
{
return false;
}
mitk::PointSet::PointsContainer *points = itkPointSet->GetPoints();
/*Each case must watch the type of the event!*/
switch (action->GetActionId())
{
case AcDONOTHING:
ok = true;
break;
case AcCHECKOPERATION:
//to check if the given Event is a DisplayPositionEvent.
{
mitk::DisplayPositionEvent const *dispPosEvent =
dynamic_cast <const mitk::DisplayPositionEvent *> (
stateEvent->GetEvent());
if (dispPosEvent != NULL)
{
mitk::StateEvent* newStateEvent =
new mitk::StateEvent(EIDYES, stateEvent->GetEvent());
this->HandleEvent( newStateEvent );
delete newStateEvent;
}
else
{
mitk::StateEvent* newStateEvent =
new mitk::StateEvent(EIDNO, stateEvent->GetEvent());
this->HandleEvent( newStateEvent );
delete newStateEvent;
}
ok = true;
break;
}
case AcADDPOINT:
// Declare two operations: one for the selected state: deselect the last
// one selected and select the new one the other operation is the add
// operation: There the first empty place have to be found and the new
// point inserted into that space
{
mitk::DisplayPositionEvent const *posEvent =
dynamic_cast < const mitk::DisplayPositionEvent * >
(stateEvent->GetEvent());
// Check if it is a DisplayEvent thrown in a 3D window. Then the
// z-information is missing. Returning false might end in the state
// full, but the last point couldn't be added, so the set wouldn't be
// full. So a extra Action that checks the operationtype has been added.
if ( posEvent == NULL )
{
return false;
}
mitk::Point3D itkPoint;
itkPoint = posEvent->GetWorldPosition();
// undo-supported deselect of all points in the DataList; if List is
// empty, then nothing will be unselected
this->UnselectAll( m_TimeStep, timeInMS );
// find the position, the point is to be added to: first entry with
// empty index. If the Set is empty, then start with 0. if not empty,
// then take the first index not occupied
int lastPosition = 0;
if (!points->empty())
{
mitk::PointSet::PointsIterator it, end;
it = points->Begin();
end = points->End();
while( it != end )
{
if (!points->IndexExists(lastPosition))
break;
++it;
++lastPosition;
}
}
PointOperation* doOp = new mitk::PointOperation(
OpINSERT, timeInMS, itkPoint, lastPosition);
if (m_UndoEnabled)
{
// difference between OpDELETE and OpREMOVE is, that OpDELETE deletes
// a point at the end, and OpREMOVE deletes it from the given position
// remove is better, cause we need the position to add or remove the
// point anyway. We can get the last position from size()
PointOperation *undoOp = new mitk::PointOperation(
OpREMOVE, timeInMS, itkPoint, lastPosition);
OperationEvent *operationEvent =
new OperationEvent(pointSet, doOp, undoOp, "Add point");
m_UndoController->SetOperationEvent(operationEvent);
}
//execute the Operation
pointSet->ExecuteOperation(doOp);
if ( !m_UndoEnabled )
delete doOp;
//the point is added and directly selected in PintSet. So no need to call OpSELECTPOINT
ok = true;
// Update the display
mitk::RenderingManager::GetInstance()->RequestUpdateAll();
break;
}
case AcINITMOVEMENT:
{
mitk::PositionEvent const *posEvent = dynamic_cast <const mitk::PositionEvent *> (stateEvent->GetEvent());
if (posEvent == NULL)
return false;
// start of the Movement is stored to calculate the undoKoordinate
// in FinishMovement
m_LastPoint = posEvent->GetWorldPosition();
// initialize a value to calculate the movement through all
// MouseMoveEvents from MouseClick to MouseRelease
m_SumVec.Fill(0);
ok = true;
break;
}
case AcMOVESELECTED://moves all selected Elements
{
mitk::PositionEvent const *posEvent = dynamic_cast <const mitk::PositionEvent *> (stateEvent->GetEvent());
if (posEvent == NULL)
return false;
mitk::Point3D newPoint, resultPoint;
newPoint = posEvent->GetWorldPosition();
// search the elements in the list that are selected then calculate the
// vector, because only with the vector we can move several elements in
// the same direction
// newPoint - lastPoint = vector
// then move all selected and set the lastPoint = newPoint.
// then add all vectors to a summeryVector (to be able to calculate the
// startpoint for undoOperation)
mitk::Vector3D dirVector = newPoint - m_LastPoint;
//sum up all Movement for Undo in FinishMovement
m_SumVec = m_SumVec + dirVector;
mitk::PointSet::PointsIterator it, end;
it = points->Begin();
end = points->End();
while( it != end )
{
int position = it->Index();
if ( pointSet->GetSelectInfo(position, m_TimeStep) )//if selected
{
PointSet::PointType pt = pointSet->GetPoint(position, m_TimeStep);
mitk::Point3D sumVec;
sumVec[0] = pt[0];
sumVec[1] = pt[1];
sumVec[2] = pt[2];
resultPoint = sumVec + dirVector;
PointOperation* doOp = new mitk::PointOperation(OpMOVE, timeInMS,
resultPoint, position);
//execute the Operation
//here no undo is stored, because the movement-steps aren't interesting.
// only the start and the end is interisting to store for undo.
pointSet->ExecuteOperation(doOp);
delete doOp;
}
++it;
}
m_LastPoint = newPoint;//for calculation of the direction vector
ok = true;
// Update the display
mitk::RenderingManager::GetInstance()->RequestUpdateAll();
break;
}
case AcREMOVEPOINT://remove the given Point from the list
{
//if the point to be removed is given by the positionEvent:
mitk::PositionEvent const *posEvent =
dynamic_cast <const mitk::PositionEvent *> (stateEvent->GetEvent());
if (posEvent != NULL)
{
mitk::Point3D itkPoint;
itkPoint = posEvent->GetWorldPosition();
//search the point in the list
int position = pointSet->SearchPoint(itkPoint, 0.0, m_TimeStep);
//distance set to 0, cause we already got the exact point from last
//State checkpointbut we also need the position in the list to remove it
if (position>=0)//found a point
{
PointSet::PointType pt = pointSet->GetPoint(position, m_TimeStep);
itkPoint[0] = pt[0];
itkPoint[1] = pt[1];
itkPoint[2] = pt[2];
//Undo
PointOperation* doOp = new mitk::PointOperation(OpREMOVE,
timeInMS, itkPoint, position);
if (m_UndoEnabled) //write to UndoMechanism
{
PointOperation* undoOp = new mitk::PointOperation(OpINSERT,
timeInMS, itkPoint, position);
OperationEvent *operationEvent = new OperationEvent(pointSet,
doOp, undoOp, "Remove point");
m_UndoController->SetOperationEvent(operationEvent);
}
//execute the Operation
pointSet->ExecuteOperation(doOp);
if ( !m_UndoEnabled )
delete doOp;
/*now select the point "position-1",
and if it is the first in list,
then contine at the last in list*/
//only then a select of a point is possible!
if (pointSet->GetSize( m_TimeStep ) > 0)
{
if (position>0)//not the first in list
{
this->SelectPoint( position-1, m_TimeStep, timeInMS );
}
//it was the first point in list, that was removed, so select
//the last in list
else
{
position = pointSet->GetSize( m_TimeStep ) - 1; //last in list
this->SelectPoint( position, m_TimeStep, timeInMS );
}//else
}//if
ok = true;
}
}
else //no position is given so remove all selected elements
{
//delete all selected points
//search for the selected one and then declare the operations!
mitk::PointSet::PointsContainer::Iterator it, end;
it = points->Begin();
end = points->End();
int position = 0;
int previousExistingPosition = -1;//to recognize the last existing position; needed because the iterator gets invalid if the point is deleted!
int lastDelPrevExistPosition = -1; //the previous position of the last deleted point
while (it != end)
{
if (points->IndexExists(it->Index()))
{
//if point is selected
if ( pointSet->GetSelectInfo(it->Index(), m_TimeStep) )
{
//get the coordinates of that point to be undoable
PointSet::PointType selectedPoint = it->Value();
mitk::Point3D itkPoint;
itkPoint[0] = selectedPoint[0];
itkPoint[1] = selectedPoint[1];
itkPoint[2] = selectedPoint[2];
position = it->Index();
PointOperation* doOp = new mitk::PointOperation(OpREMOVE,
timeInMS, itkPoint, position);
//Undo
if (m_UndoEnabled) //write to UndoMechanism
{
PointOperation* undoOp = new mitk::PointOperation(OpINSERT,
timeInMS, itkPoint, position);
OperationEvent *operationEvent = new OperationEvent(pointSet,
doOp, undoOp, "Remove point");
m_UndoController->SetOperationEvent(operationEvent);
}
pointSet->ExecuteOperation(doOp);
if ( !m_UndoEnabled )
delete doOp;
//after delete the iterator is undefined, so start again
//count to the last existing entry
if (points->Size()>1 && points->IndexExists(previousExistingPosition))
{
for (it = points->Begin(); it != points->End(); it++)
{
if (it->Index() == (unsigned int) previousExistingPosition)
{
lastDelPrevExistPosition = previousExistingPosition;
break; //return if the iterator on the last existing position is found
}
}
}
else // size <= 1 or no previous existing position set
{
//search for the first existing position
for (it = points->Begin(); it != points->End(); it++)
if (points->IndexExists(it->Index()))
{
previousExistingPosition = it->Index();
break;
}
}
//now that we have set the iterator, lets get sure, that the next it++ will not crash!
if (it == end) { break; }
}//if
else
{
previousExistingPosition = it->Index();
}
}//if index exists
it++;
}//while
if (lastDelPrevExistPosition < 0)//the var has not been set because the first element was deleted and there was no prev position
lastDelPrevExistPosition = previousExistingPosition; //go to the end
/*
* now select the point before the point/points that was/were deleted
*/
if (pointSet->GetSize( m_TimeStep ) > 0) //only then a select of a point is possible!
{
if (points->IndexExists(lastDelPrevExistPosition))
{
this->SelectPoint( lastDelPrevExistPosition, m_TimeStep, timeInMS );
}
else
{
//select the first existing element
for (mitk::PointSet::PointsContainer::Iterator it = points->Begin(); it != points->End(); it++)
if (points->IndexExists(it->Index()))
{
this->SelectPoint( it->Index(), m_TimeStep, timeInMS );
break;
}
}
}//if
ok = true;
}//else
}//case
// Update the display
mitk::RenderingManager::GetInstance()->RequestUpdateAll();
break;
// Remove all Points that have been set at once.
// TODO: Undo function not supported yet.
case AcREMOVEALL:
{
if ( !points->empty() )
{
PointSet::PointType pt;
mitk::PointSet::PointsContainer::Iterator it, end;
it = points->Begin();
end = points->End();
int position = 0;
while ( it != end )
{
position = it->Index();
if ( points->IndexExists( position ) )
{
pt = pointSet->GetPoint( position, m_TimeStep );
PointOperation* doOp =
new mitk::PointOperation( OpREMOVE, timeInMS, pt, position );
++it;
pointSet->ExecuteOperation( doOp );
delete doOp;
}
else it++;
}
}
ok = true;
// Update the display
mitk::RenderingManager::GetInstance()->RequestUpdateAll();
break;
}
//Checking if the Point transmitted is close enough to one point. Then
//generate a new event with the point and let this statemaschine
//handle the event.
case AcCHECKELEMENT:
{
mitk::PositionEvent const *posEvent =
dynamic_cast <const mitk::PositionEvent *> (stateEvent->GetEvent());
if (posEvent != NULL)
{
mitk::Point3D worldPoint = posEvent->GetWorldPosition();
int position = pointSet->SearchPoint( worldPoint, m_Precision, m_TimeStep );
if (position>=0)//found a point near enough to the given point
{
//get that point, the one meant by the user!
PointSet::PointType pt = pointSet->GetPoint(position, m_TimeStep);
mitk::Point2D displPoint;
displPoint[0] = worldPoint[0]; displPoint[1] = worldPoint[1];
//new Event with information YES and with the correct point
mitk::PositionEvent const* newPosEvent =
new mitk::PositionEvent(posEvent->GetSender(), Type_None,
BS_NoButton, BS_NoButton, Key_none, displPoint, pt);
mitk::StateEvent* newStateEvent =
new mitk::StateEvent(EIDYES, newPosEvent);
//call HandleEvent to leave the guard-state
this->HandleEvent( newStateEvent );
delete newStateEvent;
delete newPosEvent;
ok = true;
}
else
{
//new Event with information NO
mitk::StateEvent* newStateEvent = new mitk::StateEvent(EIDNO, posEvent);
this->HandleEvent(newStateEvent );
delete newStateEvent;
ok = true;
}
}
else
{
STATEMACHINE_DEBUG("OperationError")<<this->GetType()<<" AcCHECKELEMENT expected PointOperation.";
mitk::DisplayPositionEvent const *disPosEvent =
dynamic_cast <const mitk::DisplayPositionEvent *> (
stateEvent->GetEvent());
if (disPosEvent != NULL)
{ //2d Koordinates for 3D Interaction; return false to redo
//the last statechange
mitk::StateEvent* newStateEvent =
new mitk::StateEvent(EIDNO, disPosEvent);
this->HandleEvent(newStateEvent );
delete newStateEvent;
ok = true;
}
}
break;
}
case AcCHECKONESELECTED:
//check if there is a point that is selected
{
if (pointSet->GetNumberOfSelected(m_TimeStep)>0)
{
mitk::StateEvent* newStateEvent =
new mitk::StateEvent( EIDYES, theEvent);
this->HandleEvent( newStateEvent );
delete newStateEvent;
}
else //not selected then call event EIDNO
{
//new Event with information NO
mitk::StateEvent* newStateEvent =
new mitk::StateEvent( EIDNO, theEvent);
this->HandleEvent( newStateEvent );
delete newStateEvent;
}
ok = true;
break;
}
case AcCHECKSELECTED:
/*check, if the given point is selected:
if no, then send EIDNO
if yes, then send EIDYES*/
// check, if: because of the need to look up the point again, it is
// possible, that we grab the wrong point in case there are two same points
// so maybe we do have to set a global index for further computation,
// as long, as the mouse is moved...
{
int position = -1;
mitk::PositionEvent const *posEvent =
dynamic_cast <const mitk::PositionEvent *> (stateEvent->GetEvent());
if (posEvent == NULL)
return false;
mitk::Point3D worldPoint = posEvent->GetWorldPosition();
position = pointSet->SearchPoint(worldPoint, m_Precision, m_TimeStep);
if (position>=0)
{
mitk::PositionEvent const *newPosEvent =
new mitk::PositionEvent(posEvent->GetSender(),
posEvent->GetType(), posEvent->GetButton(),
posEvent->GetButtonState(), posEvent->GetKey(),
posEvent->GetDisplayPosition(), posEvent->GetWorldPosition());
//if selected on true, then call Event EIDYES
if (pointSet->GetSelectInfo(position, m_TimeStep))
{
mitk::StateEvent* newStateEvent =
new mitk::StateEvent( EIDYES, newPosEvent );
this->HandleEvent( newStateEvent );
delete newStateEvent;
ok = true;
//saving the spot for calculating the direction vector in moving
m_LastPoint = posEvent->GetWorldPosition();
}
else //not selected then call event EIDNO
{
//new Event with information NO
mitk::StateEvent* newStateEvent =
new mitk::StateEvent( EIDNO, newPosEvent );
this->HandleEvent( newStateEvent );
delete newStateEvent;
ok = true;
}
delete newPosEvent;
}
//the position wasn't set properly. If necessary: search the given
//point in list and set var position
else
{
/*
mitk::StatusBar::GetInstance()->DisplayText(
"Message from mitkPointSetInteractor: Error in Actions! Check Config XML-file",
10000);
*/
ok = false;
}
break;
}
//generate Events if the set will be full after the addition of the
// point or not.
case AcCHECKNMINUS1:
{
// number of points not limited->pass on
// "Amount of points in Set is smaller then N-1"
if (m_N<0)
{
mitk::StateEvent* newStateEvent =
new mitk::StateEvent(EIDSTSMALERNMINUS1, stateEvent->GetEvent());
this->HandleEvent( newStateEvent );
delete newStateEvent;
ok = true;
}
else
{
if (pointSet->GetSize( m_TimeStep ) < m_N-1 )
//pointset after addition won't be full
{
mitk::StateEvent* newStateEvent =
new mitk::StateEvent(EIDSTSMALERNMINUS1, stateEvent->GetEvent());
this->HandleEvent( newStateEvent );
delete newStateEvent;
ok = true;
}
else
//after the addition of a point, the container will be full
{
mitk::StateEvent* newStateEvent =
new mitk::StateEvent(EIDSTLARGERNMINUS1, stateEvent->GetEvent());
this->HandleEvent(newStateEvent );
delete newStateEvent;
ok = true;
}//else
}//else
}
break;
case AcCHECKEQUALS1:
{
//the number of points in the list is 1 (or smaler)
if (pointSet->GetSize( m_TimeStep ) <= 1)
{
mitk::StateEvent* newStateEvent =
new mitk::StateEvent(EIDYES, stateEvent->GetEvent());
this->HandleEvent( newStateEvent );
delete newStateEvent;
ok = true;
}
else //more than 1 points in list, so stay in the state!
{
mitk::StateEvent* newStateEvent =
new mitk::StateEvent(EIDNO, stateEvent->GetEvent());
this->HandleEvent(newStateEvent );
delete newStateEvent;
ok = true;
}
}
break;
case AcCHECKNUMBEROFPOINTS:
{
//the number of points in the list is 1 (or smaler), so will be empty after delete
if (pointSet->GetSize( m_TimeStep ) <= 1)
{
mitk::StateEvent* newStateEvent =
new mitk::StateEvent(EIDEMPTY, stateEvent->GetEvent());
this->HandleEvent( newStateEvent );
delete newStateEvent;
ok = true;
}
else if (pointSet->GetSize( m_TimeStep ) <= m_N || m_N <= -1)
//m_N is set to unlimited points allowed or more than 1 points in list, but not full, so stay in the state!
{
mitk::StateEvent* newStateEvent =
new mitk::StateEvent(EIDSMALLERN, stateEvent->GetEvent());
this->HandleEvent(newStateEvent );
delete newStateEvent;
ok = true;
}
else
//pointSet->GetSize( m_TimeStep ) >=m_N.
// This can happen if the points were not added
// by interaction but by loading a .mps file
{
mitk::StateEvent* newStateEvent =
new mitk::StateEvent(EIDEQUALSN, stateEvent->GetEvent());
this->HandleEvent(newStateEvent );
delete newStateEvent;
ok = true;
}
}
break;
case AcSELECTPICKEDOBJECT://and deselect others
{
mitk::PositionEvent const *posEvent =
dynamic_cast <const mitk::PositionEvent *> (stateEvent->GetEvent());
if (posEvent == NULL) return false;
mitk::Point3D itkPoint;
itkPoint = posEvent->GetWorldPosition();
//search the point in the list
int position = pointSet->SearchPoint(itkPoint, 0.0, m_TimeStep);
//distance set to 0, cause we already got the exact point from last
//State checkpoint but we also need the position in the list to move it
if (position>=0)//found a point
{
//first deselect the other points
//undoable deselect of all points in the DataList
this->UnselectAll( m_TimeStep, timeInMS);
PointOperation* doOp = new mitk::PointOperation(OpSELECTPOINT,
timeInMS, itkPoint, position);
//Undo
if (m_UndoEnabled) //write to UndoMechanism
{
PointOperation* undoOp = new mitk::PointOperation(OpDESELECTPOINT,
timeInMS, itkPoint, position);
OperationEvent *operationEvent =
new OperationEvent(pointSet, doOp, undoOp);
m_UndoController->SetOperationEvent(operationEvent);
}
//execute the Operation
pointSet->ExecuteOperation(doOp);
if ( !m_UndoEnabled )
delete doOp;
ok = true;
}
// Update the display
mitk::RenderingManager::GetInstance()->RequestUpdateAll();
break;
}
case AcDESELECTOBJECT:
{
mitk::PositionEvent const *posEvent =
dynamic_cast <const mitk::PositionEvent *> (stateEvent->GetEvent());
if (posEvent == NULL)
return false;
mitk::Point3D itkPoint;
itkPoint = posEvent->GetWorldPosition();
//search the point in the list
int position = pointSet->SearchPoint(itkPoint, 0.0, m_TimeStep);
//distance set to 0, cause we already got the exact point from last
// State checkpoint but we also need the position in the list to move it
if (position>=0)//found a point
{
//Undo
PointOperation* doOp = new mitk::PointOperation(OpDESELECTPOINT,
timeInMS, itkPoint, position);
if (m_UndoEnabled) //write to UndoMechanism
{
PointOperation* undoOp = new mitk::PointOperation(OpSELECTPOINT,
timeInMS, itkPoint, position);
OperationEvent *operationEvent = new OperationEvent(pointSet, doOp, undoOp);
m_UndoController->SetOperationEvent(operationEvent);
}
//execute the Operation
pointSet->ExecuteOperation(doOp);
if ( !m_UndoEnabled )
delete doOp;
ok = true;
}
// Update the display
mitk::RenderingManager::GetInstance()->RequestUpdateAll();
break;
}
case AcDESELECTALL:
{
//undo-supported able deselect of all points in the DataList
this->UnselectAll( m_TimeStep, timeInMS );
ok = true;
// Update the display
mitk::RenderingManager::GetInstance()->RequestUpdateAll();
break;
}
case AcFINISHMOVEMENT:
{
mitk::PositionEvent const *posEvent =
dynamic_cast <const mitk::PositionEvent *> (stateEvent->GetEvent());
if (posEvent == NULL)
return false;
//finish the movement:
//the final point is m_LastPoint
//m_SumVec stores the movement in a vector
//the operation would not be necessary, but we need it for the undo Operation.
//m_LastPoint is for the Operation
//the point for undoOperation calculates from all selected
//elements (point) - m_SumVec
//search all selected elements and move them with undo-functionality.
mitk::PointSet::PointsIterator it, end;
it = points->Begin();
end = points->End();
while( it != end )
{
int position = it->Index();
if ( pointSet->GetSelectInfo(position, m_TimeStep) )//if selected
{
PointSet::PointType pt = pointSet->GetPoint(position, m_TimeStep);
Point3D itkPoint;
itkPoint[0] = pt[0];
itkPoint[1] = pt[1];
itkPoint[2] = pt[2];
PointOperation* doOp = new mitk::PointOperation(OpMOVE,
timeInMS, itkPoint, position);
if ( m_UndoEnabled )//&& (posEvent->GetType() == mitk::Type_MouseButtonRelease)
{
//set the undo-operation, so the final position is undo-able
//calculate the old Position from the already moved position - m_SumVec
mitk::Point3D undoPoint = ( itkPoint - m_SumVec );
PointOperation* undoOp =
new mitk::PointOperation(OpMOVE, timeInMS, undoPoint, position);
OperationEvent *operationEvent =
new OperationEvent(pointSet, doOp, undoOp, "Move point");
m_UndoController->SetOperationEvent(operationEvent);
}
//execute the Operation
pointSet->ExecuteOperation(doOp);
if ( !m_UndoEnabled )
delete doOp;
}
++it;
}
//set every variable for movement calculation to zero
// commented out: increases usebility in derived classes.
/*m_LastPoint.Fill(0);
m_SumVec.Fill(0);*/
//increase the GroupEventId, so that the Undo goes to here
this->IncCurrGroupEventId();
ok = true;
// Update the display
mitk::RenderingManager::GetInstance()->RequestUpdateAll();
break;
}
case AcCLEAR:
{
this->Clear( m_TimeStep, timeInMS );
// Update the display
mitk::RenderingManager::GetInstance()->RequestUpdateAll();
break;
}
default:
return Superclass::ExecuteAction( action, stateEvent );
}
// indicate modification of data tree node
m_DataNode->Modified();
return ok;
}
| virtual const char* mitk::PointSetInteractor::GetClassName | ( | ) | const [virtual] |
Reimplemented from mitk::Interactor.
Reimplemented in mitk::MouseMovePointSetInteractor, and mitk::DisplayPointSetInteractor.
| static Pointer mitk::PointSetInteractor::New | ( | const char * | _arga, |
| DataNode * | _argb, | ||
| int | _argc | ||
| ) | [inline, static] |
Reimplemented in mitk::MouseMovePointSetInteractor, and mitk::DisplayPointSetInteractor.
Definition at line 48 of file mitkPointSetInteractor.h.
Referenced by Step6::Initialize(), main(), mitkGlobalInteractionTest(), QmitkPointListWidget::OnBtnAddPoint(), QmitkSimpleMeasurement::OnSelectionChanged(), QmitkPointListModel::RemoveSelectedPoint(), mitkDataNodeTestClass::TestInteractorSetting(), mitkPointSetInteractorTestClass::TestOnlyMovePointSetInteractor(), mitkPointSetInteractorTestClass::TestPointSetInteractor(), mitkPointSetInteractorTestClass::TestSeedPointSetInteractor(), and mitkPointSetInteractorTestClass::TestSinglePointSetInteractorWithoutShiftClick().
:
| static Pointer mitk::PointSetInteractor::New | ( | const char * | _arga, |
| DataNode * | _argb | ||
| ) | [inline, static] |
NewMacro with two parameters for calling itk::Lightobject::New(..) method.
Reimplemented from mitk::Interactor.
Reimplemented in mitk::MouseMovePointSetInteractor, and mitk::DisplayPointSetInteractor.
Definition at line 49 of file mitkPointSetInteractor.h.
:
| void mitk::PointSetInteractor::SelectPoint | ( | int | position, |
| unsigned int | timeStep = 0, |
||
| ScalarType | timeInMS = 0.0 |
||
| ) | [protected] |
Selects the point. supports Undo if enabled.
| position | Needed for declaring operations |
Definition at line 190 of file mitkPointSetInteractor.cpp.
References mitk::PointSet::ExecuteOperation(), mitk::PointSet::GetSize(), mitk::OpDESELECTPOINT, and mitk::OpSELECTPOINT.
{
mitk::PointSet *pointSet = dynamic_cast< mitk::PointSet * >(
m_DataNode->GetData() );
//if List is empty, then no select of a point can be done!
if ( (pointSet == NULL) || (pointSet->GetSize( timeStep ) <= 0) )
{
return;
}
//dummyPoint... not needed anyway
mitk::Point3D noPoint;
noPoint.Fill(0);
mitk::PointOperation *doOp = new mitk::PointOperation(
OpSELECTPOINT, timeInMS, noPoint, position);
if ( m_UndoEnabled )
{
mitk::PointOperation* undoOp = new mitk::PointOperation(
OpDESELECTPOINT, timeInMS, noPoint, position);
OperationEvent *operationEvent = new OperationEvent(pointSet, doOp, undoOp);
m_UndoController->SetOperationEvent(operationEvent);
}
pointSet->ExecuteOperation( doOp );
if ( !m_UndoEnabled )
delete doOp;
}
| void mitk::PointSetInteractor::SetPrecision | ( | unsigned int | precision ) |
Sets the amount of precision.
Definition at line 60 of file mitkPointSetInteractor.cpp.
{
m_Precision = precision;
}
| void mitk::PointSetInteractor::UnselectAll | ( | unsigned int | timeStep = 0, |
| ScalarType | timeInMS = 0.0 |
||
| ) | [protected] |
Deselects the Points in the PointSet. supports Undo if enabled.
Definition at line 139 of file mitkPointSetInteractor.cpp.
References mitk::PointSet::ExecuteOperation(), mitk::PointSet::GetPointSet(), mitk::OpDESELECTPOINT, mitk::OpSELECTPOINT, and mitk::PointSet::PointDataType::selected.
{
mitk::PointSet *pointSet =
dynamic_cast<mitk::PointSet*>( m_DataNode->GetData() );
if ( pointSet == NULL )
{
return;
}
mitk::PointSet::DataType *itkPointSet = pointSet->GetPointSet( timeStep );
if ( itkPointSet == NULL )
{
return;
}
mitk::PointSet::PointsContainer::Iterator it, end;
end = itkPointSet->GetPoints()->End();
for (it = itkPointSet->GetPoints()->Begin(); it != end; it++)
{
int position = it->Index();
PointSet::PointDataType pointData = {0, false, PTUNDEFINED};
itkPointSet->GetPointData( position, &pointData );
//then declare an operation which unselects this point;
//UndoOperation as well!
if ( pointData.selected )
{
mitk::Point3D noPoint;
noPoint.Fill( 0 );
mitk::PointOperation *doOp = new mitk::PointOperation(
OpDESELECTPOINT, timeInMS, noPoint, position);
if ( m_UndoEnabled )
{
mitk::PointOperation *undoOp =
new mitk::PointOperation(OpSELECTPOINT, timeInMS, noPoint, position);
OperationEvent *operationEvent =
new OperationEvent( pointSet, doOp, undoOp );
m_UndoController->SetOperationEvent( operationEvent );
}
pointSet->ExecuteOperation( doOp );
if ( !m_UndoEnabled )
delete doOp;
}
}
}
Point3D mitk::PointSetInteractor::m_LastPoint [protected] |
to calculate a direction vector from last point and actual point
Definition at line 107 of file mitkPointSetInteractor.h.
Referenced by PointSetInteractor().
Vector3D mitk::PointSetInteractor::m_SumVec [protected] |
summ-vector for Movement
Definition at line 110 of file mitkPointSetInteractor.h.
Referenced by PointSetInteractor().
1.7.2
