Interaction with a point. More...
#include <mitkPointInteractor.h>
Public Types | |
| typedef PointInteractor | Self |
| typedef Interactor | Superclass |
| typedef itk::SmartPointer< Self > | Pointer |
| typedef itk::SmartPointer < const Self > | ConstPointer |
Public Member Functions | |
| virtual const char * | GetClassName () const |
| void | SetPrecision (unsigned int precision) |
| Sets the amount of precision. | |
| virtual float | CanHandleEvent (StateEvent const *stateEvent) const |
| derived from mitk::Interactor; calculates Jurisdiction according to points | |
Static Public Member Functions | |
| static Pointer | New (const char *_arga, DataNode *_argb) |
| NewMacro with two parameters for calling itk::Lightobject::New(..) method. | |
Protected Member Functions | |
| PointInteractor (const char *type, DataNode *dataNode) | |
| Constructor. | |
| virtual | ~PointInteractor () |
| Destructor. | |
| virtual void | SelectPoint (int position) |
| select the point on the given position | |
| virtual void | DeselectAllPoints () |
| unselect all points that exist in mesh | |
| virtual bool | ExecuteAction (Action *action, mitk::StateEvent const *stateEvent) |
| Executes Actions. | |
Interaction with a point.
Interact with a point: set point, select point, move point and remove point All Set-operations are done through the method "ExecuteAction". the identificationnumber of this point is set by this points and evalued from an empty place in the DataStructure
Definition at line 38 of file mitkPointInteractor.h.
| typedef itk::SmartPointer<const Self> mitk::PointInteractor::ConstPointer |
Reimplemented from mitk::Interactor.
Definition at line 41 of file mitkPointInteractor.h.
| typedef itk::SmartPointer<Self> mitk::PointInteractor::Pointer |
Reimplemented from mitk::Interactor.
Definition at line 41 of file mitkPointInteractor.h.
Reimplemented from mitk::Interactor.
Definition at line 41 of file mitkPointInteractor.h.
Reimplemented from mitk::Interactor.
Definition at line 41 of file mitkPointInteractor.h.
| mitk::PointInteractor::PointInteractor | ( | const char * | type, |
| DataNode * | dataNode | ||
| ) | [protected] |
Constructor.
Definition at line 35 of file mitkPointInteractor.cpp.
: Interactor(type, dataNode), m_LastPosition(0) { m_LastPoint.Fill(0); }
| mitk::PointInteractor::~PointInteractor | ( | ) | [protected, virtual] |
| float mitk::PointInteractor::CanHandleEvent | ( | StateEvent const * | stateEvent ) | const [virtual] |
derived from mitk::Interactor; calculates Jurisdiction according to points
standard method can not be used, since it doesn't calculate in points, only in BoundingBox of Points
Reimplemented from mitk::Interactor.
Definition at line 96 of file mitkPointInteractor.cpp.
References QuadProgPP::distance(), mitk::PointSet::GetPointSet(), mitk::DisplayPositionEvent::GetWorldPosition(), mitk::PointSet::SearchPoint(), and mitk::Type_MouseMove.
{
float returnValue = 0;
mitk::PositionEvent const *posEvent = dynamic_cast <const mitk::PositionEvent *> (stateEvent->GetEvent());
//checking if a keyevent can be handled:
if (posEvent == NULL)
{
//check, if the current state has a transition waiting for that key event.
if (this->GetCurrentState()->GetTransition(stateEvent->GetId())!=NULL)
{
return 0.5;
}
else
{
return 0;
}
}
//Mouse event handling:
//on MouseMove do nothing! reimplement if needed differently
if (stateEvent->GetEvent()->GetType() == mitk::Type_MouseMove)
{
return 0;
}
//if the event can be understood and if there is a transition waiting for that event
if (this->GetCurrentState()->GetTransition(stateEvent->GetId())!=NULL)
{
returnValue = 0.5;//it can be understood
}
//check on the right data-type
mitk::PointSet* pointSet = dynamic_cast<mitk::PointSet*>(m_DataNode->GetData());
if (pointSet == NULL)
return 0;
//since we now have 3D picking in GlobalInteraction and all events send are DisplayEvents with 3D information,
//we concentrate on 3D coordinates
mitk::Point3D worldPoint = posEvent->GetWorldPosition();
float p[3];
itk2vtk(worldPoint, p);
//transforming the Worldposition to local coordinatesystem
m_DataNode->GetData()->GetGeometry()->GetVtkTransform()->GetInverse()->TransformPoint(p, p);
vtk2itk(p, worldPoint);
float distance = 5;
int index = pointSet->SearchPoint(worldPoint, distance);
if (index>-1)
//how far away is the line from the point?
{
//get the point and calculate the jurisdiction out of it.
mitk::PointSet::PointType point;
pointSet->GetPointSet()->GetPoint(index, &point);
returnValue = point.EuclideanDistanceTo(worldPoint);
//between 1 and 0. 1 if directly hit
returnValue = 1 - ( returnValue / distance );
if (returnValue<0 || returnValue>1)
{
itkWarningMacro("Difficulties in calculating Jurisdiction. Check PointInteractor");
return 0;
}
//and now between 0,5 and 1
returnValue = 0.5 + (returnValue / 2);
return returnValue;
}
else //not found
{
return returnValue;
}
}
| void mitk::PointInteractor::DeselectAllPoints | ( | ) | [protected, virtual] |
unselect all points that exist in mesh
Definition at line 64 of file mitkPointInteractor.cpp.
References mitk::PointSet::ExecuteOperation(), mitk::PointSet::GetPointSet(), mitk::OpDESELECTPOINT, mitk::OpSELECTPOINT, and mitk::PointSet::PointDataType::selected.
{
mitk::PointSet* pointSet = dynamic_cast<mitk::PointSet*>(m_DataNode->GetData());
if (pointSet == NULL)
return;
mitk::PointSet::DataType *itkPointSet = pointSet->GetPointSet();
mitk::PointSet::PointsContainer::Iterator it, end;
end = itkPointSet->GetPoints()->End();
for (it = itkPointSet->GetPoints()->Begin(); it != end; it++)
{
int position = it->Index();
PointSet::PointDataType pointData = {0, false, PTUNDEFINED};
itkPointSet->GetPointData(position, &pointData);
if ( pointData.selected )//then declare an operation which unselects this point; UndoOperation as well!
{
mitk::Point3D noPoint;
noPoint.Fill(0);
mitk::PointOperation* doOp = new mitk::PointOperation(OpDESELECTPOINT, noPoint, position);
if (m_UndoEnabled)
{
mitk::PointOperation* undoOp = new mitk::PointOperation(OpSELECTPOINT, noPoint, position);
OperationEvent *operationEvent = new OperationEvent(pointSet, doOp, undoOp);
m_UndoController->SetOperationEvent(operationEvent);
}
pointSet->ExecuteOperation(doOp);
}
}
}
| bool mitk::PointInteractor::ExecuteAction | ( | Action * | action, |
| mitk::StateEvent const * | stateEvent | ||
| ) | [protected, virtual] |
Executes Actions.
Reimplemented from mitk::StateMachine.
Definition at line 175 of file mitkPointInteractor.cpp.
References mitk::AcADDPOINT, mitk::AcCHECKELEMENT, mitk::AcCHECKGREATERONE, mitk::AcCHECKSELECTED, mitk::AcDESELECT, mitk::AcDESELECTALL, mitk::AcFINISHMOVEMENT, mitk::AcINITMOVEMENT, mitk::AcMOVESELECTED, mitk::AcREMOVEPOINT, mitk::AcSELECT, mitk::AcSELECTANOTHEROBJECT, mitk::AcSETSTARTPOINT, mitk::EIDNO, mitk::EIDYES, mitk::PointSet::ExecuteOperation(), mitk::Action::GetActionId(), mitk::Event::GetButton(), mitk::Event::GetButtonState(), mitk::StateEvent::GetEvent(), mitk::Event::GetKey(), mitk::PointSet::GetPoint(), mitk::PointSet::GetPointSet(), mitk::Action::GetProperty(), mitk::Event::GetSender(), mitk::PointSet::GetSize(), mitk::Event::GetType(), mitk::GenericProperty< T >::GetValue(), mitk::DisplayPositionEvent::GetWorldPosition(), int(), mitk::OpDESELECTPOINT, mitk::OpINSERT, mitk::OpINSERTPOINT, mitk::OpMOVE, mitk::OpREMOVE, mitk::OpREMOVEPOINT, mitk::OpSELECTPOINT, mitk::OpSETPOINTTYPE, PRECISION, mitk::PointSet::SearchPoint(), and mitk::PointSet::SearchSelectedPoint().
{
bool ok = false;//for return type bool
//checking corresponding Data; has to be a PointSet or a subclass
mitk::PointSet* pointSet = dynamic_cast<mitk::PointSet*>(m_DataNode->GetData());
if (pointSet == NULL)
return false;
//for reading on the points, Id's etc
mitk::PointSet::DataType *itkPointSet = pointSet->GetPointSet();
mitk::PointSet::PointsContainer *itkPoints = itkPointSet->GetPoints();
/*Each case must watch the type of the event!*/
switch (action->GetActionId())
{
case AcADDPOINT:
{
mitk::PositionEvent const *posEvent = dynamic_cast <const mitk::PositionEvent *> (stateEvent->GetEvent());
if (posEvent == NULL)
return false;
mitk::Point3D itkPoint;
itkPoint = posEvent->GetWorldPosition();
//find the position, the point is to be added to: first entry with empty index.
//if the Set is empty, then start with 0. if not empty, then take the first index not occupied
int lastPosition = 0;
if (!itkPoints->empty())
{
mitk::PointSet::PointsIterator it, end;
it = itkPoints->Begin();
end = itkPoints->End();
while( it != end )
{
if (!itkPoints->IndexExists(lastPosition))
break;
++it;
++lastPosition;
}
}
PointOperation* doOp = new mitk::PointOperation(OpINSERT, itkPoint, lastPosition);
if (m_UndoEnabled)
{
PointOperation* undoOp = new mitk::PointOperation(OpREMOVE, itkPoint, lastPosition);
OperationEvent *operationEvent = new OperationEvent(pointSet, doOp, undoOp, "Add point");
m_UndoController->SetOperationEvent(operationEvent);
}
pointSet->ExecuteOperation(doOp);
ok = true;
break;
}
case AcDESELECTALL:
this->DeselectAllPoints();
ok = true;
break;
case AcCHECKELEMENT :
/*checking if the Point transmitted is close enough to one point. Then generate a new event with the point and let this statemaschine handle the event.*/
{
mitk::PositionEvent const *posEvent = dynamic_cast <const mitk::PositionEvent *> (stateEvent->GetEvent());
if (posEvent != NULL)
{
mitk::Point3D worldPoint = posEvent->GetWorldPosition();
int PRECISION = 4;
mitk::IntProperty *precision = dynamic_cast<IntProperty*>(action->GetProperty("PRECISION"));
if (precision != NULL)
{
PRECISION = precision->GetValue();
}
int position = pointSet->SearchPoint(worldPoint, PRECISION);
if (position>=0)//found a point near enough to the given point
{
m_LastPosition = position;//store it to be able to move the point
worldPoint = pointSet->GetPoint(position);//get that point, the one meant by the user!
mitk::Point2D displPoint;
displPoint[0] = worldPoint[0];
displPoint[1] = worldPoint[1];
//new Event with information YES and with the correct point
mitk::PositionEvent const* newPosEvent = new mitk::PositionEvent(posEvent->GetSender(), posEvent->GetType(),
posEvent->GetButton(), posEvent->GetButtonState(), posEvent->GetKey(),
displPoint, worldPoint);
mitk::StateEvent* newStateEvent = new mitk::StateEvent(EIDYES, newPosEvent);
//call HandleEvent to leave the guard-state
this->HandleEvent( newStateEvent );
ok = true;
}
else
{
//new Event with information NO
mitk::StateEvent* newStateEvent = new mitk::StateEvent(EIDNO, posEvent);
this->HandleEvent( newStateEvent );
ok = true;
}
}
else //hardly used, due to 3dPicking of globalInteraction
{
mitk::DisplayPositionEvent const *disPosEvent = dynamic_cast <const mitk::DisplayPositionEvent *> (stateEvent->GetEvent());
if (disPosEvent != NULL)
{//2d Koordinates for 3D Interaction; return false to redo the last statechange
mitk::StateEvent* newStateEvent = new mitk::StateEvent(EIDNO, posEvent);
this->HandleEvent( newStateEvent );
ok = true;
}
}
}
break;
case AcCHECKSELECTED:
//check if the point that was hit before is still hit
{
mitk::PositionEvent const *posEvent = dynamic_cast <const mitk::PositionEvent *> (stateEvent->GetEvent());
if (posEvent != NULL)
{
mitk::Point3D worldPoint = posEvent->GetWorldPosition();
int PRECISION = 4;
mitk::IntProperty *precision = dynamic_cast<IntProperty*>(action->GetProperty("precision"));
if (precision != NULL)
{
PRECISION = precision->GetValue();
}
int position = pointSet->SearchPoint(worldPoint, PRECISION);
if (position <0)//no point found at the current mouseposition
{
//new Event with information NO
mitk::StateEvent* newStateEvent = new mitk::StateEvent(EIDNO, posEvent);
this->HandleEvent( newStateEvent );
ok = true;
break;
}
//point found at the current mouseposition, so check if this point is the same like before
unsigned int upos = (unsigned int) position;//comparison signed unsigned int
if (upos == m_LastPosition)//found the same point again
{
mitk::StateEvent* newStateEvent = new mitk::StateEvent(EIDYES, posEvent);
//call HandleEvent to leave the guard-state
this->HandleEvent( newStateEvent );
ok = true;
}
else
{
//new Event with information NO
mitk::StateEvent* newStateEvent = new mitk::StateEvent(EIDNO, posEvent);
this->HandleEvent( newStateEvent );
ok = true;
}
}
else //hardly used, due to 3dPicking of globalInteraction
{
mitk::DisplayPositionEvent const *disPosEvent = dynamic_cast <const mitk::DisplayPositionEvent *> (stateEvent->GetEvent());
if (disPosEvent != NULL)
{//2d Koordinates for 3D Interaction; return false to redo the last statechange
mitk::StateEvent* newStateEvent = new mitk::StateEvent(EIDNO, posEvent);
this->HandleEvent( newStateEvent );
ok = true;
}
}
}
break;
case AcINITMOVEMENT:
{
mitk::PositionEvent const *posEvent = dynamic_cast <const mitk::PositionEvent *> (stateEvent->GetEvent());
if (posEvent == NULL)
return false;
//start of the Movement is stored to calculate the undoCoordinate in FinishMovement
m_LastPoint = posEvent->GetWorldPosition();
ok = true;
break;
}
case AcMOVESELECTED://moves the point
{
mitk::PositionEvent const *posEvent = dynamic_cast <const mitk::PositionEvent *> (stateEvent->GetEvent());
if (posEvent == NULL)
return false;
mitk::Point3D newPoint;
newPoint = posEvent->GetWorldPosition();
PointOperation* doOp = new mitk::PointOperation(OpMOVE, newPoint, m_LastPosition);
//execute the Operation
//here no undo is stored. only the start and the end is stored for undo.
m_DataNode->GetData()->ExecuteOperation(doOp);
ok = true;
break;
}
case AcFINISHMOVEMENT:
{
mitk::PositionEvent const *posEvent = dynamic_cast <const mitk::PositionEvent *> (stateEvent->GetEvent());
if (posEvent == NULL)
return false;
//finish the movement:
// set undo-information and move it to the last position.
mitk::Point3D newPoint;
newPoint = posEvent->GetWorldPosition();
PointOperation* doOp = new mitk::PointOperation(OpMOVE, newPoint, m_LastPosition);
if ( m_UndoEnabled )
{
PointOperation* undoOp = new mitk::PointOperation(OpMOVE, m_LastPoint, m_LastPosition);
OperationEvent *operationEvent = new OperationEvent( m_DataNode->GetData(), doOp, undoOp, "Move point");
m_UndoController->SetOperationEvent(operationEvent);
}
//execute the Operation
m_DataNode->GetData()->ExecuteOperation(doOp);
// //increase the GroupEventId, so that the raw-Undo goes to here
//this->IncCurrGroupEventId();
ok = true;
}
break;
case AcCHECKGREATERONE:
//check if after deleteion the set will be empty
{
if (pointSet->GetSize()>1)
{
mitk::StateEvent* newStateEvent = new mitk::StateEvent(EIDYES, stateEvent->GetEvent());
this->HandleEvent( newStateEvent );
ok = true;
}
else
{
mitk::StateEvent* newStateEvent = new mitk::StateEvent(EIDNO, stateEvent->GetEvent());
this->HandleEvent( newStateEvent );
ok = true;
}
}
break;
case AcSELECTANOTHEROBJECT:
//selects an other Point after one point has been removed
{
/*select the point "position-1",
and if it is the first in list,
then contine at the last in list*/
if (pointSet->GetSize()>0)//only then a select of a point is possible!
{
if (m_LastPosition > 0)//not the first in list
{
this->SelectPoint( m_LastPosition-1 );
}
else//it was the first point in list, that was removed, so select the last in list
{
m_LastPosition = pointSet->GetSize()-1;//last in list
SelectPoint( m_LastPosition );
}//else
}//if
ok = true;
}
break;
case AcREMOVEPOINT:
{
//store the position of the removed point to be able to use it for selection of a next point
//even if more than one point is selected, as long as we select the point befor the first selected point we are ok.
//need to check if empty before select though!
m_LastPosition = pointSet->SearchSelectedPoint();
Operation* doOp = new mitk::Operation(OpREMOVEPOINT);
if (m_UndoEnabled)
{
Operation* undoOp = new mitk::Operation(OpINSERTPOINT);
OperationEvent *operationEvent = new OperationEvent(pointSet, doOp, undoOp, "Remove point");
m_UndoController->SetOperationEvent(operationEvent);
}
pointSet->ExecuteOperation(doOp);
ok = true;
}
break;
case AcSELECT:
//select the point found at the given mouseposition
{
mitk::PositionEvent const *posEvent = dynamic_cast <const mitk::PositionEvent *> (stateEvent->GetEvent());
if (posEvent == NULL)
return false;
mitk::Point3D worldPoint = posEvent->GetWorldPosition();
//search the point in the list
//distance set to 0, cause we already got the exact point from last State checkpoint
//but we also need the position in the list to move it
int position = pointSet->SearchPoint(worldPoint, 0);
if (position>=0)//found a point
{
PointOperation* doOp = new mitk::PointOperation(OpSELECTPOINT, worldPoint, position);
//Undo
if (m_UndoEnabled) //write to UndoMechanism
{
PointOperation* undoOp = new mitk::PointOperation(OpDESELECTPOINT, worldPoint, position);
OperationEvent *operationEvent = new OperationEvent(pointSet, doOp, undoOp);
m_UndoController->SetOperationEvent(operationEvent);
}
//execute the Operation
pointSet->ExecuteOperation(doOp);
ok = true;
}
}
break;
case AcDESELECT:
{
mitk::PositionEvent const *posEvent = dynamic_cast <const mitk::PositionEvent *> (stateEvent->GetEvent());
if (posEvent == NULL)
return false;
mitk::Point3D worldPoint = posEvent->GetWorldPosition();
//search the point in the list
//distance set to 0, cause we already got the exact point from last State checkpoint
//but we also need the position in the list to move it
int position = pointSet->SearchPoint(worldPoint, 0);
if (position>=0)//found a point
{
PointOperation* doOp = new mitk::PointOperation(OpDESELECTPOINT, worldPoint, position);
//Undo
if (m_UndoEnabled) //write to UndoMechanism
{
PointOperation* undoOp = new mitk::PointOperation(OpSELECTPOINT, worldPoint, position);
OperationEvent *operationEvent = new OperationEvent(pointSet, doOp, undoOp);
m_UndoController->SetOperationEvent(operationEvent);
}
//execute the Operation
pointSet->ExecuteOperation(doOp);
ok = true;
}
}
break;
case AcSETSTARTPOINT:
{
//get the selected point and assign it as startpoint
Point3D point;//dummy
point.Fill(0);
int position = pointSet->SearchSelectedPoint();
if (position >-1)
{
PointOperation* doOp = new mitk::PointOperation(OpSETPOINTTYPE, point, position, true, PTSTART);
//Undo
if (m_UndoEnabled) //write to UndoMechanism
{
PointOperation* undoOp = new mitk::PointOperation(OpSETPOINTTYPE, point, position, true, PTUNDEFINED);
OperationEvent *operationEvent = new OperationEvent(pointSet, doOp, undoOp);
m_UndoController->SetOperationEvent(operationEvent);
}
//execute the Operation
pointSet->ExecuteOperation(doOp);
ok = true;
}
}
break;
default:
return Superclass::ExecuteAction( action, stateEvent );
}
return ok;
}
| virtual const char* mitk::PointInteractor::GetClassName | ( | ) | const [virtual] |
Reimplemented from mitk::Interactor.
NewMacro with two parameters for calling itk::Lightobject::New(..) method.
Reimplemented from mitk::Interactor.
Definition at line 42 of file mitkPointInteractor.h.
Referenced by mitkDataNodeExtTestClass::TestInteractorSetting().
| void mitk::PointInteractor::SelectPoint | ( | int | position ) | [protected, virtual] |
select the point on the given position
Definition at line 44 of file mitkPointInteractor.cpp.
References mitk::PointSet::ExecuteOperation(), mitk::PointSet::GetSize(), mitk::OpDESELECTPOINT, and mitk::OpSELECTPOINT.
{
mitk::PointSet* pointSet = dynamic_cast<mitk::PointSet*>(m_DataNode->GetData());
if (pointSet == NULL)
return;
if (pointSet->GetSize()<=0)//if List is empty, then no select of a point can be done!
return;
mitk::Point3D noPoint;//dummyPoint... not needed anyway
noPoint.Fill(0);
mitk::PointOperation* doOp = new mitk::PointOperation(OpSELECTPOINT, noPoint, position);
if (m_UndoEnabled)
{
mitk::PointOperation* undoOp = new mitk::PointOperation(OpDESELECTPOINT, noPoint, position);
OperationEvent *operationEvent = new OperationEvent(pointSet, doOp, undoOp);
m_UndoController->SetOperationEvent(operationEvent);
}
pointSet->ExecuteOperation(doOp);
}
| void mitk::PointInteractor::SetPrecision | ( | unsigned int | precision ) |
Sets the amount of precision.
1.7.2
