Data management class that handles 'was created by' relations. More...
#include <mitkStandaloneDataStorage.h>
Public Types | |
| typedef StandaloneDataStorage | Self |
| typedef mitk::DataStorage | Superclass |
| typedef itk::SmartPointer< Self > | Pointer |
| typedef itk::SmartPointer < const Self > | ConstPointer |
Public Member Functions | |
| virtual const char * | GetClassName () const |
| void | Add (mitk::DataNode *node, const mitk::DataStorage::SetOfObjects *parents=NULL) |
| Adds a DataNode containing a data object to its internal storage. | |
| void | Remove (const mitk::DataNode *node) |
| Removes node from the StandaloneDataStorage. | |
| virtual bool | Exists (const mitk::DataNode *node) const |
| Checks if a node exists in the StandaloneDataStorage. | |
| SetOfObjects::ConstPointer | GetSources (const mitk::DataNode *node, const NodePredicateBase *condition=NULL, bool onlyDirectSources=true) const |
| returns a set of source objects for a given node that meet the given condition(s). | |
| SetOfObjects::ConstPointer | GetDerivations (const mitk::DataNode *node, const NodePredicateBase *condition=NULL, bool onlyDirectDerivations=true) const |
| returns a set of derived objects for a given node. | |
| SetOfObjects::ConstPointer | GetAll () const |
| returns a set of all data objects that are stored in the data storage | |
Static Public Member Functions | |
| static Pointer | New () |
Public Attributes | |
| itk::SimpleFastMutexLock | m_Mutex |
Protected Types | |
| typedef std::map < mitk::DataNode::ConstPointer, SetOfObjects::ConstPointer > | AdjacencyList |
| noncyclical directed graph data structure to store the nodes with their relation | |
Protected Member Functions | |
| StandaloneDataStorage () | |
| Standard Constructor for New() instantiation. | |
| virtual | ~StandaloneDataStorage () |
| Standard Destructor. | |
| bool | IsInitialized () const |
| convenience method to check if the object has been initialized (i.e. a data tree has been set) | |
| SetOfObjects::ConstPointer | GetRelations (const mitk::DataNode *node, const AdjacencyList &relation, const NodePredicateBase *condition=NULL, bool onlyDirectlyRelated=true) const |
| Traverses the Relation graph and extracts a list of related elements (e.g. Sources or Derivations) | |
| void | RemoveFromRelation (const mitk::DataNode *node, AdjacencyList &relation) |
| deletes all references to a node in a given relation (used in Remove() and TreeListener) | |
| virtual void | PrintSelf (std::ostream &os, itk::Indent indent) const |
| Prints the contents of the StandaloneDataStorage to os. Do not call directly, call ->Print() instead. | |
Protected Attributes | |
| AdjacencyList | m_SourceNodes |
| Nodes and their relation are stored in m_SourceNodes. | |
| AdjacencyList | m_DerivedNodes |
| Nodes are stored in reverse relation for easier traversal in the opposite direction of the relation. | |
Data management class that handles 'was created by' relations.
The StandaloneDataStorage provides data storage and management functionality. It handles a 'was created by' relation by associating each data object with a set of source objects that were used to create the new object was created from. Thus, nodes are stored in a noncyclical directed graph data structure. It is derived from mitk::DataStorage and implements its interface, including AddNodeEvent and RemoveNodeEvent.
Definition at line 42 of file mitkStandaloneDataStorage.h.
typedef std::map<mitk::DataNode::ConstPointer, SetOfObjects::ConstPointer> mitk::StandaloneDataStorage::AdjacencyList [protected] |
noncyclical directed graph data structure to store the nodes with their relation
Definition at line 99 of file mitkStandaloneDataStorage.h.
| typedef itk::SmartPointer<const Self> mitk::StandaloneDataStorage::ConstPointer |
Reimplemented from mitk::DataStorage.
Reimplemented in mitk::TestStandaloneDataStorage.
Definition at line 45 of file mitkStandaloneDataStorage.h.
| typedef itk::SmartPointer<Self> mitk::StandaloneDataStorage::Pointer |
Reimplemented from mitk::DataStorage.
Reimplemented in mitk::TestStandaloneDataStorage.
Definition at line 45 of file mitkStandaloneDataStorage.h.
Reimplemented from mitk::DataStorage.
Reimplemented in mitk::TestStandaloneDataStorage.
Definition at line 45 of file mitkStandaloneDataStorage.h.
Reimplemented from mitk::DataStorage.
Reimplemented in mitk::TestStandaloneDataStorage.
Definition at line 45 of file mitkStandaloneDataStorage.h.
| mitk::StandaloneDataStorage::StandaloneDataStorage | ( | ) | [protected] |
Standard Constructor for New() instantiation.
Definition at line 29 of file mitkStandaloneDataStorage.cpp.
: mitk::DataStorage() { }
| mitk::StandaloneDataStorage::~StandaloneDataStorage | ( | ) | [protected, virtual] |
Standard Destructor.
Definition at line 35 of file mitkStandaloneDataStorage.cpp.
{
for(AdjacencyList::iterator it = m_SourceNodes.begin();
it != m_SourceNodes.end(); it++)
{
this->RemoveListeners(it->first);
}
}
| void mitk::StandaloneDataStorage::Add | ( | mitk::DataNode * | node, |
| const mitk::DataStorage::SetOfObjects * | parents = NULL |
||
| ) | [virtual] |
Adds a DataNode containing a data object to its internal storage.
This Method adds a new data object to the StandaloneDataStorage. The new object is passed in the first parameter. The second parameter is a set of source objects, that were used to create this object. The new object will have a 'was created from' relation to its source objects. the addition of a new object will fire the notification mechanism. If the node parameter is NULL or if the DataNode has already been added, an exception will be thrown.
Implements mitk::DataStorage.
Definition at line 53 of file mitkStandaloneDataStorage.cpp.
{
{
itk::MutexLockHolder<itk::SimpleFastMutexLock> locked(m_Mutex);
if (!IsInitialized())
throw std::logic_error("DataStorage not initialized");
/* check if node is in its own list of sources */
if ((parents != NULL) && (std::find(parents->begin(), parents->end(), node) != parents->end()))
throw std::invalid_argument("Node is it's own parent");
/* check if node already exists in StandaloneDataStorage */
if (m_SourceNodes.find(node) != m_SourceNodes.end())
throw std::invalid_argument("Node is already in DataStorage");
/* create parent list if it does not exist */
mitk::DataStorage::SetOfObjects::ConstPointer sp;
if (parents != NULL)
sp = parents;
else
sp = mitk::DataStorage::SetOfObjects::New();
/* Store node and parent list in sources adjacency list */
m_SourceNodes.insert(std::make_pair(node, sp));
/* Store node and an empty children list in derivations adjacency list */
mitk::DataStorage::SetOfObjects::Pointer children = mitk::DataStorage::SetOfObjects::New();
m_DerivedNodes.insert(std::make_pair(node, children));
/* create entry in derivations adjacency list for each parent of the new node */
for (SetOfObjects::ConstIterator it = sp->Begin(); it != sp->End(); it++)
{
mitk::DataNode::ConstPointer parent = it.Value().GetPointer();
mitk::DataStorage::SetOfObjects::ConstPointer derivedObjects = m_DerivedNodes[parent]; // get or create pointer to list of derived objects for that parent node
if (derivedObjects.IsNull())
m_DerivedNodes[parent] = mitk::DataStorage::SetOfObjects::New(); // Create a set of Objects, if it does not already exist
mitk::DataStorage::SetOfObjects* deob = const_cast<mitk::DataStorage::SetOfObjects*>(m_DerivedNodes[parent].GetPointer()); // temporarily get rid of const pointer to insert new element
deob->InsertElement(deob->Size(), node); // node is derived from parent. Insert it into the parents list of derived objects
}
// register for ITK changed events
this->AddListeners(node);
}
/* Notify observers */
EmitAddNodeEvent(node);
}
| bool mitk::StandaloneDataStorage::Exists | ( | const mitk::DataNode * | node ) | const [virtual] |
Checks if a node exists in the StandaloneDataStorage.
Implements mitk::DataStorage.
Definition at line 128 of file mitkStandaloneDataStorage.cpp.
{
itk::MutexLockHolder<itk::SimpleFastMutexLock> locked(m_Mutex);
return (m_SourceNodes.find(node) != m_SourceNodes.end());
}
| mitk::DataStorage::SetOfObjects::ConstPointer mitk::StandaloneDataStorage::GetAll | ( | ) | const [virtual] |
returns a set of all data objects that are stored in the data storage
Implements mitk::DataStorage.
Definition at line 152 of file mitkStandaloneDataStorage.cpp.
{
itk::MutexLockHolder<itk::SimpleFastMutexLock > locked(m_Mutex);
if (!IsInitialized())
throw std::logic_error("DataStorage not initialized");
mitk::DataStorage::SetOfObjects::Pointer resultset = mitk::DataStorage::SetOfObjects::New();
/* Fill resultset with all objects that are managed by the StandaloneDataStorage object */
unsigned int index = 0;
for (AdjacencyList::const_iterator it = m_SourceNodes.begin(); it != m_SourceNodes.end(); ++it)
if (it->first.IsNull())
continue;
else
resultset->InsertElement(index++, const_cast<mitk::DataNode*>(it->first.GetPointer()));
return SetOfObjects::ConstPointer(resultset);
}
| virtual const char* mitk::StandaloneDataStorage::GetClassName | ( | ) | const [virtual] |
Reimplemented from mitk::DataStorage.
Reimplemented in mitk::TestStandaloneDataStorage.
| mitk::DataStorage::SetOfObjects::ConstPointer mitk::StandaloneDataStorage::GetDerivations | ( | const mitk::DataNode * | node, |
| const NodePredicateBase * | condition = NULL, |
||
| bool | onlyDirectDerivations = true |
||
| ) | const [virtual] |
returns a set of derived objects for a given node.
GetDerivations() returns a set of objects that are derived from the DataNode node. This means, that node was used to create the returned objects. If the parameter onlyDirectDerivations is set to true (default value), only objects that directly have node as one of their source objects will be returned. Otherwise, objects that are derived from derivations of node are returned too. The derived objects can be filtered with a predicate object as described in the GetSubset() method by providing a predicate as the condition parameter.
Implements mitk::DataStorage.
Definition at line 239 of file mitkStandaloneDataStorage.cpp.
{
itk::MutexLockHolder<itk::SimpleFastMutexLock>locked(m_Mutex);
return this->GetRelations(node, m_DerivedNodes, condition, onlyDirectDerivations);
}
| mitk::DataStorage::SetOfObjects::ConstPointer mitk::StandaloneDataStorage::GetRelations | ( | const mitk::DataNode * | node, |
| const AdjacencyList & | relation, | ||
| const NodePredicateBase * | condition = NULL, |
||
| bool | onlyDirectlyRelated = true |
||
| ) | const [protected] |
Traverses the Relation graph and extracts a list of related elements (e.g. Sources or Derivations)
Definition at line 171 of file mitkStandaloneDataStorage.cpp.
References mitk::NodePredicateBase::CheckNode().
{
if (node == NULL)
throw std::invalid_argument("invalid node");
/* Either read direct relations directly from adjacency list */
if (onlyDirectlyRelated)
{
AdjacencyList::const_iterator it = relation.find(node); // get parents of current node
if ((it == relation.end()) || (it->second.IsNull())) // node not found in list or no set of parents
return SetOfObjects::ConstPointer(mitk::DataStorage::SetOfObjects::New()); // return an empty set
else
return this->FilterSetOfObjects(it->second, condition);
}
/* Or traverse adjacency list to collect all related nodes */
std::vector<mitk::DataNode::ConstPointer> resultset;
std::vector<mitk::DataNode::ConstPointer> openlist;
/* Initialize openlist with node. this will add node to resultset,
but that is necessary to detect circular relations that would lead to endless recursion */
openlist.push_back(node);
while (openlist.size() > 0)
{
mitk::DataNode::ConstPointer current = openlist.back(); // get element that needs to be processed
openlist.pop_back(); // remove last element, because it gets processed now
resultset.push_back(current); // add current element to resultset
AdjacencyList::const_iterator it = relation.find(current); // get parents of current node
if ( (it == relation.end()) // if node not found in list
|| (it->second.IsNull()) // or no set of parents available
|| (it->second->Size() == 0)) // or empty set of parents
continue; // then continue with next node in open list
else
for (SetOfObjects::ConstIterator parentIt = it->second->Begin(); parentIt != it->second->End(); ++parentIt) // for each parent of current node
{
mitk::DataNode::ConstPointer p = parentIt.Value().GetPointer();
if ( !(std::find(resultset.begin(), resultset.end(), p) != resultset.end()) // if it is not already in resultset
&& !(std::find(openlist.begin(), openlist.end(), p) != openlist.end())) // and not already in openlist
openlist.push_back(p); // then add it to openlist, so that it can be processed
}
}
/* now finally copy the results to a proper SetOfObjects variable exluding the initial node and checking the condition if any is given */
mitk::DataStorage::SetOfObjects::Pointer realResultset = mitk::DataStorage::SetOfObjects::New();
if (condition != NULL)
{
for (std::vector<mitk::DataNode::ConstPointer>::iterator resultIt = resultset.begin(); resultIt != resultset.end(); resultIt++)
if ((*resultIt != node) && (condition->CheckNode(*resultIt) == true))
realResultset->InsertElement(realResultset->Size(), mitk::DataNode::Pointer(const_cast<mitk::DataNode*>((*resultIt).GetPointer())));
}
else
{
for (std::vector<mitk::DataNode::ConstPointer>::iterator resultIt = resultset.begin(); resultIt != resultset.end(); resultIt++)
if (*resultIt != node)
realResultset->InsertElement(realResultset->Size(), mitk::DataNode::Pointer(const_cast<mitk::DataNode*>((*resultIt).GetPointer())));
}
return SetOfObjects::ConstPointer(realResultset);
}
| mitk::DataStorage::SetOfObjects::ConstPointer mitk::StandaloneDataStorage::GetSources | ( | const mitk::DataNode * | node, |
| const NodePredicateBase * | condition = NULL, |
||
| bool | onlyDirectSources = true |
||
| ) | const [virtual] |
returns a set of source objects for a given node that meet the given condition(s).
Implements mitk::DataStorage.
Definition at line 232 of file mitkStandaloneDataStorage.cpp.
{
itk::MutexLockHolder<itk::SimpleFastMutexLock> locked(m_Mutex);
return this->GetRelations(node, m_SourceNodes, condition, onlyDirectSources);
}
| bool mitk::StandaloneDataStorage::IsInitialized | ( | ) | const [protected] |
convenience method to check if the object has been initialized (i.e. a data tree has been set)
Definition at line 47 of file mitkStandaloneDataStorage.cpp.
{
return true;
}
| static Pointer mitk::StandaloneDataStorage::New | ( | ) | [static] |
Reimplemented in mitk::TestStandaloneDataStorage.
Referenced by mitk::NavigationToolWriter::DoWrite(), Step6::Load(), mitk::SceneIO::LoadScene(), main(), mitkContourMapper2DTest(), mitkDataStorageTest(), mitkImageMapper2DTest(), mitkLevelWindowManagerTest(), mitkRenderingManagerTest(), mitkSceneIOTest(), mitkToolManagerTest(), mitkVtkPropRendererTest(), mitk::NavigationToolStorageSerializer::Serialize(), and TestDataStorage().
| void mitk::StandaloneDataStorage::PrintSelf | ( | std::ostream & | os, |
| itk::Indent | indent | ||
| ) | const [protected, virtual] |
Prints the contents of the StandaloneDataStorage to os. Do not call directly, call ->Print() instead.
Reimplemented from mitk::DataStorage.
Definition at line 246 of file mitkStandaloneDataStorage.cpp.
{
os << indent << "StandaloneDataStorage:\n";
Superclass::PrintSelf(os, indent);
}
| void mitk::StandaloneDataStorage::Remove | ( | const mitk::DataNode * | node ) | [virtual] |
Removes node from the StandaloneDataStorage.
Implements mitk::DataStorage.
Definition at line 100 of file mitkStandaloneDataStorage.cpp.
{
if (!IsInitialized())
throw std::logic_error("DataStorage not initialized");
if (node == NULL)
return;
// remove ITK modified event listener
this->RemoveListeners(node);
// muellerm, 22.9.10: add additional reference count to ensure
// that the node is not deleted when removed from the relation map
// while m_Mutex is locked. This would cause the an itk::DeleteEvent
// is thrown and a deadlock will occur when event receivers
// access the DataStorage again in their event processing function
//
mitk::DataNode::ConstPointer nodeGuard(node);
/* Notify observers of imminent node removal */
EmitRemoveNodeEvent(node);
{
itk::MutexLockHolder<itk::SimpleFastMutexLock> locked(m_Mutex);
/* remove node from both relation adjacency lists */
this->RemoveFromRelation(node, m_SourceNodes);
this->RemoveFromRelation(node, m_DerivedNodes);
}
}
| void mitk::StandaloneDataStorage::RemoveFromRelation | ( | const mitk::DataNode * | node, |
| AdjacencyList & | relation | ||
| ) | [protected] |
deletes all references to a node in a given relation (used in Remove() and TreeListener)
Definition at line 134 of file mitkStandaloneDataStorage.cpp.
{
for (AdjacencyList::const_iterator mapIter = relation.begin(); mapIter != relation.end(); ++mapIter) // for each node in the relation
if (mapIter->second.IsNotNull()) // if node has a relation list
{
SetOfObjects::Pointer s = const_cast<SetOfObjects*>(mapIter->second.GetPointer()); // search for node to be deleted in the relation list
SetOfObjects::STLContainerType::iterator relationListIter = std::find(s->begin(), s->end(), node); // this assumes, that the relation list does not contain duplicates (which should be safe to assume)
if (relationListIter != s->end()) // if node to be deleted is in relation list
s->erase(relationListIter); // remove it from parentlist
}
/* now remove node from the relation */
AdjacencyList::iterator adIt;
adIt = relation.find(node);
if (adIt != relation.end())
relation.erase(adIt);
}
Nodes are stored in reverse relation for easier traversal in the opposite direction of the relation.
Definition at line 129 of file mitkStandaloneDataStorage.h.
itk::SimpleFastMutexLock mitk::StandaloneDataStorage::m_Mutex [mutable] |
Definition at line 93 of file mitkStandaloneDataStorage.h.
Nodes and their relation are stored in m_SourceNodes.
Definition at line 126 of file mitkStandaloneDataStorage.h.
1.7.2
