#include <mitkSceneReaderV1.h>
Public Types | |
| typedef SceneReaderV1 | Self |
| typedef SceneReader | Superclass |
| typedef itk::SmartPointer< Self > | Pointer |
| typedef itk::SmartPointer < const Self > | ConstPointer |
Public Member Functions | |
| virtual const char * | GetClassName () const |
| virtual bool | LoadScene (TiXmlDocument &document, const std::string &workingDirectory, DataStorage *storage) |
Static Public Member Functions | |
| static Pointer | New () |
Protected Types | |
| typedef std::map < DataNode::Pointer, std::list < std::string > > | NodesAndParentsMapType |
| typedef std::map< std::string, DataNode * > | IDToNodeMappingType |
| typedef std::map< DataNode *, std::string > | NodeToIDMappingType |
Protected Member Functions | |
| DataNode::Pointer | LoadBaseDataFromDataTag (TiXmlElement *dataElement, const std::string &workingDirectory, bool &error) |
| tries to create one DataNode from a given XML <node> element | |
| bool | DecorateNodeWithProperties (DataNode *node, TiXmlElement *nodeElement, const std::string &workingDirectory) |
| reads all the properties from the XML document and recreates them in node | |
Protected Attributes | |
| NodesAndParentsMapType | m_Nodes |
| IDToNodeMappingType | m_NodeForID |
| NodeToIDMappingType | m_IDForNode |
| UIDGenerator | m_UIDGen |
Definition at line 23 of file mitkSceneReaderV1.h.
| typedef itk::SmartPointer<const Self> mitk::SceneReaderV1::ConstPointer |
Reimplemented from mitk::SceneReader.
Definition at line 27 of file mitkSceneReaderV1.h.
typedef std::map<std::string, DataNode*> mitk::SceneReaderV1::IDToNodeMappingType [protected] |
Definition at line 47 of file mitkSceneReaderV1.h.
typedef std::map<DataNode::Pointer, std::list<std::string> > mitk::SceneReaderV1::NodesAndParentsMapType [protected] |
Definition at line 46 of file mitkSceneReaderV1.h.
typedef std::map<DataNode*, std::string> mitk::SceneReaderV1::NodeToIDMappingType [protected] |
Definition at line 48 of file mitkSceneReaderV1.h.
| typedef itk::SmartPointer<Self> mitk::SceneReaderV1::Pointer |
Reimplemented from mitk::SceneReader.
Definition at line 27 of file mitkSceneReaderV1.h.
Reimplemented from mitk::SceneReader.
Definition at line 27 of file mitkSceneReaderV1.h.
Reimplemented from mitk::SceneReader.
Definition at line 27 of file mitkSceneReaderV1.h.
| bool mitk::SceneReaderV1::DecorateNodeWithProperties | ( | DataNode * | node, |
| TiXmlElement * | nodeElement, | ||
| const std::string & | workingDirectory | ||
| ) | [protected] |
reads all the properties from the XML document and recreates them in node
Definition at line 207 of file mitkSceneReaderV1.cpp.
References mitk::PropertyList::Clear(), TiXmlNode::FirstChildElement(), mitk::BaseRenderer::GetByName(), mitk::DataNode::GetPropertyList(), MITK_ERROR, mitk::PropertyListDeserializer::New(), and TiXmlNode::NextSiblingElement().
{
assert(node);
assert(nodeElement);
bool error(false);
for( TiXmlElement* properties = nodeElement->FirstChildElement("properties"); properties != NULL; properties = properties->NextSiblingElement("properties") )
{
const char* propertiesfilea( properties->Attribute("file") );
std::string propertiesfile( propertiesfilea ? propertiesfilea : "" );
const char* renderwindowa( properties->Attribute("renderwindow") );
std::string renderwindow( renderwindowa ? renderwindowa : "" );
BaseRenderer* renderer = BaseRenderer::GetByName( renderwindow );
if (renderer || renderwindow.empty())
{
PropertyList::Pointer propertyList = node->GetPropertyList(renderer); // DataNode implementation always returns a propertylist
// clear all properties from node that might be set by DataNodeFactory during loading
propertyList->Clear();
// use deserializer to construct new properties
PropertyListDeserializer::Pointer deserializer = PropertyListDeserializer::New();
deserializer->SetFilename(workingDirectory + Poco::Path::separator() + propertiesfile);
bool success = deserializer->Deserialize();
error |= !success;
PropertyList::Pointer readProperties = deserializer->GetOutput();
if (readProperties.IsNotNull())
{
propertyList->ConcatenatePropertyList( readProperties, true ); // true = replace
}
else
{
MITK_ERROR << "Property list reader did not return a property list. This is an implementation error. Please tell your developer.";
error = true;
}
}
else
{
MITK_ERROR << "Found properties for renderer " << renderwindow << " but there is no such renderer in current application. Ignoring those properties";
error = true;
}
}
return !error;
}
| virtual const char* mitk::SceneReaderV1::GetClassName | ( | ) | const [virtual] |
Reimplemented from mitk::SceneReader.
| mitk::DataNode::Pointer mitk::SceneReaderV1::LoadBaseDataFromDataTag | ( | TiXmlElement * | dataElement, |
| const std::string & | workingDirectory, | ||
| bool & | error | ||
| ) | [protected] |
tries to create one DataNode from a given XML <node> element
Definition at line 167 of file mitkSceneReaderV1.cpp.
References TiXmlElement::Attribute(), MITK_ERROR, and New().
{
DataNode::Pointer node;
if (dataElement)
{
const char* filename( dataElement->Attribute("file") );
if ( filename )
{
DataNodeFactory::Pointer factory = DataNodeFactory::New();
factory->SetFileName( workingDirectory + Poco::Path::separator() + filename );
try
{
factory->Update();
node = factory->GetOutput();
}
catch (std::exception& e)
{
MITK_ERROR << "Error during attempt to read '" << filename << "'. Exception says: " << e.what();
error = true;
}
if (node.IsNull())
{
MITK_ERROR << "Error during attempt to read '" << filename << "'. Factory returned NULL object.";
error = true;
}
}
}
// in case there was no <data> element we create a new empty node (for appending a propertylist later)
if (node.IsNull())
{
node = DataNode::New();
}
return node;
}
| bool mitk::SceneReaderV1::LoadScene | ( | TiXmlDocument & | document, |
| const std::string & | workingDirectory, | ||
| DataStorage * | storage | ||
| ) | [virtual] |
Reimplemented from mitk::SceneReader.
Definition at line 27 of file mitkSceneReaderV1.cpp.
References TiXmlNode::FirstChildElement(), MITK_ERROR, MITK_WARN, and TiXmlNode::NextSiblingElement().
{
assert(storage);
bool error(false);
// TODO prepare to detect errors (such as cycles) from wrongly written or edited xml files
// iterate all nodes
// first level nodes should be <node> elements
for( TiXmlElement* element = document.FirstChildElement("node"); element != NULL; element = element->NextSiblingElement("node") )
{
// 1. if there is a <data type="..." file="..."> element,
// - construct a name for the appropriate deserializer
// - try to instantiate this deserializer via itk object factory
// - if deserializer could be created, use it to read the file into a BaseData object
// - if successful, call the new node's SetData(..)
DataNode::Pointer node = LoadBaseDataFromDataTag( element->FirstChildElement("data"), workingDirectory, error );
// 2. check child nodes
const char* uida = element->Attribute("UID");
std::string uid("");
if (uida)
{
uid = uida;
m_NodeForID[uid] = node.GetPointer();
m_IDForNode[ node.GetPointer() ] = uid;
}
else
{
MITK_ERROR << "No UID found for current node. Node will have no parents.";
error = true;
}
// remember node for later adding to DataStorage
m_Nodes.insert( std::make_pair( node, std::list<std::string>() ) );
// 3. if there are <source> elements, remember parent objects
for( TiXmlElement* source = element->FirstChildElement("source"); source != NULL; source = source->NextSiblingElement("source") )
{
const char* sourceUID = source->Attribute("UID");
if (sourceUID)
{
m_Nodes[node].push_back( std::string(sourceUID) );
}
}
// 5. if there are <properties> nodes,
// - instantiate the appropriate PropertyListDeSerializer
// - use them to construct PropertyList objects
// - add these properties to the node (if necessary, use renderwindow name)
bool success = DecorateNodeWithProperties(node, element, workingDirectory);
if (!success)
{
MITK_ERROR << "Could not load properties for node.";
error = true;
}
} // end for all <node>
// remove all unknown parent UIDs
for (NodesAndParentsMapType::iterator nodesIter = m_Nodes.begin();
nodesIter != m_Nodes.end();
++nodesIter)
{
for (std::list<std::string>::iterator parentsIter = nodesIter->second.begin();
parentsIter != nodesIter->second.end();)
{
if (m_NodeForID.find( *parentsIter ) == m_NodeForID.end())
{
parentsIter = nodesIter->second.erase( parentsIter );
MITK_WARN << "Found a DataNode with unknown parents. Will add it to DataStorage without any parent objects.";
error = true;
}
else
{
++parentsIter;
}
}
}
// repeat
// for all created nodes
unsigned int lastMapSize(0);
while ( lastMapSize != m_Nodes.size()) // this is to prevent infinite loops; each iteration must at least add one node to DataStorage
{
lastMapSize = m_Nodes.size();
for (NodesAndParentsMapType::iterator nodesIter = m_Nodes.begin();
nodesIter != m_Nodes.end();
++nodesIter)
{
bool addNow(true);
// if any parent node is not yet in DataStorage, skip node for now and check later
for (std::list<std::string>::iterator parentsIter = nodesIter->second.begin();
parentsIter != nodesIter->second.end();
++parentsIter)
{
if ( !storage->Exists( m_NodeForID[ *parentsIter ] ) )
{
addNow = false;
break;
}
}
if (addNow)
{
DataStorage::SetOfObjects::Pointer parents = DataStorage::SetOfObjects::New();
for (std::list<std::string>::iterator parentsIter = nodesIter->second.begin();
parentsIter != nodesIter->second.end();
++parentsIter)
{
parents->push_back( m_NodeForID[ *parentsIter ] );
}
// if all parents are found in datastorage (or are unknown), add node to DataStorage
storage->Add( nodesIter->first, parents );
// remove this node from m_Nodes
m_Nodes.erase( nodesIter );
// break this for loop because iterators are probably invalid
break;
}
}
}
// All nodes that are still in m_Nodes at this point are not part of a proper directed graph structure. We'll add such nodes without any parent information.
for (NodesAndParentsMapType::iterator nodesIter = m_Nodes.begin();
nodesIter != m_Nodes.end();
++nodesIter)
{
storage->Add( nodesIter->first );
MITK_WARN << "Encountered node that is not part of a directed graph structure. Will be added to DataStorage without parents.";
error = true;
}
return !error;
}
| static Pointer mitk::SceneReaderV1::New | ( | ) | [static] |
Reimplemented from mitk::SceneReader.
Referenced by LoadBaseDataFromDataTag().
NodeToIDMappingType mitk::SceneReaderV1::m_IDForNode [protected] |
Definition at line 52 of file mitkSceneReaderV1.h.
IDToNodeMappingType mitk::SceneReaderV1::m_NodeForID [protected] |
Definition at line 51 of file mitkSceneReaderV1.h.
NodesAndParentsMapType mitk::SceneReaderV1::m_Nodes [protected] |
Definition at line 50 of file mitkSceneReaderV1.h.
UIDGenerator mitk::SceneReaderV1::m_UIDGen [protected] |
Definition at line 54 of file mitkSceneReaderV1.h.
