#include <qxtscheduleview_p.h>
Definition at line 104 of file qxtscheduleview_p.h.
| QxtScheduleViewPrivate::QxtScheduleViewPrivate | ( | ) |
Definition at line 418 of file qxtscheduleview_p.cpp.
References delegate, handlesConcurrency, m_Cols, m_hHeader, m_Model, m_selectedItem, m_vHeader, m_zoomStepWidth, scrollTimer, and scrollTimerTimeout().
{
m_Cols = 0;
m_vHeader = 0;
m_hHeader = 0;
m_Model = 0;
m_selectedItem = 0;
handlesConcurrency = false;
delegate = 0;
m_zoomStepWidth = 0;
connect(&scrollTimer, SIGNAL(timeout()), this, SLOT(scrollTimerTimeout()));
}
| QVector< QRect > QxtScheduleViewPrivate::calculateRangeGeometries | ( | const int | iStartOffset, |
| const int | iEndOffset | ||
| ) | const |
Definition at line 64 of file qxtscheduleview_p.cpp.
References m_hHeader, m_vHeader, offsetToVisualColumn(), offsetToVisualRow(), and visualIndexToOffset().
{
QVector<QRect> rects;
if (iStartOffset < 0 || iEndOffset < 0)
return rects;
if (iEndOffset < iStartOffset)
return rects;
int iCurrentStartOffset = iStartOffset;
int iCurrentEndOffset;
do
{
if (offsetToVisualColumn(iCurrentStartOffset) == offsetToVisualColumn(iEndOffset))
iCurrentEndOffset = iEndOffset;
else
iCurrentEndOffset = visualIndexToOffset(m_vHeader->count() - 1, offsetToVisualColumn(iCurrentStartOffset));
qint32 iLeft = m_hHeader->sectionPosition(offsetToVisualColumn(iCurrentStartOffset));
qint32 iTop = m_vHeader->sectionPosition(offsetToVisualRow(iCurrentStartOffset));
qint32 iBottom = m_vHeader->sectionPosition(offsetToVisualRow(iCurrentEndOffset)) + m_vHeader->sectionSize(offsetToVisualRow(iCurrentEndOffset));
qint32 iRight = m_hHeader->sectionPosition(offsetToVisualColumn(iCurrentEndOffset)) + m_hHeader->sectionSize(offsetToVisualColumn(iCurrentEndOffset));
rects.append(QRect(iLeft + 1, iTop + 1, iRight - iLeft - 1, iBottom - iTop - 1));
iCurrentStartOffset = visualIndexToOffset(0, offsetToVisualColumn(iCurrentEndOffset) + 1);
}
while (iCurrentEndOffset < iEndOffset);
return rects;
}
| QList< QLinkedList< QxtScheduleInternalItem * > > QxtScheduleViewPrivate::findConcurrentItems | ( | const int | from, |
| const int | to | ||
| ) | const |
collects groups of concurrent items in the offset range
Definition at line 173 of file qxtscheduleview_p.cpp.
References m_Items, and qxtScheduleItemLessThan().
Referenced by handleItemConcurrency().
{
QList< QLinkedList<QxtScheduleInternalItem *> > allConcurrentItems;
QList<QxtScheduleInternalItem *> allItemsSorted = m_Items;
if(m_Items.size() == 0)
return allConcurrentItems;
qSort(allItemsSorted.begin(), allItemsSorted.end(), qxtScheduleItemLessThan);
int startItem = 0;
int endItem = allItemsSorted.size() - 1;
//find the startitem that interferes with our range
for (int i = 0; i < allItemsSorted.size(); i++)
{
if (i > 0)
{
if (!(allItemsSorted.at(i - 1)->visualEndTableOffset() >= allItemsSorted.at(i)->visualStartTableOffset()
&& allItemsSorted.at(i - 1)->visualStartTableOffset() <= allItemsSorted.at(i)->visualEndTableOffset()))
startItem = i;
}
if (allItemsSorted.at(i)->visualEndTableOffset() >= from && allItemsSorted.at(i)->visualStartTableOffset() <= to)
break;
}
//find the last item that interferes with our range
for (int i = allItemsSorted.size() - 1; i >= 0 ; i--)
{
if (i < allItemsSorted.size() - 1)
{
if (!(allItemsSorted.at(i + 1)->visualEndTableOffset() >= allItemsSorted.at(i)->visualStartTableOffset()
&& allItemsSorted.at(i + 1)->visualStartTableOffset() <= allItemsSorted.at(i)->visualEndTableOffset()))
endItem = i;
}
if (allItemsSorted.at(i)->visualEndTableOffset() >= from && allItemsSorted.at(i)->visualStartTableOffset() <= to)
break;
}
int startOffset = allItemsSorted.at(startItem)->visualStartTableOffset();
int endOffset = allItemsSorted.at(endItem)->visualEndTableOffset();
/*now we have to populate a list with all items that interfere with our range */
QLinkedList<QxtScheduleInternalItem *> concurrentItems;
for (int iAllItemLoop = startItem; iAllItemLoop <= endItem; iAllItemLoop++)
{
int tempStartOffset = allItemsSorted.at(iAllItemLoop)->visualStartTableOffset();
int tempEndOffset = allItemsSorted.at(iAllItemLoop)->visualEndTableOffset();
if (tempEndOffset >= startOffset && tempStartOffset <= endOffset)
{
if (concurrentItems.size() >= 1)
{
bool bAppend = false;
/*check all items in the list if the current items interfers although the items are ordered by startIndex
*we can loose some of them if the endTime of the last Item is before the endTime of the pre last item
*/
for (QLinkedList<QxtScheduleInternalItem *>::iterator it = concurrentItems.begin(); it != concurrentItems.end(); ++it)
{
int lastStartOffset = (*it)->visualStartTableOffset();
int lastEndOffset = (*it)->visualEndTableOffset();
if (tempEndOffset >= lastStartOffset && tempStartOffset <= lastEndOffset)
{
bAppend = true;
break;
}
}
if (bAppend)
{
concurrentItems.append(allItemsSorted.at(iAllItemLoop));
}
else
{
allConcurrentItems.append(concurrentItems);
concurrentItems.clear();
concurrentItems.append(allItemsSorted.at(iAllItemLoop));
}
}
else
concurrentItems.append(allItemsSorted.at(iAllItemLoop));
if (tempStartOffset < startOffset)
startOffset = tempStartOffset;
if (tempEndOffset > endOffset)
endOffset = tempEndOffset;
}
}
if (concurrentItems.size() > 0)
allConcurrentItems.append(concurrentItems);
return allConcurrentItems;
}
| void QxtScheduleViewPrivate::handleItemConcurrency | ( | const int | from, |
| const int | to | ||
| ) |
Definition at line 274 of file qxtscheduleview_p.cpp.
References findConcurrentItems(), handlesConcurrency, m_hHeader, m_Items, offsetToVisualColumn(), and QxtPrivate< QxtScheduleView >::qxt_p().
Referenced by handleItemConcurrency(), and reloadItemsFromModel().
{
/*collect all items that interfere only in that range*/
if (from < 0 || to < 0 || m_Items.size() == 0){
//do a update or we may have artifacts
qxt_p().viewport()->update();
return;
}
qDebug() << "handleItemConcurrency";
if (handlesConcurrency)
return;
handlesConcurrency = true;
QList< QLinkedList<QxtScheduleInternalItem *> > allConcurrentItems = findConcurrentItems(from, to);
/*thx to ahigerd for suggesting that algorithm*/
//[16:24] <ahigerd> Start with the first event. Put it in a list.
//[16:25] <ahigerd> Iterate until you find an event that doesn't overlap with the first event. Put it in the list. Repeat until you've reached the last event.
//[16:25] <ahigerd> This fills the left column optimally.
//[16:25] <ahigerd> Repeat the algorithm for the second column, etc., until there aren't any events left that don't have a column.
//[16:27] <ahigerd> This algorithm is O(n*m), where n is the number of events and m is the maximum number of overlapping events.
QList< QList< QxtScheduleInternalItem *> >virtualTable;
for (int iListLoop = 0; iListLoop < allConcurrentItems.size(); iListLoop++)
{
QLinkedList<QxtScheduleInternalItem *> & currentItems = allConcurrentItems[iListLoop];
QList< QxtScheduleInternalItem * > currentColumn;
qDebug() << "handle overlapping for " << currentItems.size() << " Items";
virtualTable.clear();
//we iterate over the currect collection and remove every item that can be placed in the current column
//when the collection is empty we are done
while (currentItems.size())
{
QMutableLinkedListIterator< QxtScheduleInternalItem * > iter(currentItems);
while (iter.hasNext())
{
iter.next();
//initialize the current column
if (currentColumn.isEmpty() || currentColumn[currentColumn.size()-1]->visualEndTableOffset() < iter.value()->visualStartTableOffset())
{
currentColumn.append(iter.value());
iter.remove();
continue;
}
}
if (!currentColumn.isEmpty())
{
virtualTable.append(currentColumn);
currentColumn.clear();
}
}
qDebug() << "Found columns" << virtualTable.size();
//this code part resizes the item geometries
for (int col = 0; col < virtualTable.size(); col++)
{
for (int item = 0; item < virtualTable.at(col).size() ; item++)
{
int startVisualCol = offsetToVisualColumn(virtualTable[col][item]->visualStartTableOffset());
QVector<QRect> geo = virtualTable[col][item]->geometry();
for (int rect = 0; rect < geo.size(); rect++)
{
int sectionStart = m_hHeader->sectionPosition(startVisualCol);
int fullWidth = m_hHeader->sectionSize(startVisualCol);
int oneItemWidth = fullWidth / virtualTable.size();
int itemWidth = oneItemWidth;
int itemXStart = (col * oneItemWidth) + sectionStart;
int overlap = oneItemWidth / 10;
int adjustX1 = 0;
int adjustX2 = 0;
//this is very expensive.I try to check if my item can span over more than one col
int possibleCols = 1;
bool foundCollision;
for (int tmpCol = col + 1; tmpCol < virtualTable.size(); tmpCol++)
{
foundCollision = false;
for (int tmpItem = 0; tmpItem < virtualTable.at(tmpCol).size() ; tmpItem++)
{
if ((virtualTable[tmpCol][tmpItem]->visualEndTableOffset() >= virtualTable[col][item]->visualStartTableOffset()
&& virtualTable[tmpCol][tmpItem]->visualStartTableOffset() <= virtualTable[col][item]->visualEndTableOffset()))
{
foundCollision = true;
break;
}
}
if (!foundCollision)
possibleCols++;
else
break;
}
//now lets adjust the size to get a nice overlapping of items
if (virtualTable.size() > 1)
{
if (col == 0)
adjustX2 = overlap;
else if (col == virtualTable.size() - 1)
{
adjustX1 = -overlap;
adjustX2 = overlap;
}
else
{
if (col + possibleCols == virtualTable.size())
adjustX2 = overlap;
else
adjustX2 = overlap * 2;
adjustX1 = -overlap;
}
}
// possibleCols = 1;
itemWidth = oneItemWidth * possibleCols;
qDebug() << "orginial rect" << geo[rect];
geo[rect].setLeft(itemXStart + adjustX1);
geo[rect].setWidth(itemWidth + adjustX2);
qDebug() << "new rect" << geo[rect];
startVisualCol++;
}
virtualTable[col][item]->setGeometry(geo);
}
}
}
handlesConcurrency = false;
qxt_p().viewport()->update();
}
| void QxtScheduleViewPrivate::handleItemConcurrency | ( | QxtScheduleInternalItem * | item ) | [inline] |
Definition at line 141 of file qxtscheduleview_p.h.
References handleItemConcurrency(), QxtScheduleInternalItem::rows(), and QxtScheduleInternalItem::startTableOffset().
{
if (item)
{
int startOffset = item->startTableOffset();
int endOffset = startOffset + item->rows() - 1 ;
handleItemConcurrency(startOffset, endOffset);
}
}
| void QxtScheduleViewPrivate::init | ( | ) |
Definition at line 142 of file qxtscheduleview_p.cpp.
References m_hHeader, m_vHeader, QxtPrivate< QxtScheduleView >::qxt_p(), reloadItemsFromModel(), and QxtScheduleView::updateGeometries().
{
if (qxt_p().model())
{
qxt_p().viewport()->setMouseTracking(true);
if (!m_vHeader)
{
m_vHeader = new QxtScheduleHeaderWidget(Qt::Vertical, &qxt_p());
connect(m_vHeader, SIGNAL(geometriesChanged()), &qxt_p(), SLOT(updateGeometries()));
}
m_vHeader->show();
if (!m_hHeader)
{
m_hHeader = new QxtScheduleHeaderWidget(Qt::Horizontal, &qxt_p());
connect(m_hHeader, SIGNAL(geometriesChanged()), &qxt_p(), SLOT(updateGeometries()));
}
m_hHeader->show();
/*here we also initialize the items*/
m_vHeader->setDefaultSectionSize(20);
m_vHeader->setResizeMode(QHeaderView::Fixed);
reloadItemsFromModel();
}
qxt_p().updateGeometries();
}
| QxtScheduleInternalItem * QxtScheduleViewPrivate::internalItemAt | ( | const QPoint & | pt ) |
Definition at line 108 of file qxtscheduleview_p.cpp.
References QxtScheduleInternalItem::contains(), and m_Items.
{
QListIterator<QxtScheduleInternalItem *>iterator(m_Items);
QxtScheduleInternalItem *currentItem;
iterator.toBack();
while (iterator.hasPrevious())
{
currentItem = iterator.previous();
if (currentItem->contains(pt))
return currentItem;
}
return 0;
}
| QxtScheduleInternalItem* QxtScheduleViewPrivate::internalItemAtModelIndex | ( | const QModelIndex & | index ) |
| QxtScheduleInternalItem* QxtScheduleViewPrivate::itemForModelIndex | ( | const QModelIndex & | index ) | const [inline] |
| void QxtScheduleViewPrivate::itemGeometryChanged | ( | QxtScheduleInternalItem * | item, |
| QVector< QRect > | oldGeometry | ||
| ) | [slot] |
Definition at line 432 of file qxtscheduleview_p.cpp.
References QxtScheduleInternalItem::geometry(), and QxtPrivate< QxtScheduleView >::qxt_p().
Referenced by reloadItemsFromModel().
{
QRegion oldRegion;
if (item->geometry() == oldGeometry)
return;
QVectorIterator<QRect> iter(oldGeometry);
QRect currRect;
while (iter.hasNext())
{
currRect = iter.next();
currRect.adjust(-1, -1, 2, 2);
oldRegion += currRect;
}
//viewport()->update(oldRegion);
QRegion newRegion;
QVectorIterator<QRect> newIter(item->geometry());
while (newIter.hasNext())
{
currRect = newIter.next();
currRect.adjust(-1, -1, 2, 2);
newRegion += currRect;
}
//viewport()->update(newRegion);
qxt_p().viewport()->update();
}
| int QxtScheduleViewPrivate::offsetToUnixTime | ( | const int | offset, |
| bool | indexEndTime = false |
||
| ) | const |
Definition at line 539 of file qxtscheduleview_p.cpp.
References m_currentZoomDepth, m_endUnixTime, m_startUnixTime, offsetToVisualColumn(), offsetToVisualRow(), QxtPrivate< QxtScheduleView >::qxt_p(), and QxtScheduleView::rows().
{
qint32 rows = qxt_p().rows();
uint unixTime = (offsetToVisualRow(offset) + (offsetToVisualColumn(offset) * rows)) * m_currentZoomDepth;
unixTime += m_startUnixTime;
if (indexEndTime)
{
unixTime += m_currentZoomDepth;
}
if (unixTime >= m_startUnixTime && unixTime <= m_endUnixTime + 1)
return unixTime;
return -1;
}
| int QxtScheduleViewPrivate::offsetToVisualColumn | ( | const int | iOffset ) | const |
Definition at line 45 of file qxtscheduleview_p.cpp.
References QxtPrivate< QxtScheduleView >::qxt_p(), and QxtScheduleView::rows().
Referenced by calculateRangeGeometries(), handleItemConcurrency(), and offsetToUnixTime().
| int QxtScheduleViewPrivate::offsetToVisualRow | ( | const int | iOffset ) | const |
Definition at line 57 of file qxtscheduleview_p.cpp.
References QxtPrivate< QxtScheduleView >::qxt_p(), and QxtScheduleView::rows().
Referenced by calculateRangeGeometries(), and offsetToUnixTime().
| int QxtScheduleViewPrivate::pointToOffset | ( | const QPoint & | point ) |
Definition at line 99 of file qxtscheduleview_p.cpp.
References m_hHeader, m_vHeader, and visualIndexToOffset().
{
int iRow = m_vHeader->visualIndexAt(point.y());
int iCol = m_hHeader->visualIndexAt(point.x());
return visualIndexToOffset(iRow, iCol);
}
| void QxtScheduleViewPrivate::reloadItemsFromModel | ( | ) |
Definition at line 123 of file qxtscheduleview_p.cpp.
References handleItemConcurrency(), itemGeometryChanged(), m_Items, m_selectedItem, QxtScheduleView::model(), and QxtPrivate< QxtScheduleView >::qxt_p().
Referenced by init().
{
qDeleteAll(m_Items.begin(), m_Items.end());
m_Items.clear();
m_selectedItem = NULL;
int iNumItems = qxt_p().model()->rowCount();
//delete all old stuff here
QxtScheduleInternalItem *currentItem;
for (int iLoop = 0; iLoop < iNumItems; iLoop++)
{
currentItem = new QxtScheduleInternalItem(&qxt_p(), qxt_p().model()->index(iLoop, 0));
m_Items.append(currentItem);
connect(currentItem, SIGNAL(geometryChanged(QxtScheduleInternalItem*, QVector<QRect>)), this, SLOT(itemGeometryChanged(QxtScheduleInternalItem * , QVector< QRect >)));
}
handleItemConcurrency(0, (qxt_p().rows()*qxt_p().cols()) - 1);
}
| void QxtScheduleViewPrivate::scrollTimerTimeout | ( | ) | [slot] |
Definition at line 485 of file qxtscheduleview_p.cpp.
References m_hHeader, m_vHeader, and QxtPrivate< QxtScheduleView >::qxt_p().
Referenced by QxtScheduleViewPrivate().
{
QPoint globalPos = QCursor::pos();
QPoint viewportPos = qxt_p().viewport()->mapFromGlobal(globalPos);
int iScrollVertical = this->m_vHeader->defaultSectionSize();
int iScrollHorizontal = this->m_hHeader->defaultSectionSize();
if (viewportPos.y() <= iScrollVertical)
{
int iCurrPos = qxt_p().verticalScrollBar()->value();
if (iCurrPos > qxt_p().verticalScrollBar()->minimum() + iScrollVertical)
{
qxt_p().verticalScrollBar()->setValue(iCurrPos - iScrollVertical);
}
else
qxt_p().verticalScrollBar()->setValue(qxt_p().verticalScrollBar()->minimum());
}
else if (viewportPos.y() >= qxt_p().viewport()->height() - iScrollVertical)
{
int iCurrPos = qxt_p().verticalScrollBar()->value();
if (iCurrPos < qxt_p().verticalScrollBar()->maximum() - iScrollVertical)
{
qxt_p().verticalScrollBar()->setValue(iCurrPos + iScrollVertical);
}
else
qxt_p().verticalScrollBar()->setValue(qxt_p().verticalScrollBar()->maximum());
}
if (viewportPos.x() <= iScrollHorizontal / 2)
{
int iCurrPos = qxt_p().horizontalScrollBar()->value();
if (iCurrPos > qxt_p().horizontalScrollBar()->minimum() + iScrollHorizontal)
{
qxt_p().horizontalScrollBar()->setValue(iCurrPos - iScrollHorizontal);
}
else
qxt_p().horizontalScrollBar()->setValue(qxt_p().horizontalScrollBar()->minimum());
}
else if (viewportPos.x() >= qxt_p().viewport()->width() - (iScrollHorizontal / 2))
{
int iCurrPos = qxt_p().horizontalScrollBar()->value();
if (iCurrPos < qxt_p().horizontalScrollBar()->maximum() - iScrollHorizontal)
{
qxt_p().horizontalScrollBar()->setValue(iCurrPos + iScrollHorizontal);
}
else
qxt_p().horizontalScrollBar()->setValue(qxt_p().horizontalScrollBar()->maximum());
}
}
| int QxtScheduleViewPrivate::unixTimeToOffset | ( | const uint | constUnixTime, |
| bool | indexEndTime = false |
||
| ) | const |
Definition at line 462 of file qxtscheduleview_p.cpp.
References m_currentZoomDepth, m_endUnixTime, m_startUnixTime, QxtPrivate< QxtScheduleView >::qxt_p(), QxtScheduleView::rows(), and visualIndexToOffset().
{
uint unixTime = constUnixTime;
if (unixTime >= m_startUnixTime && unixTime <= m_endUnixTime)
{
if (indexEndTime)
{
unixTime -= m_currentZoomDepth;
}
qint32 rows = qxt_p().rows();
qint32 iOffset = unixTime - m_startUnixTime;
//round to the closest boundaries
iOffset = qRound((qreal)iOffset / (qreal)m_currentZoomDepth);
qint32 iCol = iOffset / rows;
qint32 iRow = iOffset % rows;
return visualIndexToOffset(iRow, iCol);
}
//virtual void handleItemOverlapping(QxtScheduleInternalItem *item);
return -1;
}
| int QxtScheduleViewPrivate::visualIndexToOffset | ( | const int | iRow, |
| const int | iCol | ||
| ) | const |
Definition at line 52 of file qxtscheduleview_p.cpp.
References QxtPrivate< QxtScheduleView >::qxt_p().
Referenced by calculateRangeGeometries(), pointToOffset(), and unixTimeToOffset().
{
return (iCol* qxt_p().rows()) + iRow;
}
friend class QxtScheduleView [friend] |
Definition at line 109 of file qxtscheduleview_p.h.
Definition at line 174 of file qxtscheduleview_p.h.
Definition at line 173 of file qxtscheduleview_p.h.
Referenced by QxtScheduleViewPrivate().
Definition at line 172 of file qxtscheduleview_p.h.
Referenced by handleItemConcurrency(), and QxtScheduleViewPrivate().
Definition at line 169 of file qxtscheduleview_p.h.
Referenced by QxtScheduleViewPrivate().
Definition at line 151 of file qxtscheduleview_p.h.
Definition at line 157 of file qxtscheduleview_p.h.
Definition at line 155 of file qxtscheduleview_p.h.
Referenced by offsetToUnixTime(), and unixTimeToOffset().
Definition at line 159 of file qxtscheduleview_p.h.
Referenced by offsetToUnixTime(), and unixTimeToOffset().
Definition at line 167 of file qxtscheduleview_p.h.
Referenced by calculateRangeGeometries(), handleItemConcurrency(), init(), pointToOffset(), QxtScheduleViewPrivate(), and scrollTimerTimeout().
Definition at line 162 of file qxtscheduleview_p.h.
Definition at line 161 of file qxtscheduleview_p.h.
Referenced by findConcurrentItems(), handleItemConcurrency(), internalItemAt(), itemForModelIndex(), and reloadItemsFromModel().
Definition at line 154 of file qxtscheduleview_p.h.
| QAbstractItemModel* QxtScheduleViewPrivate::m_Model |
Definition at line 171 of file qxtscheduleview_p.h.
Referenced by QxtScheduleViewPrivate().
Definition at line 152 of file qxtscheduleview_p.h.
Referenced by QxtScheduleViewPrivate(), and reloadItemsFromModel().
Definition at line 158 of file qxtscheduleview_p.h.
Referenced by offsetToUnixTime(), and unixTimeToOffset().
Definition at line 166 of file qxtscheduleview_p.h.
Referenced by calculateRangeGeometries(), init(), pointToOffset(), QxtScheduleViewPrivate(), and scrollTimerTimeout().
Definition at line 156 of file qxtscheduleview_p.h.
Referenced by QxtScheduleViewPrivate().
Definition at line 164 of file qxtscheduleview_p.h.
Referenced by QxtScheduleViewPrivate().
1.7.2
